- Page 1 PICO REPEATERS OR2-SBLP2 SERIES TECHNICAL HANDBOOK Radio Frequency Systems...
-
Page 2: Table Of Contents
3.1. System Configuration..................8 • WCDMA System configuration ............... 8 3.2 Detail Frequency Information................8 3.3 OR2-SBLP2-21F General Performance Specification ........8 3.4 OR2-SBLP2-21F Fading Performance Specification........9 3.5 System Configuration................... 9 3.6 Environmental Specification ................9 3.7 Mechanical Specification ..................9 4. - Page 3 List of Figures [Figure - 1] System Network Configuration..............6 [Figure - 2] NMS Network [Figure - 3] Front, Side View [Figure - 4] Unit [Figure - 5] External Connectors Radio Frequency Systems...
- Page 4 List of Tables [Table - 1] RF System configuration................8 [Table - 2] Detail Frequency Information [Table - 3] OR2-SBLP2-21F General Performance Specification [Table - 4] OR2-SBLP2-21F Fading Performance Specification [Table - 5] System Configuration [Table - 6] Environmental Specification...
-
Page 5: System Overview
(Interference Cancellation System) to make the most efficient way to enhance WCDMA network. OR2-SBLP2-21F consists of the same components as normal RF repeater except DSP (Digital Signal Processing) part and it can overcome oscillation problem caused by lack of the isolation level between donor and coverage antennas. -
Page 6: System Network Configuration
OR2-SBLP2-21F is the advanced antenna-embedded ICS repeater for indoor coverage enhancement. This repeater adopted automatic setup feature with Plug & Play to save time and installation cost. Network layout with OR2-SBLP2-21F is as follows. [Figure - 1] System Network Configuration OR2-SBLP2-21F receives input signals through donor antenna from Node-B for DL and receives input signals through service antenna from a cell phone. -
Page 7: Nms Network
2.2. NMS Network OR2-SBLP2-21F can be operated with its own RMS (Remote Monitoring System) or connected with the existing remote management system if the operator provides the protocols. The Connection between Remote management system and OR2-SBLP2-21F follows the standard of network operators. -
Page 8: System Configuration & Specification
DL, UL 3 us Gain Tracking Time Target Gain ±1dB < 10 Sec -10dB < Gain < 10dB Accuracy ±3 Isolation Sensing Range (-5dB < Gain < 5dB) (Accuracy ±1) [Table - 3] OR2-SBLP2-21F General Performance Specification Radio Frequency Systems... -
Page 9: Or2-Sblp2-21F Fading Performance Specification
Gain Variation : < ±2dB EVM : ≤ 12.5% G = I 3Hz General Operating Gain Variation : < 2dB [Table - 4] OR2-SBLP2-21F Fading Performance Specification 3.5 System Configuration Item Specification AGC(Automatic Gain Control) & Boundary AGC Total Power Limit Additional Features Real time Isolation monitoring. -
Page 10: Housing
4. Housing 4.1 Composition • System Exterior [Figure - 3] Front, Side View Donor Service - internal antenna – Radio Frequency Systems... -
Page 11: External Connectors
A Type B Type - Donor anntena option - [Figure - 4] Unit • External Connectors [Figure - 5] External Connectors Radio Frequency Systems... -
Page 12: [Table - 6] Mechanical Specification
Item Specification Size 117mm(W) X 167mm(H) X 55mm(D)(Without Stand) Material Aluminum for rust protection Cooling Natural Convection with Heat Sink Lock Bolt 1. Indoor Type 2. ∆T: below 20° Environmental (∆T: Highest temperature in Chamber Vs. Highest Condition temperature of repeater inner part) 3.Vibration : 1.5G, 10~100Hz, 0.1oct/min, XYZ [Table - 6] Mechanical Specification Radio Frequency Systems... -
Page 13: Module Specification
5. Module Specification 5.1 Internal Antenna • Donor Antenna Specification Specification Remark Micro-strip Patch 1920MHz ~ 1980MHz Up link Frequency Range 2110MHz ~ 2170MHz Down link Polarization Vertical Gain > 7dBi F/B Ratio ≥ 15dB Horizontal : 60°±10° Electrical Beam width Vertical : 60°±10°... -
Page 14: External Antenna
5.2 External Antenna Specification Remark Micro-strip Patch 1920MHz ~ 1980MHz Up link Frequency Range 2110MHz ~ 2170MHz Down link Gain > 7dBi F/B Ratio ≥ 15dB Electrical Horizontal : 60°±10° Beam width Characteristic Vertical : 60°±10° V. S. W. R <... -
Page 15: Lcd Display Configuration
6. LCD Display Configuration 6.1 LCD display Configuration Function Details Remark Display LCD Indicator (Alarm, Status, Control) Control Tact SW#1, Tact SW#2 Up/Down Compatible Back Light Blue Back Light For 3 Minute 6.2 Alarm and Status Display Section Segment Details Remark Input Power Scale Status... -
Page 16: Downlink Input/ Output Power Display
6.3 Downlink Input/ Output Power Display Input Power Range Scale Output Power Range Scale -85dBm 0 Segment ~-10dBm 0 Segment -84 ~ -76dBm 1 Segment -9 ~-4dBm 1 Segment -75 ~ -67dBm 2 Segment -3 ~ +2dBm 2 Segment -66 ~ -58dBm 3 Segment +3 ~ +8dBm 3 Segment... -
Page 17: Installation Guide
7. Installation Guide 7.1. Accessory • Pico Repeater 1EA • AC/DC Adaptor 1EA • Donor Antenna 1EA (Inside Repeater) • Service Antenna 1EA (Inside Repeater) • External Antenna 1EA • SMA To SMBL Adaptor Cable 7.2. Installation Chart • Connect the Power Adaptor to repeater power port before installation •...
