Plum 25501 Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. Plum Manuals
  4. Play Sets & Playground Equipment
  5. 25501
  6. Assembly instructions manual

Plum 25501 Assembly Instructions Manual

Look-out tower
Hide thumbs

Advertisement

Quick Links

Download this manual
look-out tower
WARNING!
Not suitable for children under 36 months – fall hazard/small parts
-choke hazard.
Min user age 3 years. Max user age 12 years. Max user weight
50kg. Only for domestic use. Outdoor use only. Adult assembly required. Adult
supervision recommended at all times.
assembly
instructions
25501
assembly requires 2 adults
(approx. 4 hours assembly time)
69/V5

Advertisement

loading
Need help?

Need help?

Do you have a question about the 25501 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Plum 25501

Summary of Contents for Plum 25501

  • Page 1 25501 assembly instructions look-out tower assembly requires 2 adults (approx. 4 hours assembly time) WARNING! Not suitable for children under 36 months – fall hazard/small parts -choke hazard. Min user age 3 years. Max user age 12 years. Max user weight 50kg.

  • Page 2: Routine Maintenance

    Remember to keep these instructions in a safe place for future reference. Plum Products Ltd, The Cliff, Middle Street, Ingham, Lincolnshire, LN1, 2YQ, UK Plum Products Australia Pty Ltd Tel: +44 (0) 344 880 5302 Suite 303, 156 Military Road, Fax: +44 (0) 152 273 0379 Neutral Bay NSW 2089 Australia customerservices@plumproducts.com...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS WARNING! Minimum user age 3 years Maximum user age 12 years Maximum user weight 50kgs Not suitable for children under 36 months – small parts Adult assembly required Adult supervision recommended at all times Only for domestic use Outdoor use only Not suitable for children under 36 months –...
  • Page 4 Es wird empfohlen, dass die Rutsche nicht in Richtung Sonne aufgestellt wird, da sich die Oberfläche erhitzt und diese unangenehm warm wird Denken Sie daran, dass Sie diese Anleitung für eine spätere Nutzung sicher aufbewahren Der Anker verhindert, dass der Rahmen während der Nutzung angehoben wird Es wird empfohlen, dass alle wichtigen Teile/Befestigungen regelmäßig (also am Anfang der Saison und danach monatlich) darauf überprüft werden, ob diese sicher und gut geölt (falls metallisch) und intakt sind, und keine scharfen Ecken und Kanten aufweisen.
  • Page 5 AVERTENCIA Edad mínima del usuario 3 años No es conveniente para niños menores de 36 meses, ya que posee partes pequeñas que podrían causar asfixia. Se recomienda en todo momento la supervisión de un adulto Edad máxima del usuario: 12 años Utilícese exclusivamente en el ámbito domésticoUtilícese exclusivamente al aire libre No es conveniente para niños menores de 36 meses: peligro de caídas Peso máximo del usuario en cada columpio: 50kgs...
  • Page 6 Odporúča sa pravidelná kontrola (napr. na začiatku sezóny a potomo mesiac) hlavných častí/upevnení, či sú zaistené, dobrr naolejované (ak sú kovové), či na nich nie sú ostré body/rohy a či sú kompletné. V prípade potreby ich nahraďte, naolejujte a/alebo utiahnite. Zanedbanie takejto činnosti môže mať za následok úraz alebo iné nebezpečenstvo Všetky prídavné...
  • Page 7 Skal samles af en voksen Gyngesæder skal være minimum 350 mm over jorden Placeres på en jævn overflade, mindst 2 m fra bygninger eller andre forhindringer Må ikke installeres over beton, asfalt eller andre hårde overflader. Husk at gemme disse vejledninger på et sikkert sted for fremtidig brug. Ankeret skal fastgøres, så...

  • Page 8: Wood: Parts List

    WOOD: PARTS LIST FASTENER LIST: (WOOD PACK 3) PART ID QUANTITY WOOD PACK 1 M8 x 125 125mm D1656 2100 x 68 x 68mm M8 x 100 100mm D2006 2100 x 68 x 68mm M8 x 70 70mm D2067 2100 x 68 x 68mm M8 Washer WOOD PACK 2 M8 Washer...
  • Page 9 ACCESSORIES: PART ID QUANTITY D1936 430 x 44 x 24mm D1938 750 x 44 x 44mm H121 D1939 924 x 88 x 18mm WOOD PACK 3 D1973 1374 x 88 x 28mm D1974 1374 x 88 x 28mm D1930 926 x 68 x 28mm H122 D1671 1035 x 88 x 12mm...
  • Page 10 M8 x 125 M8 x 70 125mm 70mm M8 Spring Washer M5 x 60 D1930 D1930 60mm M8 Washer   M8 Nut D2006 D1656 D1930 D1658    D1652 M8 x 125 M8 x 70 125mm 70mm M8 Spring Washer M5 x 60 60mm M8 Washer...
  • Page 11 D1661 900 x 88 x 18mm M5 x 60 60mm D1652 944 x 88 x 18mm M5 x 60 60mm   ...
  • Page 12 D1663 M5 x 40 40mm 944 x 88 x 18mm D2008 944 x 120 x 18mm D1664 808 x 68 x 18mm D1931 D1663 808 x 50 x 18mm 808 x 50 x 18mm D1931 D1664 2008 944mm...
  • Page 13 D1662 330 x 68 x 28mm D1733 287.5 x 68 x 28mm M5 x 60 60mm D1733 M5 x 40 40mm...
  • Page 14 M5 x 60 60mm D1937 1113 x 44 x 24mm M5 x 60 60mm D1936 430 x 44 x 24mm...
  • Page 15 D1932 30mm 808x125x18mm T-NUT SPRING WASHER (Shapes & T-Nut Colours will vary) M5 x 40 40mm D1934 D1932 D1933...
  • Page 16 M5 x 40 D1938 40mm 750 x 44 x 44mm M4 x 60 60mm D1939 924 x 88 x 18mm H112 M5 x 16 16mm...
  • Page 17 M4 x 25 25mm M5 x 40 40mm M4 x 25 M4x25 25mm M5x40 D1666 D2007...
  • Page 18 D1940 608 x 44 x 44mm D1670 343 x 120 x 18mm M5 x 40 40mm D1671 1035 x 88 x 12mm D2066 1035 x 88 x 12mm M5 x 40 40mm D2066 D2066...
  • Page 19 M5 x 90 90mm...
  • Page 20 M5 x 40 40mm D1941 660 x 88 x 18mm M2 x 25 25mm D1735 1035 x74 x38mm...
  • Page 21 D1673 1374 x 88 x 28mm D1674 1374 x 88 x 28mm D1675 395 x 40 x 40mm M5 x 40 40mm M8 x 100 100mm M8 Washer 16mm M8 Nut 16mm 16mm...
  • Page 22 H122 H121 H123...
  • Page 23       SH:M6 x 90 M6 Washer 90mm D1734 M6 Nut 380 x 44 x 44mm...
  • Page 24 Concrete Concrete Thank you for purchasing a Plum Product. Product safety and customer satisfaction are our priorities and we value your opinion. If you could spare two minutes to complete the customer feedback survey at http://www.plumproducts.com/feedback we would appreciate it.
