  • Page 1 http://www.wholesalesolar.com/inverters.html Sunny Boy 6000U Installation Guide http://www.wholesalesolar.com/inverters.html...
  • Page 2 http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html...

  • Page 3: Revision History

    Specifications are subject to change without notice. Every attempt has been made to make this document complete, accurate and up-to-date. Readers are cautioned, however, that SMA America reserves the right to make changes without notice and shall not be responsible for any damages, including indirect, incidental or...
  • Page 4 Installation Guide http://www.wholesalesolar.com/inverters.html Tel 530.273.4895 Fax 530.274.7271 www.sma-america.com http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 5: Safety And Hazard Symbols

    This symbol appears beside instructions and warnings that deal with dangerous voltages that can injure or kill people who come in contact with them. This symbol appears beside terminations that are connected to earth-ground. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 6: Warnings

    It calls attention to a procedure or practice, which, if not correctly performed or adhered to, could result in dam- age to or destruction of part or all of the SMA equipment and/ or other equipment connected to the SMA equipment or per- sonal injury.

  • Page 7: General Warnings

    Sunny Boy shipping container. For warranty coverage, or if you have questions about the Sunny Boy warranty, contact SMA America at the address, telephone number or Web site listed on page i (to send E-mail, see the Contact section of the SMA America Web site).
  • Page 8 Installation Guide http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 9: Table Of Contents

    RS-485 Communication ..... . . 5-17 Replacing the Cover ......5-19 Commissioning http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 10 Sunny Boy SB6000U Wiring Diagrams ... . 10-2 Specifications ......10-3 http://www.wholesalesolar.com/inverters.html viii SMA America SB6000U-13:SE2506...

  • Page 11: Introduction

    An example of basic system components is shown in Figure 1-1. Meter PV Array Sunny Boy 6000U Utility Grid Figure 1-1 Sunny Boy 6000U Installed in a Utility Interactive PV System http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 12: Safety

    Photovoltaic Power Systems and UL1998 Software in Programmable Components, as well as IEEE-929-2000 Recommended Practice for Utility Interface of Photovoltaic Systems and IEEE 519 Standard Practices and Requirements for Harmonic Control in Electrical Power Systems. The SB6000U is also listed under UL1741 for Canadian UL. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 13 45°C. Fan cooling allows this level of output power to be achieved even in enclosed spaces. The SB6000U will continue to operate well beyond 45°C and de-rates as needed to maintain a safe internal component temperature. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 14: Installation Overview

    Commissioning involves applying DC input power to the SB6000U, observing the LED and LCD indicators on the front cover, and resolving any problems that occur. Section 7: Displays and Messages This section provides troubleshooting tips and procedures for resolving problems that may occur during installation and operation. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 15: Unpacking And Inspection

    If you need assistance with a damaged Sunny Boy, contact your SMA dealer or SMA America. Contact information for SMA America is provided below.
  • Page 16 Unpacking and Inspection http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 17: Mounting

    SB6000U-13:SE2506 SMA America...
  • Page 18 WARNING: To prevent electrical shock or other injury, check for existing electrical or plumbing installations in the walls before drilling mounting holes for the Sunny Boy. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 19: Dimensions And Recommended Clearances

    Sunny Boy! In a normal operating environment with good ventilation, eight inches of clearance is adequate. Note: The National Electrical Code may require significantly larger working clearances (see NEC Section 110.26). http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 20 Mounting Dimensions and Recommended Clearances http://www.wholesalesolar.com/inverters.html Figure 3-3 Dimensions of the Wall Mounting Bracket http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 21: Mounting Procedure

    Be sure to use the appropriate type of mounting hardware for the wall material and ensure that the hardware is no smaller than 1/4”. Wood wall mounting Stone wall mounting Figure 3-4 Sunny Boy 6000U with Mounting Bracket http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 22 DO NOT use molly or toggle bolts to mount the SB6000U to sheet rock or panelling. 4. Set the bracket aside temporarily, and drill holes at the marks you made on the wall. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 23 8. Replace the hex screw through the hole in the mounting strap and into the threaded hole in the bottom end of the wall-mounting bracket (see Figure 3-4). 9. Tighten the screw. (Do not overtighten) 10.Carefully verify that the Sunny Boy 6000U is firmly mounted in place. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 24 Mounting Mounting Procedure http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 25: Input Voltage Configuration

