- Page 1 HURRICANE II FAN Operating Instructions P/N 100160 (110V) P/N 100165 (230V...
- Page 2 And finally, we believe you will enjoy many years of dependable, trouble-free service if you properly install and maintain this powerful piece of machinery called the Hurricane II Fan CITC 2100 196 St. S.W., Ste. 138 Lynnwood, WA 98036 (888) 786-CITC www.citcfx.com...
-
Page 3: Table Of Contents
Contents 1. Set of Equipment Supplied 2. Accessories and Parts 3. Description 4. Safety Instructions 5. Operating the Hurricane II Fan 5.1 Unpacking the Hurricane II Fan 5.2 Electrical Power Requirements 5.3 Running the Hurricane II Fan 5.4 Transporting the Hurricane II Fan 5.5 Hanging the Hurricane II Fan 5.6 Optional Universal DMX Control 5.7 Troubleshooting... - Page 4 1. Set of Equipment Supplied 1 Hurricane II Fan 1 Bracket with hardware (P/N 600440) Operating Instructions Booklet 2. Accessories and Parts C-Clamp w/Baby Spud and Safety Cable (P/N 250140) Universal DMX for on/off control only (P/N 250041) ...
-
Page 5: Safety Instructions
4. Safety Instructions WARNING: Read and understand all labels and operating instructions before attempting installation. o RISK OF ELECTRICAL SHOCK- This fan is supplied with a grounding conductor. Improper connection of the equipment-grounding conductor can result in a risk of electric shock. -
Page 6: Running The Hurricane Ii Fan
Sometimes in shipping the fan may be damaged due to mishandling or jarring of the unit. Contact your shipper and CITC if damage has occurred in transport. 2. Spin the entire fan to the position you want the air to flow, tightening the lock- down nut on the spindle to stop it from moving. -
Page 7: Troubleshooting
DMX doesn’t work: turn on control knob on fan to desired speed setting. Fan rubs when turning: call CITC for instructions. Do not remove cover. Motor jumps or is unsteady: check extension cord for low gauge. Turn off any other loads sharing the same circuit or test in dedicated outlet. -
Page 8: Service And Maintenance
Inspect the cord for damage before each use. Never operate with extension cords that are under 12 awg. Technical Data Hurricane II Fan P/N 100160 (230V P/N 100165) Weight 49lbs (19.3 kg) Size (with bracket) 17 3/4” x 19 1/2” x 19 1/2”... - Page 9 4. Freight costs to CITC when under the limited warranty services are the responsibility of the customer. CITC will pay freight upon return.
- Page 10 If you should send the unit for service, obtain your RMA# first by calling CITC. Obtain your RMA # by calling CITC. Payment arrangements for repair must be made before receiving RMA # in case unit is not covered under Limited Warranty.
