PowerOak PS10B Operating Manual

Portable power station
Hide thumbs Also See for PS10B:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
Operating Manual
PS10B
Many thanks for buying this Portable Power Station. In order to use this product safely,
please read this manual carefully; and please safekeep this manual (including letter of guarantee) so
that you can read it any time you need. Please refer and keep the additional detail file together with
this manual if it's offered.
Disobeying safety considerations may cause human injury such as fire hazard or
Note:
electric shock, etc.
Portable Power Station

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS10B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PowerOak PS10B

Summary of Contents for PowerOak PS10B

  • Page 1 Operating Manual Portable Power Station PS10B Many thanks for buying this Portable Power Station. In order to use this product safely, please read this manual carefully; and please safekeep this manual (including letter of guarantee) so that you can read it any time you need. Please refer and keep the additional detail file together with this manual if it’s offered.

  • Page 2: Table Of Contents

    Contents Packing Confirmation Preface Safety Considerations Name of Parts Lifting &Handling AC Charging Solar Charging AC Output Estimated Backup Time Charge&Discharge Simultaneously Storage Long Using Life of Polymer Lithium Battery Recycle of Lithium Ion Battery Malfunction & Maintenance Product Specification Parameters Warranty&...

  • Page 3: Packing Confirmation

    Packing Confirmation Solar Input Plug AC input Plug Product specifications and guarantee...

  • Page 4: Preface

    2.Preface Please pay attention to the following content when reading the operating instruction. ● The change of this manual won’t be informed to users in future. ● The change of product appearance or specifications won’t be informed to users in future. ● We have tried our best to make this manual.

  • Page 5: Safety Considerations

    Circle means the behavior that is required during the operation of the product. The specific required behavior is illustrated or described in the picture. For safe use of PS10B, we pasted notice label. Please use the product with reference to the manual content and label.
  • Page 6 Dangerous Do not touch this product and connector socket when your hands are wet. It may cause electric shock. Do not connect the metal to AC input and output. It may cause electric shock, fever, fire, etc Do not wipe when the liquid inside of this product gets into your eyes. Please rinse and seek medical advice urgently.
  • Page 7 Warning Please keep the place clean where you use or store the product. It may cause short circuit, smoke or fire accident if powdered or small metal object contact the terminals. CAUTION Please check the products before using. When you found the products have damage, rupture, cracks, fever or other abnormity, please stop using it and contact selling shop or our customer service.
  • Page 8 Caution For unusual conditions such as rusting, rare smell, heating, please stop using the product immediately and contact the agent shop or our customer service. This product is very heavy, please mind when operation. It may cause lumbar pain or hurt. Please do not make the label stuck to the product dirty or fall.

  • Page 9: Name Of Parts

    4. Name of Parts Handle DC Output On/Off AC Output Outlet Power On/Off Button AC Output Indicator AC Input Socket AC Output On/Off AC Input Indicator DC12V Output Outlet Solar Input Indicator Capacity Indicator Solar Input Socket DC Output Indicator...

  • Page 10: Lifting &Handling

    5.Lifting & Handing 1. Pull the handle up 2.Moving by carry handle Notice Notice Keep the product away from anything Hold the handle steady. when moving. 3.Put at stationary place Notice Please put the product at stationary place. And indicators can be saw easier. 4.Do not place it where unsteady...

  • Page 11: Ac Charging

    SolarCharging Solar in AC IN 3.Connect AC cable to wall AC outlet Please make sure AC cable plug is inserted into standard AC outlet. (PS10B-P :100V/110V/120V;PS10B-P :220V/230V/240V) Capacity indicator flash every 2 seconds, AC input indicator lights up. Notice Please charge under temperature 0~40°C 4.After fully charged: 4 green indicators lights up.

