15-AMP ELECTRIC SNOW THROWER

22-INCH | LED HEADLIGHTS | 180° ADJUSTABLE CHUTE

OPERATOR'S MANUAL

Model MTS-22SB

IMPORTANT!

Safety Instructions

All Operators Must Read These

Instructions Before Use

Any electrical appliance can be dangerous if used incorrectly.

Some of the safety precautions given in this manual apply

generally to many appliances. Other warnings are specific

to the use of this snow thrower. Keep this manual for future

reference.

General Safety WARNINGS!

You and any other operator of this snow thrower must read,

understand, and follow these instructions in their entirety, and

should reread them at the start of each snow season. Failure

to follow these instructions may result in ELECTRIC SHOCK,

FIRE, and/or serious PERSONAL INJURY.

Notice the personal safety alert symbol

manual to draw your attention to a WARNING given along

with the particular operating instruction. This means that

the operation requires special ATTENTION, CAUTION, and

AWARENESS.

1. Keep work area clean and well lit. Cluttered, dark areas

invite accidents.

2. Do not operate the snow thrower in an explosive

atmosphere, such as in the presence of flammable

liquids, gases, or dust. Electrical appliances create sparks

that may ignite the dust or fumes.

3. Keep children, pets, and bystanders away from the

work area. Be aware that the normal noise of the

machine when turned on may make it difficult for you to

hear approaching people. Spectators should wear safety

glasses and be kept a safe distance away from the work

area. Do not let spectators touch the snow thrower or the

extension cord.

4. Electrical plugs must match the outlet. Never modify

the plug in any way. Do not use any adapter plugs with

grounded appliances. Unmodified plugs and matching

outlets will reduce the risk of electric shock.

5. Avoid body contact with earthed or grounded surfaces

(i.e. upper and lower water pipes, radiators, ranges,

refrigerators, microwave ovens, and outer frames of

heating equipment). Take necessary precautions to avoid

, LLC

6. Do not abuse the cord. Keep the cord away from heat,

7. Replace or properly repair damaged cords. If the cord

8. Contact with water while operating the snow thrower

used in this

10. Turn off the power switch and disconnect the power

11. If you find the main power cable or the extension cable

12. When replacing any parts, you must strictly observe

13. Do not move or transport the snow thrower when the

14. If, during use, you notice that the unit runs unstably

electric shock. There is an increased risk of electric shock

if your body is earthed or grounded.

oil, sharp edges, or moving parts. Never carry the snow

thrower by its cord or yank the cord to disconnect it from

the electrical outlet. Damaged or entangled cords increase

the risk of electric shock.

becomes damaged in any manner while plugged into the

wall receptacle, immediately pull the extension cord plug

from the receptacle.

can result in electric shock and serious bodily injury.

Do not use the snow thrower in damp or wet locations or

expose to rain. Do not handle the plug or the appliance

with wet hands or while standing in water.

WARNING – Use outdoor extension cords marked

SW-A, SOW-A, STW-A, STOW-A, SJW-A, SJOW-A,

SJTW-A, or SJTOW-A. These cords are rated for outdoor

use and reduce the risk of electric shock.

cable before making any adjustments to the unit and

before inspecting, servicing, changing accessories, or

cleaning the snow thrower. Follow the same procedure

if any other dangerous conditions are present during

operation. Any adjustments to the unit should be

performed after revolving parts inside the snow thrower

stop completely. Such preventative safety measures

reduce the risk of starting the power tool accidentally.

damaged, please pull out the plug from the socket and

disconnect the power immediately. Repair the cable or

replace it if necessary.

the instructions and procedures described in this

operator's manual. Special care should be paid to any

rubber parts, since these parts may increase the engine

load and decrease its mechanical power if damaged.

plug is connected to the power socket and the switch

is turned on.

or hear abnormal sounds from the motor, stop the

machine, disconnect the power immediately and

contact an authorized Snow Joe

center.

Form No. SJ-MTS-22SB-880E-M

+ Sun Joe

service

SAVE THESE INSTRUCTIONS

Table of Contents

Need help?

Do you have a question about the MTS-22SB and is the answer not in the manual?

