ASSEMBLY INSTRUCTIONS
Foldable Magnetic
Exercise Bike
Thank you for your purchase of this Harvil product!
We work around the clock and around the globe to ensure that Harvil products
maintain the highest possible quality. However, in the rare instance that your
product is defective or missing parts, contact your retailer to submit parts
requests or warranty claims. Please read the warranty information at the back
of these assembly instructions for further details.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
The information contained in this manual is subject to change without notice.
XB-P / XB-A
1
Advertisement
Table of Contents
Related Manuals for Harvil XB-A
Summary of Contents for Harvil XB-A
- Page 1 Exercise Bike Thank you for your purchase of this Harvil product! We work around the clock and around the globe to ensure that Harvil products maintain the highest possible quality. However, in the rare instance that your product is defective or missing parts, contact your retailer to submit parts requests or warranty claims.
- Page 2 7. Please make sure all the screws and bolts are tightly screwed before using for the rst time. 8. For equipment repair and maintenance, please use the Harvil-provided spare parts only. 9. Please wear clothes and shoes suitable for tness training and exercise every time you use the equipment.
-
Page 3: Kit List
(M6 x 12) Carriage Bolts Cap Nut Semi-Round Lock Nut (M8 x 50) (M8) Head Screw (M8) (M8 x 35) Semi-Round Spring Washer Flat Washer Outer Hexagonal Head Screw (M8) (M8) Spanner (M8 x 45) (13-15) Socket Spanner (L5) XB-P / XB-A... -
Page 4: Accessories List
Foot Tube M8*50 Carriage Screw Pedal (Left) Main Frame Ø 6.2 Flat Washer M6*12 Semi-Round Head Screw Ø 6.2 Arc Washer Armrest of Main Frame Frame Regulating Lever Regulating Rod Fixed Nut Spring Gasket M8*45 Carriage Bolts XB-P / XB-A... -
Page 5: Exploded View
EXPLODED VIEW XB-P / XB-A... - Page 6 Flat Washer (M8) M8 Lock Nut (M8) Step 2 To align hole site of Seat (9) & Seat Holder (10), use Ø 8.5 Flat Washer (7), M8 Lock Nut (6) to connect, then tighten M8 Lock Nut (12). XB-P / XB-A...
- Page 7 (M8) Semi-Round Head Screw (M8 x 45) Step 4 Use (25) and align with the back of a chair of 5 holes, Bolt with (24) connect Ø 8.5 Spring Washer, tighten M8 x 50 Ball Stud (25) XB-P / XB-A...
- Page 8 Step 6 To align hole site of Back Armrest (4) & Back (5), Use M8*40 Semi-Round Head Screw (3), Back Stator (2), Ø8.5 Arc Washer (8), M8 Lock Nut (7) to connect and tighten M8 Lock Nut (7). XB-P / XB-A...
- Page 9 Semi-Round Head Screw (19). Finally, connect wire between monitor & frame. Step 8 Position the Pedal (12) and Crank of Main Frame (17) correctly, then tighten. Note: Distinguish position of right and left. Same method to assemble Right Pedal (16). XB-P / XB-A...
-
Page 10: Training Instruction
You must stay in the target zone for at least 12 minutes. Some people train for 15-20 minutes. XB-P / XB-A... -
Page 11: Day Limited Warranty
Harvil reserves the right to make substitutions to warranty claims if parts are unavailable or obsolete. Harvil shall not be liable for loss of use of the product or other consequential or incidental costs, expenses or damages incurred by the consumer of any other use. The user assumes all risk of injury resulting from the use of this product.