  • Page 12: Solar Charging

    7.Solar Charging 1.Special solar input connector 1# Red wire: positive 2# Black wire: negative 2.Connect the solar panel to solar input connector Red wire connects to positive of solar panel and black wire connects to negative of solar panel. (attention: solar panel voltage requires DC18V to DC54V) 3.Press power on/off button: solar charging indicator lights up and also battery capacity indicators 4.Plug the solar input connector into solar charging input socket Capacity indicator twinkles once per second and also solar input indicator lights up.
  • Page 13 6. Capacity Indicator Indicator State Indication Power off or no electric inside 4 indicators off 1 green on Twinkle per second, charging, SOC 0%~25% 75 100 2 green on Twinkle per second, charging, SOC 25%~50% 75 100 3 green on Twinkle per second, charging, SOC 50%~75% 75 100 Twinkle per second, charging, SOC 75%~100%...

  • Page 14: Ac Output

    8.AC Output 1.Press the on/off button AC Output DC 12V AC ON Capacity DC ON AC OUT DC OUT Please turn the power off for long period no-operation status 2.Match the frequency of the electronic appliance (50Hz or 60Hz) Note Standard frequency: 50Hz.
  • Page 15 4.Using of electrical appliances Make sure electric appliances is powered off before using. Confirm the battery capacity according to indicator 1-4 lights during the processing. Usage time is varied due to the ambient temperature or change of the built-in li-ion battery . Connect To It’s normal if the product heats up during output.
  • Page 16 6.Discharging SOC Indicators Indicator State Indication 4 green on Discharging, SOC 75～100% 75 100 3 green on Discharging, SOC 50～75% 75 100 2 green on Discharging, SOC25～50% 75 100 Discharging, SOC 0～25% 1 green on 75 100 Green Output 50Hz AC output indicator Output 60Hz...

  • Page 17: Estimated Backup Time

    15.5 hours hours hours 430Wh 80Wh 90Wh Model PS10B back up time calculation Power Consumption ≈ 1400 Hours Note Above data is just for reference. We collect the approx values when we develop it with ambient temperature of 25°C and full charged, these values may vary regarding to different electrical appliance manufacturer or other else.

  • Page 18: Charge&Discharge Simultaneously

    10.Function of Charging & Discharging Simultaneously PS10B power station can be discharged while charging. In the condition of charging, it can supply power to electric appliance at the same time. Connect To Electric Device...

  • Page 19: Storage

    11.Storage 1.Full charge Fully charge the power station before long term storage. Fully charge the power bank at least once a year. Note please refer to the content in page 11 2.Shut down all the buttons After fully charged, pull out AC input connector from AC input socket, shut down on/off buttons AC Output DC 12V AC ON...

  • Page 20: Long Using Life Of Polymer Lithium Battery

    Otherwise, it shortens cycle life of lithium battery. Don’t discharge battery when SOC is 0 PS10B cuts off discharging automatically. But electric device connecting to AC output outlet shortens cycle life of lithium battery. Shut it down when no need to use Wasting the electricity inside the battery is another reason of less cycle life of lithium battery.

  • Page 21: Recycle Of Lithium Ion Battery

    13.Recycle of Lithium Ion Battery. After use, complete lithium-ion batteries can be recycled . Please do not disassemble, be sure to contact the retail store or our “customer service center”...

  • Page 22: Malfunction & Maintenance

    14.Malfunction & Maintenance For the occasions that the following "corresponding disposal"is not available, please stop using the product immediately and contact the retail store or "customer service center" of our company. Corresponding disposal Phenomenon Status Main reason AC wire is not connected No enough power or not connected well supply...

  • Page 23: Product Specification Parameters

    15.Specification Modle PS10B-P1 PS10B-P2 Battery Capacity 7 00Wh 1200Wh 1500Wh 700 Wh 1200Wh 1500Wh Output 500VA Rated Output Power 750VA 10s Peak Output Output Voltage 100V/110V/120Vac 200V/230V/240Vac 50Hz/60Hz Output Frequency 120%<load<130% @10min; 130%<load<150% @10s Overload Ability Max Efficiency 90% (>70% load)
  • Page 24 FREE REPAIR REGULATIONS 1.For product failure caused by manufacturing reasons, please bring the guarantee and vouchers of purchase date (invoices, etc.) to retail store. It is free to repair or replace the product during the 2 year warranty period under normal use. In addition, customer should bear the necessary shipping costs when needed.

This manual is also suitable for:

Ps10b-p1Ps10b-p2