    Locating Internal Components Figure 4-1 illustrates the locations of the major internal components of the SB6000U. Refer to this illustration as needed to locate particular components. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 26 N L2 used 277 Vac: used used Output AC Line DC– GFDI Terminals Terminal Terminal Fuse Holder (N, L1 and L2) (input from (input from PV array) PV array) Figure 4-1 Sunny Boy 6000U Internal Components http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 27: Configuring The Input Voltage

    3. Do not remove the wire in the left terminal block labeled 0V (2). It remains connected to the right side of the left terminal block in all configurations. 4. All unused wires connect to the right terminal block (3). http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 28 240V and then connected to a 208V grid), the SB6000U will display the following error message: Disturbance XFMR If this error message in encountered, recheck the input voltage configuration and confirm that it is set properly. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 29 If the utility system has a neutral, the local authority having jurisdictiom (AHJ) may require that the neutral be connected to the inverter. Follow the steps to properly configure the utility and neutral in the SB6000U. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 30 The utility configuration jumpers allow the SB6000U to be connected to transformers where the neutral is not present, such as the 208V and 240V Delta, shown in Figure 4- 3 above. Refer to Figures 4-4 and 4-5 for a description of jumper settings. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 31 208V Delta, No Neutral. 240V Delta, No Neutral. NOTE: This functionality applies to units with firmware version 2.58, 2.58 or later. The SB6000U displays the current firmware version during start-up. Fan Test. Figure 4-4 Utility Configuration Jumpers http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 32 Figure 4-5 Utility Configuration Jumper Examples Figure 4-5 above illustrates the proper jumper settings when connecting to a 240 Delta: 120V Stinger type transformer. Note the order in which inverters are connected to the phases. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 33: Wiring The Sb6000U

    3. Connect wires from the AC disconnect to the SB6000U. 4. Connect the PV wires to the DC disconnect. 5. Connect the DC disconnect wires to the SB6000U· 6. Turn the AC switches and/or breakers ON. 7. Turn the DC switches and/or breakers ON. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 34 Knockouts are provided on the bottom of the SB6000U near each of the terminals for the wires to enter the case, see Figure 5-1. 3/4” DC Knockout GFDI Fuse 3/4” AC Knockout Communication Cable Gland Figure 5-1 Bottom View of the Sunny Boy 6000U Showing 3/4” Wiring Knockouts http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 35: Wiring The Ac Output

    CAUTION: All knockouts are sized for -inch rigid conduit (EMT). DO NOT enlarge any of these holes, as this is a violation of UL requirements and will void the SMA warranty. Refer to the table below for the appropriate torque values. Terminal in.
  • Page 36 Percent voltage drop for 208 V AC and 240 V AC service Figure 5-2 Energy Losses in Various Wire Sizes and Wire Lengths Percent voltage drop for 277 V AC service Figure 5-3 Energy Losses in Various Wire Sizes and Wire Lengths http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 37 Voltage Range for 277 V nominal, line to neutral 244 V - 305 V Frequency Range 59.3 Hz - 60.5 Hz See Section 4 for information on configuring the inverter jumpers for the utility type of the installation. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 38: Connecting The Ac Wires

    N in the SB6000U. NOTE: For 277 V the L2 terminal is not used. 10. Connect the wires and tighten to a torque of 18 in-lb. 11. Verify that all connections are correctly wired and properly torqued. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 39 L1 wire connected to L1 terminal N wire connected to N terminal Equipment ground wire connected L2 wire connected to L2 terminal to PE terminal Figure 5-5 AC Connection Terminals for 208 V and 240 V http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 40: Wiring The Dc Input

    WARNING: The DC disconnect for the inverter must have a minimum rating of 600 VDC and 30 A continuous. Note: Use the online SMA string size calculator at www.sma-america.com to determine the correct string configuration (see Figure 5-9). To navigate to the string size calculator, click “Solar Design Tools / String Sizing”...

