SD Biosensor SD GlucoNavii Voice N User Instruction Manual

Blood glucose voice monitoring system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Voice N
Voice N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD GlucoNavii Voice N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SD Biosensor SD GlucoNavii Voice N

Summary of Contents for SD Biosensor SD GlucoNavii Voice N

  • Page 1 Voice N Voice N...
  • Page 2 Monitoring System is an important tool that can help you better manage your diabetes. Important steps for using the System are inside this guide. Please read it carefully. If you have questions, we are here to help. Please contact SD Biosensor, Inc. Tel : +82-31-300-0400 Fax : +82-31-300-0499 website : www.sdbiosensor.com We o er assistance 24 hours a day, 365 days a year in many languages.

  • Page 3: Table Of Contents

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM TABLE OF CONTENTS Chapter 1 : Understanding Your New System Before You Start Testing Special Information for Healthcare Providers and Caregivers Indication for Use Product Description and the Principle of the use The Complete SD GlucoNavii®...
  • Page 4 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Chapter 4 : Using NFC function Information on NFC function Information on Caution for NFC Using NFC function How to use GlucoNaviiApp How to use SD NFC Software for PC Chapter 5 : Using the Meter Memory Searching Test Results Downloading results to a computer Chapter 6 : Maintenance and Troubleshooting...

  • Page 5: Chapter 1 : Understanding Your New System

    If you see any damage to the container cap or if anything prevents the cap from closing properly, do not use the test strips. Contact SD Biosensor, Inc. Damaged test strips can cause inaccurate results, which could lead to improper treatment.
  • Page 6 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Keep the meter and testing supplies away from small children. The battery door, test strips, lancets, protective disks, and control solution cap are choking hazards. CAUTION Do not eat the test strips. Do not swallow or inject SD GlucoNavii®...

  • Page 7: Special Information For Healthcare Providers And Caregivers

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Guide, call your healthcare professional. Never ignore symptoms or make signi cant changes to your diabetes control program without speaking to your healthcare professional. Consult your physician to determine if it is appropriate for your child to be taught how to use the meter system or any other medical products.
  • Page 8 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM blood sample mixes with reagent on the test strip that cause a small electric current. The amount of current that is created depends on how much glucose is in the blood. SD GlucoNavii® Voice N meter measures the current that is created and converts the measurement to the amount of glucose that is in the blood.

  • Page 9: Sd Gluconavii® Voice N Meter

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 6. SD GlucoNavii® Voice N Meter Display Shows blood glucose result, messages, and glucose result stored in memory. Voice N ON/OFF Button Press to turn meter ON or OFF. Arrow Buttons Use for meter setup and review of memory moving to the right and left.
  • Page 10 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Display Indicates Indicates during the meter Measurement time setting Warns when the batteries Indicates sound are low or must be level replaced Indicates if environmental Indicates post-meal or temperature is pre-meal exceeded during testing Indicates a test result stored Testing date...
  • Page 11 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Indicates the Test strip average result Tell you when to apply the sample and indicates if you Indicates a control select whole blood solution test result for blood reference type Indicates alarm Indicates hypo warning setting Indicates time...
  • Page 12 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 1) Strip Stand-by Display After turning on the meter, the below' will be displayed automatically to show the test strip icon ashing. When the test strip icon is ash at any setting stage, it can be strip stand-by mode.

  • Page 13: Sd Gluconavii® Voice N Test Strips

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM SD GlucoNavii® Voice N Test Strip SD GlucoNavii® Voice N System measures the amount of glucose in whole blood. Blood is applied in the Yellow Window (TOP EDGE) of SD GlucoNavii® Voice N Test Strip and is automatically drawn into the reaction cell where the reaction takes place.

  • Page 14: Sd Gluconavii® Voice N Accessories

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 8. SD GlucoNavii® Voice N Accessories Lancet SD Glucose check strip Electrode Arming Knob Lancing Device Cap & Comfort dial with puncture depth selection Release Arming Button Knob SD GlucoNavii® control solution SD Voice N Reader/Writer...

  • Page 15: Changing The Battery

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 9. Changing the Battery Inserting and replacing the Battery Your meter is shipped with two 1.5V AA alkaline batteries that needs to be inserted before testing. The batteries that come with your meter can be found in the mesh pocket of your carrying case.
  • Page 16 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM STEP-2: Insert the 1.5V AA alkaline batteries into the compartment correctly with respect to their polarity (follow the directions on the case). 1.5V AA 1.5V AA STEP-3: Snap battery cover back in place. STEP-4: Push the ON/OFF button or insert a strip to start testing.

