Universal Remote (RM pro) Quick Guide
compatible with Amazon Alexa

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RM Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BroadLink RM Pro

  • Page 1 Universal Remote (RM pro) Quick Guide compatible with Amazon Alexa...
  • Page 2: Copyright Information

    The information contained in this document is the proprietary information of Hangzhou Gubei Electronics Technology Co., Ltd. (hereinafter referred to as BroadLink). No portion of this document may be altered or edited in any form or by any means without the prior written consent of BroadLink, the copyright holder.
  • Page 3: Product Overview

    I. Introduction Product Overview What This Product Does Universal Remote makes it easy to control your infrared frequency (IR) & radio frequency (RF) appliances such as TVs, cable TV set-top box (STB), DVDs and ACs from anywhere in the world using the Intelligent Home Center ( ) App.
  • Page 4: Buttons And Indications

    Buttons and Indications Status Indication Flashes quickly (about 2-3 times per configuration mode (the Universal Remote second) is waiting to be Blue Wi-Fi LED added to a network). Flashes fast to slow then goes off Added to Wi-Fi network. (during configuration) Flashes slowly (once per second) No network connection.
  • Page 5: Download And Install App

    II. Setup the ihc App Download and Install App Download the App from the App Store or Google Play by searching “ihc” or “Intelligent Home Center”. Now, connect to a Wi-Fi network with internet access. The App supports iOS 8.0 / Android 4.0 and above. Note: Universal Remote 1) The...
  • Page 6 Setup Your ihc iHome After signing in for the first time, set up your home in . Name your home and select a photo for easy recognition. Set up your Universal Remote Universal Remote Power on your using the USB cable and power adapter provided. If it is the Universal Remote first time that the is being used, the blue Wi-Fi LED will flash rapidly (about 2-...
  • Page 7: Add Device

    App. Devices In the App, select Add device or in , select +.Scan the bar code on the packaging or Universal Remotes, tap Add by categories to select the category and model manually. In select RM pro.
  • Page 8 Universal Remote Check the Wi-Fi name and input its password. Tap Next so that the will be added as a device. The process may take 20-60 seconds, depending on network conditions. Once the configuration is completed, the blue Wi-Fi LED will flash slowly then turn off, choose a room for the device and tap Done.
  • Page 9 designated reset button keyhole, press and hold the reset button for at least 6 seconds until the LED indicator flashes rapidly. Repeat this and hold the reset button until the blue LED indicator Universal Remote flashes slowly at intervals. This indicates that the has entered Wi-Fi AP mode.
  • Page 10 Add Remote Universal Remote If it is the first time that the is in use, the App will automatically show different appliance options for their remote controls to be added. Select the type of appliance you want to control and add its remote. For example, if you want to add a TV (without a set- top box), tap and select your brand of TV.
  • Page 11 Now, turn off your TV using its physical remote control and follow the instructions to start Universal Remote calibrating the physical remote to the App. During the calibration, the will send several control commands to the appliance and all you have to do is confirm the results. When the calibration is done, the App will show a remote control panel with buttons mapped from the physical remote.
  • Page 12 TV on/off before using the STB. Then calibrate the remote of the STB. Ensure you are in the correct room in the App, tap RM pro, then tap +. In , choose the brand of your STB, input the postcode of your location.
  • Page 13 If you cannot find the brand of your appliance in the list, you can use a “User-defined remote” to learn the buttons individually. Tap+, the indicator LED will turn orange, please point your Universal Remote remote to the and press the button on the physical remote to learn. The orange LED will go off, and the button will have been learned successfully.
  • Page 15 If you would like to use voice control for the TV channels, Tap CH in the remote control panel. Input the channel name and channel number, then save it. Note: Only when the account link steps are completed and the device has been discovered in the Alexa App will using voice control for the channels by name be possible.
  • Page 16 III. Setup Alexa Install Alexa Alexa Install the App, then log in using your Amazon account (if you don’t have an account, please create one). Tap ≡ to open a side menu and select Settings. Then tap SET UP A NEW .
  • Page 17 Enable Skill ≡ to open a side menu and select Skills. Search “BroadLink Smart Home” to find the skill. Select the skill to enable it.
  • Page 18 Link BroadLink Account Input your App credentials, tap Sign in. This will link your account to Alexa After linking, tap Done. Discover Device BroadLink Smart Device . Alexa will search for your DISCOVER DEVICES...
  • Page 19 Note: If you are not prompted to , you can also find on the DISCOVER DEVICES DISCOVER DEVICES Alexa App Smart Home page. Say to Alexa Assume you named your TV in App as “TV”, you can use these commands to control it: Alexa, turn on the TV Power control Alexa, turn off the TV...
  • Page 20 Alexa, go forward on the TV Alexa, rewind on the TV Alexa, fast forward on the TV * Requires channel setup before this command is available.
