Mounting

1) The remote access panel which has been chosen for this location is to be
mounted beside the door on the opposite side of the wall from the door
controller (Platinum 3, Platinum 3B, or Sentry).
2) Mount the remote access panel close to the door in a convenient location at
approximately 4 ½ feet from the floor. Mark a precise location for mounting
and drill through the wall.
(If necessary, wires may be run through a Wiremold channel mounted
vertically, but an access hole must be drilled through the top of the surface
mount box.)
4) Screw surface mount box (backbox) to the wall. (The backbox must be
securely attached to the wall).
5) After the backbox has been securely fastened to the wall you may pull the
wires to the box from the door controller.

Set-up Connections

KP-1 & KP-2
There are 3 wires used on the KP-1 & KP-2. The colors and functions are as follows:
- Positive Power (6 – 12VDC)
Red
Black - Common Ground
Green - Output
Connect the three wires from the controller to the KP-1 or KP-2 remote access panels
as follows:
KP-1 & KP-2
Red
Black
Green
Platinum 3, Platinum 3B, or Sentry controller J3 Pin 1 is NOT
used in connecting a remote access panel.
WCSI Keypad Installation Manual Page 5 of 6
We recommended that you use 18 - 4 stranded wire
because you need to run three wires from the
Platinum 3, Platinum 3B or Sentry control unit out to
the KP-1or KP-2 remote access panel.
Platinum 3, Platinum 3B or Sentry Controllers
J5 – Pin 1 – +12VDC
J5 – Pin 2 – Ground
J3 – Pin 2 – Escort Trigger In
