Summary of Contents for Craig CRT713
-
Page 2: Fcc Information
FCC INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide residential protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not Installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Location Of Controls
LOCATION OF CONTROLS: Main Unit: Blades Battery Door Power ON-OFF Switch Connection Jack of Camera Built-in Battery DC IN Jack of Main Unit... - Page 4 Remote Control: Power On-Off Button Left Joystick Right Joystick H (High Speed ) Button L (Low Speed) Button Headless Button Forward/Backward Trimmer Left/Right Trimmer 3D Rolling 1 Button 10. 3D Rolling 2 Button...
-
Page 5: Battery Recharging
PREPARATIONS: Battery Recharging: The unit has a built-in DC 3.7V Li-ion rechargeable battery, recharge it before first time use or when it is consumed as follows: Open the battery door by slide it out then lift up. Take out the battery from the battery compartment. Connected the small jack from the supplied USB Charging Cable to the connection plug of the battery. - Page 6 Insert the connection plug from the battery to the DC IN Jack on the unit as the figure below: Replace the battery into the battery compartment then close the battery door. Notes: Your battery will last longer if you follow these simple guidelines for charging for and storing.
- Page 7 Install or replace the batteries of Remote Control: If using the supplied Remote Control to control the unit. Install or replace (when the batteries were consumed) the batteries as below: Unsecure the screw from the battery door. Open the battery door by slide it off then lift it up as the Fig. 1 below. Install four (4) AA size batteries (not included ) into the battery compartment as the polarity marking inside.( For longest playing time, Alkaline batteries are recommended.)
-
Page 8: Operation With Remote Control
OPERATION Operation with Remote Control: 1. Recharge the built-in battery and connected it to the DC IN Jack on the unit as previous procedure. 2. Slide the Power ON-OFF Switch on the bottom of unit to ON position to power on the unit. - Page 9 The angle of camera can be adjust as below: Camera Replacement of Blades: When the blade was damaged or deformed, replace it by the supplied same type (same makings) spare blade with the supplied screwdriver as the figure below: Note: Always replace the damaged blade by the same type (same makings) blade. Otherwise, the motion of the unit will become abnormal.
-
Page 10: Troubleshooting
TROUBLE SHOOTING: SYMPTOM: POSSIBLE CAUSE POSSIBLE SOULTION The batteries consume. Replace by new batteries. Remote Control not functioning Reinstall the batteries as the polarity marking Batteries wrong installed. inside the battery compartment. The built-in battery had not Connect the built-in battery to the unit as the connected to the unit. -
Page 11: General Specification
General Specification: Power Source: Unit:........Built-in DC 3.7V, 380mAh (1.406WH) Li-ion rechargeable battery. Recharge by DC 5V from any Computer or USB Charger with the supplied USB Charging Cable (Computer and USB Charger not included). Remote Control:........DC 6V, 4 x AA Size Batteries (Not Included). Effective range of Radio Control:....Up to 100 feet in open area Radio Frequency:........2.4GHz Sensor of Camera:........300k Pixels...