  • Page 17: Meter Set Up

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 10. Meter Set up STEP-1 : Setting the sound level In strip stand-by mode with sound icon, if you press the ON/OFF button, the display for setting the sound level will be appeared. Set the sound level by pressing the left or right button.
  • Page 18 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM STEP-2: Setting the Hypo warning In strip stand-by mode with set icon, if you press the ON/OFF button, the display for setting the hypo warning will be appeared. NOTE Set the OFF or 60/70/80 mg/dL by pressing the left or right button.
  • Page 19 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM STEP 3: Setting the date and time [ Date Setting ] In strip stand-by mode with hypo set icon, if you press the right button, the display for setting the date & time will be appeared.
  • Page 20 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Next will appear the setting display for month and day format. The meter can display the month and day in either a Month-Day (m-d) format or a Day-Month (d- m) format. Set the preferred format on the display by pressing either the left or the right button and select by pressing the ON/OFF button.
  • Page 21 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM [ Time Setting ] Next will appear the display for setting the 12 or 24 Hour clock format. The meter can display the time in either the 12h format or the 24h format. Set the preferred format on the display by pressing either the left or the right button and select by pressing the ON/OFF button.
  • Page 22 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM STEP 4: Post-meal alarm You can use the meter’s post-meal alarm function to remind you to test your blood glucose after meal. In strip stand-by mode with time set icon, if you press the right button, the display for setting the post-meal alarm set icon will be appeared.
  • Page 23 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Set the post-meal alarm mode ‘2h’ or ‘o ’ by pressing either the left or the right button and then select the preferred feature by pressing the ON/OFF button. [Left or right [ON/OFF button] button]...
  • Page 24 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM STEP 5: Setting the alarm You can use the meter’s alarm function to remind you to test your blood glucose. In strip stand-by mode with post-meal alarm set icon, if you press the right button, the display for alarm set icon will be appeared.
  • Page 25 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Set the rst alarm on or o by pressing either the left or the right button and then select the preferred feature by pressing the ON/OFF button. [Left or right [ON/OFF button] button] If you select the alarm o feature, next will appear the Strip Stand-by Display.
  • Page 26 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM If you nish setting the rst alarm, next will appear the second alarm setting mode. Set the alarm with the same way as above. [2, 3] You can set the third and fourth alarm mode with the same way as above.
  • Page 27 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Right Left button button ON/OFF button Right button Right button Right Right button button ON/OFF button...
  • Page 28 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM When you press the left or right button, 'L-1' , 'L-2' and 'L-3' will be appeared. The meter has 3 di erent languages per each country. Language numbers are as follows. L 1 : English L 2 : Spanish L 3 : French L 4 : German...

  • Page 29: Using Sd Gluconavii® Voice N Test Strips

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 11. Using SD GlucoNavii® Voice N Test Strips [ Important Test Strip Information ] SD GlucoNavii® Voice N blood glucose test strip should be used with SD GlucoNavii® Voice N meter. Using other glucose test strip can cause inaccurate the result or ‘E-1’...
  • Page 30 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Avoid getting dirt, food or liquids on the test strip. With clean, dry hands, you may touch the test strip anywhere on its surface. Do not bend, cut, or alter SD GlucoNavii® Voice N Test Strip in any way.

  • Page 31: Chapter 2 : Control Solution Test

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM CHAPTER 2 : Control Solution Test Why you do control solution test ; SD GlucoNavii® control solution is used to check that the meter and the test strips are working together as a system and that you are performing the test correctly.

  • Page 32: Performing A Control Solution Test

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM Shake the container, discard the rst drop of control solution, and wipe o the tip to ensure a proper sample and an accurate result. Store SD GlucoNavii® control solution tightly closed at temperatures between 8-30°C (46-86°F). Do Not refrigerate.
  • Page 33 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM STEP-1: Remove a new test strip from container. Be sure to tightly replace container cap after removing test strip. Insert a test strip (yellow window printed ‘ ’ facing up) into test strip slot. The meter turns on automatically. VOICE N STEP-2: Press the left button for 3 seconds to check the testing...
  • Page 34 SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM The control solution result appears on the screen in just 5 seconds. Compare control solution result with the range printed on the test strip container. If the results are not within the control range printed on the test strip container, then the meter and strips may not be working properly.

  • Page 35: Troubleshooting Control Solution Test

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM 2. Troubleshooting Control Solution Test Check Action Did you do the test in If not, do the test again. Insert a control solution mode? test strip; Press the left button Did you see “control for 3 seconds in Blood Stand- solution container icon”...
  • Page 36 Repeat the test. If you get the Is the control result same results, do not use your outside the acceptable meter and test strip until you range(printed on your solve the problem. If you still test strip container)? have problem, call SD Biosensor, Inc. at +82-31-300-0400.

  • Page 37: Chapter 3 : Testing Your Blood Sugar

    SD GlucoNavii® Voice N BLOOD GLUCOSE MONITORING SYSTEM CHAPTER 3 : Testing Your Blood Sugar 1. Getting a Drop of Blood Wash your hands in warm, soapy water. Rinse well and dry completely. Warming ngers can increase blood Turn the lancet insert cap counterclockwise to remove it, insert the lancet into the lancing device holder and push down rmly until it is fully seated.
