Safety Instruction
Installation
To get a better view, please use this projector in a semi dark room.
Please use this projector carefully, dropping it may cause damaged parts or result in
a blurred image or abnormal displaying.
Power
Be careful while using the power cord, avoid excessive bending. Damaging the power cable
may cause electric shock and fire.
It is better to unplug the power cord after poweringoff.
Cleaning
Unplug the power cable first.
Clean the shell regularly with a damp cloth, neutral detergent can be used.
Please use a glasses cloth or lens paper, not to scratch the lens.
Please clean projector's vents and speakers regularly by banister brush, or the vents will be blocked.
High temperature attention
When projection is finished, the exhaust port will be very hot, may cause burning.
While projecting, please do not look the lens directly or it may hurt your eyes.
Warning tips
Do not disassemble the projector, which may cause electric shock and void the warranty.
Please do not put any liquids or weight on the projector.
To assure the stability of heat exhaust, please open the height bracket in the bottom before starting.
Instrucation Manual
Advertisement
Table of Contents
Related Manuals for Guangzhou Rigal Electronics RD-601
Summary of Contents for Guangzhou Rigal Electronics RD-601
- Page 1 Safety Instruction Installation To get a better view, please use this projector in a semi dark room. Instrucation Manual Please use this projector carefully, dropping it may cause damaged parts or result in a blurred image or abnormal displaying. Power Be careful while using the power cord, avoid excessive bending.
-
Page 2: Projector Overview
1.Projector Overview (1) 1.Projection lens 2.Front IR remote control sensor 3.Ventilation holes 4.Power on/off 5.U disk/mouse port 6.TF card reader 8.Adapter connection port 9.U disk/mouse port 10.HDMI input port 11.Computer/video port 12.Switch Warning Tip: computer/video port need to match the especial cable with the projector( More details please inquiry the distributor) . -
Page 3: Specifications
1.Projector Overview (2) 2. Specifications Display chip: 0.3'' DMD RGB-LED Lens: High light transmittance coating glasses Optical Brightness uniformity:98% Brightness:1600 lumens(international standard 350 Ansi Lumens) parameters Contrast ratio:1000:1 NTSC: ≥120% 1.Height bracket Resolution: 1 280*800 3D display: Yes 2.Air intake hole Projection size:20-200 inch 3.Stend hole(M5) Throw ratio: 1.47:1... - Page 4 3.Remote Control 4.Powering On/Off 1.ON: Plug the DC terminal of power adaptor to DC-IN terminal of projector, adjust the master switch on the right to “ON”, while the red indicator light , press the power key. 1.Power 2.OFF: Press the power key while the projector is working normally, if the indicator light turn from green 2.Arrow keys to red, the projector is off.
-
Page 5: How To Focus
6.How to use the USB2.0/3.0 interface ? 5.How to Focus? USB2.0/3.0 interfaces could be connected with mouse/keyboard; it could read the video, Adjust the focus button up or down lightly until the images clear. audio, picture, office document;it also could be installed APK applications. Support Format Picture Format JPG/JPEG/GIF/BMP/PNG etc... - Page 6 7.How to connect WiFi? 8.How to connect Bluetooth? WiFi connection steps: For the first time to connect the Bluetooth devices, (such as Bluetooth Speaker/ Headset),you need to match with projector Please press the main interface on the remote control, the main screen appears, Please press the “System Setting”, find the “Network Setting”...
-
Page 7: Surfing The Net
10.File Management 9. Surfing the Net Please press the main interface on the remote control, the main screen appears , Please press the main interface on the remote control, the main screen appears , and press “My Media”, find the “Web Browser”. The default website is Google, if and press “My Media”... -
Page 8: Local Play
11.Local Play 12.APK Install Instructions Put the U disk with audio, video and text into the USB2.0 or USB3.0 interface, Please press the main interface on the remote control, the main screen appears, press the main interface on the remote control, the main screen appears, and and press the “All applications”, find the “... - Page 9 13. Wireless Display for Android 14.Wireless Display for ios 1. Please press the main interface on the remote control, the main screen appears, 1. Please press the main interface on the remote control, the main screen appears, and press the “My Media”, find the “Miracast”. and press the”...
-
Page 10: How To Charge
16.How to Charge 15.3D Function 1. 3D video play: 1. To charge when projector is off: when the projector is connected with the power adapter, put When playing video, the video sources for the 3D format, it will recognize the 3D the switch in the “OFF”... - Page 11 FCC ID: 2AK43RD-601 FCC statement This device complies with Part 15 of the FCC Rules: Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference that is received, including any interfer ence that may cause undesired operation.