  • Page 41: Dc Input Grounding

    To configure the SB6000U for positive ground, move the fuse (1) and change the jumper position (2) as show in the following illustrations. Figure 5-7 GFDI Fuse and Jumper Settings for Negative Ground http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 42 Wiring the SB6000U Wiring the DC Input http://www.wholesalesolar.com/inverters.html Figure 5-8 GFDI Fuse and Jumper Settings for Positive Ground http://www.wholesalesolar.com/inverters.html 5-10 SMA America SB6000U-13:SE2506...
  • Page 43 Wiring the SB6000U Wiring the DC Input http://www.wholesalesolar.com/inverters.html Figure 5-9 Online String-Configuration Calculator at www.sma-america.com http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 5-11...

  • Page 44: Connecting The Dc Wires

    SB6000U and void the warranty! Always configure the DC-input-voltage range correctly before connecting the DC-input wires from the PV array to the SB6000U. Use the online SMA string size calculator at www.sma-america.com (see Figure 5-7) to determine the correct string configuration.
  • Page 45 4. Install 3/4-inch conduit between the DC disconnect enclosure and the SB6000U’s DC wiring knockout. Note: Refer to Figure 5-10 for steps 5 through 7. Positive DC wire connected Negative DC to DC+ terminal wire connected to DC- terminal Figure 5-10 DC Connection Terminals http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 5-13...

  • Page 46: Communication Wiring

    Piggy-Back modules that can be installed and connected either at the time the inverter is installed or at any time thereafter. These modules are not included with the SB6000U. Please contact SMA America for information. Refer to the instructions included with the communication module for installation procedures.
  • Page 47 • The cable should be no longer than 15 meters (50 ft.) Use the cable type specified in the RS-232 Tech Note on www.sma-america.com. • RS-232 cables are available from SMA America. • Conduit may be required for communication wiring, per local electrical code re- quirements.
  • Page 48 2 3 5 7 SMC60-AST Terminal block for RS-232 communication 208 Vac: used used 240 Vac: N L2 used used 277 Vac: used used used used Figure 5-11 Connecting a SB6000U to a PC with an RS-232 Cable http://www.wholesalesolar.com/inverters.html 5-16 SMA America SB6000U-13:SE2506...

  • Page 49: Rs-485 Communication

    24 AWG. Use the cable type specified in the RS- 232 Tech Note on www.sma-america.com. • RS-485 cables are available from SMA America. • Conduit may be required for communication wiring, per local electrical code re- quirements.
  • Page 50 Note: The termination of the other end of the RS-485 cable will depend on what type of device you’re connecting to. For detailed information, please see the Tech Updates section of our web site at www.sma-america.com There you will find technical information on all of the Sunny Boy communication options.

  • Page 51: Replacing The Cover

    3. Check the seal on the inside of the cover to ensure it is undamaged and in the correct position. 4. Carefully position the cover on the front of the SB6000U so that the six holes in the cover are aligned correctly with the six threaded holes in the case. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 5-19...
  • Page 52 6. Verify that the cover is in the correct position and that the seal is in place between the case and the cover. 7. Tighten the cover screws to a torque of 70 in-lbs. (8 Nm). http://www.wholesalesolar.com/inverters.html 5-20 SMA America SB6000U-13:SE2506...
  • Page 53 Note: If there is a ground fault in the array, the “EarthCurrentMax” error message will be displayed and the GFDI fuse may clear. If this error message is encountered, switch off the DC and AC disconnects to the SB6000U and troubleshoot the array. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 54 AC disturbance, the inverter will wait 5 minutes after the AC power has been restored to reconnect. When servicing the inverter, always disconnect the DC first, then the AC. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 55: Displays And Messages

