EVENT TENT
HUMANITY TENT
DE
AUFBAUANLEITUNG
EN
ASSEMBLY INSTRUCTIONS
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Event and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GYBE Event

  • Page 1 EVENT TENT HUMANITY TENT AUFBAUANLEITUNG ASSEMBLY INSTRUCTIONS...
  • Page 2: Table Of Contents

    Gebrauchs- und Gefahrenhinweise ..3 Aufbau Event Tent ..... . . 4 Aufbau Humanity Tent ....6 Side Panels .
  • Page 3: Lieferumfang

    Spülmittel gereinigt werden. Agieren Sie bei bedruckten Seitenteilen besonders vorsichtig. Prüfen Sie gegebenenfalls an einer unauffälligen Stelle, ob der Reiniger die Oberfläche angreift. ACHTUNG Die Zeltmaterialien sind wasserabweisend und brandhemmend beschichtet. Starkes Reiben oder lösungsmittelhaltige Reiniger zerstören diese Beschichtungen! GYBE übernimmt keinerlei Haftung bei unsachgemäßer Behandlung der GYBE Produkte.
  • Page 4 AUFBAU EVENT TENT Entnehmen Sie das Zelt dem Transport- Entrollen Sie nun den durchgehenden Teil der rucksack. Schlagen Sie das zusammen- Stützstruktur vollständig zu beiden Seiten. gerollte Zelt in der Mitte ein Stück weit auf. Schließen Sie sämtliche Auslassventile (3a) und eines der Einlassventile am unteren Ende der Strut.
  • Page 5: Aufbau Event Tent

    AUFBAU EVENT TENT Die Strut nimmt durch die einströmende Luft Befüllen Sie nun die ausgerollte Strut durch selbstständig ihre endgültige Form an. das Einlassventil am Fußende. Es befindet Rollen Sie nun die verbliebene Strut nach sich an der Unterseite. vorne hin aus.
  • Page 6 AUFBAU HUMANITY TENT Entnehmen Sie das Zelt dem Transport- Entrollen Sie nun das Zelt vollständig zu rucksack. Schlagen Sie das zusammen- allen Seiten. gerollte Zelt in der Mitte ein Stück weit auf. Schließen Sie sämtliche Auslassventile (3a). Drehen Sie das Einlassventil (4a) so ein, dass es seitlich zugänglich wird.
  • Page 7: Aufbau Humanity Tent

    AUFBAU HUMANITY TENT Schließen Sie den Druckluftschlauch Ihrer Durch unterstützendes Anheben der Zeltmitte Druckluftzufuhr am Einlassventil an. bringen Sie das Zelt in die endgültige Form. Abhängig von der Strömungsgeschwindigkeit beginnt sich das Zelt rasch aufzurichten. Achten Sie darauf, dass beim Befüllen der Luft- druck der Strut nicht über 6 psi / 0,4 bar liegt.
  • Page 8: Side Panels

    ANBRINGEN DER SIDE PANELS Das Side Panel parallel zum Zelt auslegen. Beim Hochziehen des Reißverschlusses Der Startpunkt des Reißverschlusses befindet darauf achten, dass der vordere Teil des Side sich am linken Rand jedes Side Panels. Panels mit der Hand geführt wird (2a), um ein einwandfreies Aufziehen zu gewährleisten.
  • Page 9 ANBRINGEN DER WASSER- / SANDSÄCKE Der befüllte Wasser- bzw. Sandsack wird auf Den Zeltfuß bündig auf den Wasser- oder den Boden gestellt. Achten Sie darauf, dass der Sandsack stellen. Dabei die Soft Shackle nach Reißverschluss des Sandsacks, bzw. die Ventile oben halten und jeweils ein Ende durch die des Wassersacks, nach oben zeigen.
  • Page 10 ANBRINGEN DER FUSION PANELS Zum Anbringen der Fusion Panels beide Zelte Das Fusion Panel parallel zum Boden auslegen. nebeneinander mit etwa 2 Metern Abstand Der Startpunkt des Reißverschlusses befindet platzieren. sich am linken Rand jedes Fusion Panels. Dabei sollte eines der Zelte bereits fest mit Der zeltseitige Startpunkt des Reißverschlusses dem Untergrund verbunden sein.
  • Page 11: Fusion Panels

