Truth Sentry II Operating Instructions Manual

Hand held remote
Hide thumbs Also See for Sentry II:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Instructions Manual
An FKI Industries Company
700 West Bridge Street
Owatonna, MN 55060
1-800-324-4487
www.truth.com
Form 90059 R1
Danger: To help prevent severe personal injury or death:
o Read and understand instructions completely before beginning
o When connecting the Sentry 2 system to accessories, read the
o Save ALL instructions.
o
o
o
o
o
o
o
o
o Do not allow children to operate the wall push buttons or remote
LANGUAGES
ENGLISH PAGE 1
ESPAÑOL PAGINA 10
FRANÇAIS PAGE 20
installation.
installation instructions supplied with each accessory before
beginning installation.
Installer – please be sure to give ALL instructions to the
homeowner once installation is complete.
Wiring must be installed by a qualified electrician according to local
and National Electrical Codes (N.E.C.)
Disconnect main power before beginning installation! Verify that
power is OFF at the main breaker or fuse panel by testing with a
voltage meter that you know is working correctly.
Connect power only after motor connections and settings are
verified.
This equipment does not provide a method to shut off power, and
should be connected to a dedicated breaker or fused power circuit.
The Sentry 2 system should not be used on windows that are
intended to meet egress codes.
The Sentry 2 system is intended for indoor use only, with screens in
place.
The screen interlock MUST be correctly mounted and is a required
part of the installation. It is intended to help prevent injury that could
result from reaching into the window or skylight area during
operation. The correct installation of the screen interlock is the
responsibility of the installer.
control transmitter(s).
Sentry II
Hand Held Remote

Operating Instructions

Made in USA
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sentry II and is the answer not in the manual?

Questions and answers

Related Manuals for Truth Sentry II

Summary of Contents for Truth Sentry II

  • Page 1: Operating Instructions

    Sentry II ® An FKI Industries Company Hand Held Remote 700 West Bridge Street Owatonna, MN 55060 1-800-324-4487 Operating Instructions www.truth.com Form 90059 R1 Danger: To help prevent severe personal injury or death: o Read and understand instructions completely before beginning installation.
  • Page 2 Important Information o This remote control is an RF (radio frequency) device and therefore does not need to be pointed in any manner toward the intended window/skylight to be operated. The effective range for this remote is approximately 100ft, but this varies with application conditions such as: wall materials, mounting height of receiver and interference from other devices radiating on RF frequencies.

  • Page 3: Regulatory Compliance

    Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications not expressly approved by Truth Hardware could void the FCC compliance and negate your authority to operate the product. FCC Declaration of Conformity According to 47 CFR, Parts 15.107 and 15.109 Class B...

  • Page 4: Programming The Remote Control

    Programming the Remote Control If optional Hand Held Remote was purchased, it can now be programmed using the “Learn” button (see S1 on wire diagram) Program the remote using the following steps: Place three “AAA” batteries into the Remote. The display on the Remote will be blank except for the word “SET” “Set”...
  • Page 5 Press the “Open” button on the remote once. Press “Open” Open Unit Mode Close The display on the remote should change to show both the unit as “All” and the ambient temperature. Motor Unit By pressing the “Unit” button on the remote, select the desired Unit Code which will represent this window/skylight.
  • Page 6 Options for programming multiple units: There are a number of different programming possibilities provided by the “Unit” code function of the Sentry 2 remote. Here are a few: 1. Grouped Units on Single Unit Code: By pressing the “Learn” button on a number of selected control panels you can simultaneously program more than one window or skylight to a single unit code.

  • Page 7: Normal Operation

    Normal Operation: Motor Unit or Group the Room remote is set to Temp. Unit control. Mode selects the function to be controlled. Open ie: Motor, Blind etc... Mode Unit Close To “Open” a selected window/skylight. 1) Using the “Unit” key select the number which you programmed into the control unit for the selected window or skylight.

  • Page 8: Thermostat Operation

    Thermostat Operation: Therm Use Mode button Unit Use Unit button to to select “therm” select the units to be controlled by the thermostat. Open Unit Mode Close To control a selected window/skylight via the internal thermostat in the hand held remote.
  • Page 9 Note:The temperature display can provide either Fahrenheit (F) or Celsius (C) by changing the position of switch 2 found behind the battery door. Remove the batteries before changing position of switch 2. This Switch changes Temp. display from F to C.

  • Page 10: Forced Re-Initialization

    Forced Re-initialization: Motor Unit Open Unit Mode Close Press Unit & Mode buttons together and hold for “Reset” When an error is noted in the operation of the motor unit (indicated by a Flashing RED light on the wall plate or status indicator), the unit can be “Reset” by forcing a re-initialization via the remote control.
