Wander Control Systems, Inc.

EscortR

Run wires from J3 Pins 1 & 2 on the Platinum 3, Platinum 3B, or Sentry control unit to
the EscortR remote access panel.

FAQs

How do I change the code on KP-1 and KP-2?
1) Pull the circuit board free from the keypad. On the board you will see five
wires and a plastic strip with holes that are labeled ABCDE and 0123456789.
2) Escort code used on KP-1 or KP-2 must match code used on Platinum 3,
Platinum 3B, or Sentry controller.
3) Connect wire from hole A to appropriate hole for first numeral of escort code.
4) Repeat with wire from hole B to appropriate hole for second numeral of escort
code. Repeat with wires C, D, & E as necessary.
Can I use repeat digits in my code? No, unique digits only (i.e., 12345). Do not use
the same numeral twice in your escort code.
your code.
WCSI Keypad Installation Manual Page 6 of 6
If you change the escort code on the main door
controller (Platinum 3, Platinum 3B, or Sentry)
you must also change the escort code on the
opposite side keypad (KP-1 or KP-2).
Wander Control Systems, Inc.
210 Richlandtown Pike
Quakertown, PA 18951
Telephone 215-538-1983
After Hours 407-446-0055
www.wandercontrol.com
Do NOT use the numeral 9 in
6
