- Page 1 Installation Manual INTEGRATED ACCESS CONTROLERS PROXIMITY CARD READERS KZC-800-U/H KZC-800-M KZC-900-U/H VERSION 1.2 Update 29.12.2014...
- Page 2 These models supports 13.56MHz IC Mifare cards (KZC-800-M) or 125KHz EM, HID Prox cards (KZC-800-U/H i KZC-900-U/H ). It controls 1 door, supports up to 2000 users in total, each user have one card and one PIN (PIN - 1234 as de- fault, should be change for normal using).
-
Page 3: Technical Specifications
Wiegand 26~37 input & output Wiring Connections Electric lock, External alarm, Door status (NC), Exit button (NO), Bell Dimensions: KZC-800-U/H/M 125 x 83 x 22 mm (HxWxD) KZC-900-U/H 159 x 43 x 22 mm (HxWxD) All rights reserved. © AAT HOLDING S.A. -
Page 4: Unit Installation
Thread the cable through the cable hole Attach the unit to the metal bracket (figure 2) Fix 2 pcs. safe screws at the bottom of the unit using supplied tools (fig. 3) All rights reserved. © AAT HOLDING S.A. - Page 5 ALARM Alarm output Lock A connection - for NC type - Normally Close - locked without supply power Lock B connection - for NO type - Normally Open - locked with supply power All rights reserved. © AAT HOLDING S.A.
- Page 6 It will be not conducted when alarm is removed Principle of Door Bell Connector Each press of door bell button, contact of relay in BELL_A and BELL_B will close contact for 200mS then release. All rights reserved. © AAT HOLDING S.A.
-
Page 7: User Operation
In Toggle mode, every time a valid card/tag read or PIN input, the relay changes state, which will not turn back until read card/tag or input PIN again. All rights reserved. © AAT HOLDING S.A. - Page 8 1 second (when LED is orange), release it until hearing two shot beep, then hearing a long beep, enter normal mode - it means reset to factory default set- ting is successfully. Remark: Reset to factory default, the users' information is still retained. All rights reserved. © AAT HOLDING S.A.
-
Page 9: Sound And Light Indication
“*”, the logo light will indi- cate the operation mode. Note that to undertake the following programming, the master user must be logged in. All rights reserved. © AAT HOLDING S.A. - Page 10 Integrated Access Controller – Installation manual 9.1 Basic Operation： 50 ms All rights reserved. © AAT HOLDING S.A.
- Page 11 Integrated Access Controller – Installation manual In 10 minutes, if there's 10 times ⑨ invalid card or wrong password, the device will lock on for 10 minutes. All rights reserved. © AAT HOLDING S.A.
- Page 12 The external reader only read card or as a device for input PIN, you can connect with a numbers of readers , but function all same. External Reader Access Access (Inside Door) Host Host (Outside Door) (Outside Door) Standalone for single door Anti-pass back for single door All rights reserved. © AAT HOLDING S.A.
- Page 13 (Factory default is 26Bit) Wiegand 26 card reader, HID card can out- put Wiegand 26~37 automatically, other cards are output Wiegand 26 compul- sively. Wiegand 27~37 card reader, all cards are forced output Wiegand 27~37. All rights reserved. © AAT HOLDING S.A.
- Page 14 Integrated Access Controller – Installation manual All rights reserved. © AAT HOLDING S.A.
- Page 15 If without the entering record from access host, the users can not exit from the inside reader, also the users can't en- ter in twice without the first exit record. All rights reserved. © AAT HOLDING S.A.
