- Page 1 Avonic AV-CAP100 HDMI to USB3.0 Video Capture Dongle User Manual Version 1.1 Update notes: Join Avonic linkedin.com/company/avonic twitter.com/avonic1 facebook.com/avonic www.avonic.eu...
-
Page 2: Table Of Contents
Safety Notes ............................3 Package contents and Accessories ..........3 Product Overview ................3 Features ............................... 4 Product Description ..........................4 Installation ..................5 Connection Diagram ..........................5 Operation Instructions ..............5 Contact ..................6 Appendix ..................7 Technical Data ............................. 7 www.avonic.eu... -
Page 3: Introduction
USB 3.0 cable Product Overview The Avonic AV-CAP100 HDMI to USB3.0 Video Capture Dongle is easy to carry, has a superior performance and superior compatibility. It can capture one HDMI 1080p60 input and output signal; compatible with Windows, Linux, Mac OS X and USB 3.0 interface. Compatible with many USB 3.0 chipset (Intel, Renesas, ASMedia, Fresco Logic), compatible with PCIe Gen1.1 x1 expansion via USB... -
Page 4: Features
2. USB3.0 Capture out: connect to the USB3.0 input of the computer or Notebook. 3. Power indicator: LED illuminates when the device is connected to computer USB port. 4. Action indicator: LED illuminates when the device capture the video normally. www.avonic.eu... -
Page 5: Installation
Use a USB 3.0 cable to connect from the dongle to PC or Notebook. Operation Instructions The Avonic AV-CAP100 HDMI to USB3.0 Video Capture Dongle is based on UVC (USB video class) and UAC (USB audio class) standard. No additional drivers have to be installed. After installation in operating system, the relevant video and audio devices will be added. -
Page 6: Contact
Then play, stream or save the content to a desired location. Contact For any questions or suggestions, contact the reseller or the local distributor of Avonic. Find the local distributor on the website of Avonic. For the recent manual or datasheet, look at the Avonic website. -
Page 7: Appendix
Player (OS X), Wirecast (Windows, S X) , Potplayer(Windows)and etc. Development interface compatibility, DirectShow (Windows), DirectSound (Windows), V4L2 (Linux), ALSA (Linux),OS X (QuickTime) Size 98x56x16 (L/W/H, mm) Power consumption <= 2.5W Working Temperature 0-50 °C Storage Temperature -20-70 °C Storage Humidity 5%-90% www.avonic.eu...
