Page 1: User Manual
ZigBee - Wireless Methane Gas Detector User Manual Wireless Methane Gas Detector Model: ZA01B 20151127... -
Page 2: Table Of Contents
Table of Contents 1. Introduction................................2 2. Product Appearance..............................3 3. Specification................................4 4. Setting up ZA01B..............................5 4-1. Join the ZigBee Network..........................5 4-2. Enroll in the ZigBee Security System......................5 4-3. Permit-Join..............................5 4-4. Alert Test.................................5 4-5. Gas Sensing..............................6 4-6. -
Page 3: Introduction
1. Introduction Netvox ZA01B, a gas detector with heat sensor, acts as a Router Device in ZigBee network. ZA01B is featured to play a role of the sensor (Zone device) in the ZigBee security system. When the leak is occurring, ZA01B would send out the alert message to the Warning Device. -
Page 4: Product Appearance
2. Product Appearance Binding Key Test Key Indicator Sensor Mounting... -
Page 5: Specification
3. Specification Fully IEEE 802.15.4 compliant Utilizes 2.4GHz ISM band; up to 16 channels Power supply: 100~240VAC; 50/60Hz Power consumption: 19.8mA@220VAC Up to 195 meters wireless transmission range in non-obstacle space Easy installation and configuration ... -
Page 6: Setting Up Za01B
ZA01B is a Zone device in the ZigBee security system. Right after ZA01B join the ZigBee network, it will automatically find out a CIE (Control and Indicating Equipment) device (i.e. Netvox Z201B) and send a registration request to the CIE device to enroll in the security system. The enrollment has these 3 situations: A. -
Page 7: Gas Sensing
sound. The indicator keeps flashing red. D. ZA01B is not enrolled in the Security System → it sends the enrollment request. After the enrollment is successful, it will generate an alert sound. 4-5. Gas Sensing When the leak is occurring, ZA01B would send out the alert message to the Warning Device. It will also send the notification to CIE device or to the device which is bound using Cluster ID (0x0500). -
Page 8: Home Automation Clusters For Za01B
0x00 – Read only -------- 8-bit integer 0xff 0x0003 HWVersion Unsigned 0x00 – Read only -------- 8-bit integer 0xff 0x0004 ManufacturerName Character 0 – 32 Read only netvox string bytes 0x0005 ModelIdentifier Character 0 – 32 Read only -------- string bytes... - Page 9 0x0006 DateCode Character 0 – 16 Read only ------- string bytes 0x0007 PowerSource 8-bit 0x00 – Read only 0x04 Enumeration 0xff 0x0010 LocationDescription Character 0 – 16 Read/write -------- string bytes 0x0011 PhysicalEnvironment 8-bit 0x00 – Read/write ------- Enumeration 0xff 0x0012 DeviceEnabled Boolean...
-
Page 10: Installation
6. Installation Natural gas, gas Place within 30 cm from ceiling < 6 meters < 3 meters Gas Stove Liquefied petroleum gas Place within 30 cm from ground 7. Important Maintenance Instructions Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits.