Questions and answers

Summary of Contents for Martha Stewart MTS-22SB

Page 1 15-AMP ELECTRIC SNOW THROWER 22-INCH | LED HEADLIGHTS | 180° ADJUSTABLE CHUTE OPERATOR’S MANUAL Model MTS-22SB Form No. SJ-MTS-22SB-880E-M IMPORTANT! electric shock. There is an increased risk of electric shock if your body is earthed or grounded. Safety Instructions 6. Do not abuse the cord. Keep the cord away from heat, oil, sharp edges, or moving parts.
Page 2: Electrical Safety
Electrical Safety WARNING 1. Ground fault circuit interrupter (GFCI) protection should be provided on the circuit(s) or outlet(s) to be used for the snow thrower. Receptacles are available having Electric shock may cause SEVERE INJURY or built-in GFCI protection and may be used for this DEATH.
Page 3: Personal Safety
Personal Safety Safety Instructions for Walk-Behind Snow Throwers 1. Stay alert – Watch what you are doing and use common sense when operating the snow thrower. Do not use the • Read the operator’s manual carefully – Learn your machine when tired, ill, or under the influence of drugs, snow thrower’s applications and limitations as well as the alcohol, or medication.
Page 4 • When work is completed – Disconnect the snow thrower from the power source when not in use, when changing accessories, and before performing any maintenance function. • Store safely – Store the snow thrower indoors in a dry area between uses. Keep it in a locked area, where children and unauthorized users cannot gain access.
Page 5: Safety Symbols
Safety Symbols The following table describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbols Descriptions Symbols Descriptions READ THE OPERATOR'S MANUAL(S) – Read, understand, Disconnect the plug before conducting maintenance or when it is and follow all instructions in the...
Page 6: Technical Data
Know Your Electric Snow Thrower Read the owner’s manual and safety rules carefully before operating your electric snow thrower. Compare the illustration below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference.
Page 7: Carton Contents
Unpacking Handle Frame Assembly 1. For easy assembly, the unit comes complete with most parts already connected. To complete the handle Carton Contents: assembly, simply pull the middle frame back and pull the • Electric snow thrower with middle frame and upper frame upper frame up (Fig.
Page 8: Discharge Chute Assembly
Chute Crank Assembly Fig. 3 1. Slide the upper chute crank through the rubber ring located on the middle frame (Fig. 6). Upper Fig. 6 frame Upper chute crank Knob + T-bolt Rubber ring Middle frame Discharge Chute Assembly 1. Loosen the knob to lift the chute deflector (Fig. 4). 2.
Page 9: Operation
4. Align the screw holes and tighten the thumbscrew by hand (Fig. 9). Fig. 11 Fig. 9 Thumbscrew WARNING! Damaged electrical cords present risk of fire, electrical shock, and serious bodily injury. Before operating the snow thrower, carefully examine the electrical cord. If the cord is damaged, do not use the snow Operation thrower.
Page 10 Headlights 6. While moving the snow thrower, do not drag the power cable violently or roughly. The snow thrower should move The snow thrower is equipped with 2 headlights that can be within the range that the cable can reach. used to illuminate the forward path in the dark.
Page 11: General Maintenance Tips
Fig. 14 Fig. 16 Chute crank Deflector knob WARNING! Make sure that the chute deflector snaps Discharge chute and locks completely onto the discharge chute. An opening between the discharge chute and the chute deflector may allow foreign objects to be picked up by the snow thrower and thrown in the direction of the operator causing serious boldly injury.
Page 12 5. Do not use detergent or solvents as these could cause irreparable damage to the snow thrower. Chemicals can Fig. 19 destroy the plastic parts. Metal frame 6. To protect the snow thrower from corrosion when storing for long periods, lightly oil the metal parts. 7.
Page 13 Replacing the Belt + Pulley Fig. 24 NOTE: Determine the left and right hand side of the snow thrower by standing behind the unit in the normal operating position. Screw 1. Remove the screws from the left panel of the snow thrower and remove the left panel (Fig.
Page 14: Automatic Reset
® thrower cover (Model SJCVR-24) for added protection. Visit snowjoe.com to purchase the cover online. Service + Support If your Martha Stewart MTS-SB22 electric snow thrower requires service or maintenance, please call 1-866-SNOWJOE (1-866-766-9563) for assistance. Model + Serial Numbers...
Page 15: Optional Accessories
Optional Accessories WARNING! ALWAYS use only authorized Snow Joe + Sun Joe replacement parts and accessories. NEVER use ® ® replacement parts or accessories that are not intended for use with this electric snow thrower. Contact Snow Joe + Sun Joe ®...
Page 16 NOTES...
Page 17 NOTES...
Page 18 NOTES...
Page 19 SNOW JOE + SUN JOE CUSTOMER PROMISE ® ® ABOVE ALL ELSE, Snow Joe + Sun Joe are dedicated to you, our customer. We strive to make your experience as pleasant ® ® as possible. Unfortunately, there are times when a product does not work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us.
Page 20 WARNING! This product or its power cord contains chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For more information go to www.P65Warnings.ca.gov. WARNING! Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known [to the State of California] to cause cancer, birth defects, or other reproductive harm.