    ANBRINGEN DER SPANNSEILE Befestigen Sie die Zeltfüße des zweiten Zeltes am Boden mit Hilfe der Wasser- oder Sandsäcke. Für ein faltenfreies Aufstellen des Fusion Panels müssen Sie etwas Spannung zwischen den Zelten aufbauen. Hierfür am besten die Zelte mit Hilfe der Abspannseile spannen. ANBRINGEN DER SPANNSEILE Um das Zelt ausreichend gegen Windlasten Die größtmögliche Stabilität wird erreicht,...
  • Page 12 ABBAU EVENT TENT / HUMANITY TENT Öffnen Sie den Klettverschluss eines der unteren Das Auslassventil (1a) an der Ventillasche öffnen. Auslassventile (1a), so dass die Ventillasche Die Strut wird daraufhin in sich zusammenfallen. greifbar wird. Verfahren Sie so mit allen drei Struts, bis das Zelt vollständig zusammengefallen ist.
  • Page 13: Abbau Event Tent / Humanity Tent

    ABBAU EVENT TENT / HUMANITY TENT Verfahren Sie auf dieselbe Weise mit allen vier Zeltfüßen. Schlagen Sie das Zelt in der Mitte ein und verstauen es im Transportrucksack. konzeption / gestaltung Markus Günther und Anne Wenkel www.formzoo.com © Berlin 2011...
  • Page 15 EVENT TENT HUMANITY TENT ASSEMBLY INSTRUCTIONS...
  • Page 16 Instructions for use / Safety warnings . . 15 Setting up your Event Tent ....16 Setting up your Humanity Tent ..18 Side Panels .
  • Page 17 In case of doubt, check on an inconspicuous part if a cleaning agent is aggressive to the tent surface. WARNING Tent materials are water resistant and flame retardant because of special coatings. Harsh scrubbing or cleaning agent with solvents destroy these coatings! GYBE accepts no liability for mal- or non-function of improperly handled GYBE products.
  • Page 18 SETTING UP YOUR EVENT TENT Remove the tent from the transport Now fully unroll in both directions the backpack. Unfold the rolled-up tent just full-length part of the inflatable structure, once in the middle. which has just been revealed. Close all deflation valves (3a) and one of the inflation valves, which you will find on the underside of the strut.
  • Page 19 SETTING UP YOUR EVENT TENT The strut takes its final form on its own Fill the unrolled strut using the inflation once the air is rushing in. Roll out the valve at the end of the foot. remaining strut as indicated in the illustration.
  • Page 20 SETTING UP YOUR HUMANITY TENT Remove your tent from the transport Fully unroll all parts of the support structure backpack. Unfold the rolled-up tent just in every direction. once in the middle. Close all deflation valves (3a). Turn the inflation valve (4a) so that it is accessible.
  • Page 21 SETTING UP YOUR HUMANITY TENT Attach the compressed air hose to the With some gentle lifting, the tent will be inflation valve. guided to its final form. Regardless of the speed of inflation, the tent will begin to stand up by itself. Be sure not to let the internal pressure of the strut exceed 6 psi (0.4 bar).
  • Page 22 ATTACHING SIDE PANELS Spread out the side panel parallel to the tent. While pulling the zipper up, please be sure The starting point of the zipper is always that the leading edge of the side panel is located on the left edge of a side panel. guided by hand (2a), in order to ensure a problem-free zip-up.
  • Page 23 ATTACHING WATER- / SANDBAGS The filled water- or sandbags are placed on Place the tent foot roundly on the water- or the ground or floor. Make sure that the zipper sandbag. While doing so, pull the soft shackle of the sandbag, or the valve of the waterbag, upward and through the eyelet on the tent is facing up.
  • Page 24 ATTACHING FUSION PANELS For attaching the Fusion Panels, two tents Lay out the Fusion Panel next to the tents. The are to be placed next to each other at about starting point of the zipper is always located on 6.5 feet distance. the left edge of a Fusion Panel.
  • Page 25 ATTACHING GUY ROPES Fasten the tent feet of the second tent to the ground using the water- or sandbags. Tip: If you want to set up the Fusion Panel without any wrinkles, you need to increase the tension between the tents, perhaps using the guy ropes provided.
  • Page 26 TAKING DOWN YOUR EVENT TENT / HUMANITY TENT For taking the tent down, open the velcro strap Open the deflation valve (1a). at one of the lower release valves (1a), so that The strut will immediately begin to deflate. the valve plug is accessible.
  • Page 27 TAKING DOWN YOUR EVENT TENT / HUMANITY TENT Repeat this procedure for all 4 feet. Afterwards, fold the tent in the middle and stow in the backpack. concept / design Markus Günther and Anne Wenkel www.formzoo.com © Berlin 2011...
  • Page 28 WWW.GYBE-DESIGN.COM...