    The red and yellow LEDs combined indicate that the inverter has detected a ground fault. The ground fault must be located and cleared and the inverter reset manually. The inverter will not restart automatically after detecting a ground fault. The ground fault may also clear the GFDI fuse. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 56 Displays and Messages http://www.wholesalesolar.com/inverters.html Figure 7-1 The Sunny Boy LED Status Indicator http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 57: Led Operation Indicators

    Occasionally, during inclement weather or low irradiation, the LEDs may all turn on at once and then go off again. This indicates that the inverter is trying to initialize but the power available from the array is not sufficient for normal operation. This is not a malfunction. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 58 Note: If the inverter fails to connect to the utility grid 3 times in a row, it will wait 10 minutes before the next attempt. In case of a grid failure, the Sunny Boy waits 5 minutes before it tries to reconnect to the grid. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 59 45°C and will derate as required to maintain a safe internal component temperature. Unnecessary derating can be caused by blocked fan intakes. For this reason the fan intakes should be inspected often and cleaned when needed. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 60: Led Fault Indicators

    CAUTION: For continued protection against the risk of fire, replace the GFDI fuse with fuses of the same type and rating only. The SB6000U is shipped with a Littelfuse KLKD 1 Amp, 600V AC/DC type fuse. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 61 The SB6000U has detected a fault within the internal monitoring systems. When the inverter detects a fault of this kind it will no longer connect to the utility grid. To correct this, the inverter must be serviced by a qualified service technician. Contact SMA America for assistance.
  • Page 62 AC disconnect between the Sunny Boy and the grid. CAUTION: Have the grid connection to the SB6000U checked only by qualified personnel. WARNING: If opening the SB6000U is required, do so only after disconnecting all sources of power and waiting at least 5 minutes. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...
  • Page 63 WARNING: Disconnect the PV array from the SB6000U immediately. High DC input voltage can permanently damage the inverter. Have the input source checked by a qualified technician. WARNING: Always test the DC voltage at the DC disconnect switch before energizing the SB6000U. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 64 The code is repeated 3 times. If the condition remains the code will continue to be sent. The inverter has encountered an internal fault that prohibits normal operation and will most likely require servicing. Contact SMA America for assistance. http://www.wholesalesolar.com/inverters.html 7-10...

  • Page 65: Status Messages On The Lcd Display

    Sunny Boy Inverter Model # BFR Version x.xx The installed firmware versions of the control system SRR Version x.xx processor (BFR) and the current regulator processor (SRR) are displayed after 6 seconds. Firmware Version #’s http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 7-11...
  • Page 66 MSG #3 Actual AC power output and DC input: 380V AC power and DC voltage E-total 724.4kWh MSG #4 Accumulated yield of the device since installation h-total 512h and the total operating hours: Total energy yield and total operating hours http://www.wholesalesolar.com/inverters.html 7-12 SMA America SB6000U-13:SE2506...
  • Page 67 Note: Each fault message is displayed for 5 seconds. After 5 seconds, the LCD will once again scroll through its normal operating screens. The fault condition will be included in the series of screens until the condition is cleared. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 7-13...

  • Page 68: Communication Options

    Sunny Boy Control Light or the full featured Sunny Boy Control Plus. For more information and assistance in choosing the right data option for your system, please visit the SMA America web site. http://www.wholesalesolar.com/inverters.html 7-14 SMA America...
  • Page 69 Beam Piggy-Back option and provides wireless communication with up to four Sunny Boys in the PV plant. Its graphic display shows a bar chart of actual efficiency as well as daily and total-energy-yields in a single window. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 7-15...
  • Page 70 French and German. Use the diagram and chart below for setting the display. Position of the switches for configuration of the LCD Display language Language Switch S2 Switch S1 German English French Spanish Switch S2 Switch S1 Figure 7-3 Language Selection Switches for the LCD Display http://www.wholesalesolar.com/inverters.html 7-16 SMA America SB6000U-13:SE2506...
  • Page 71 Total system start-up counter Power On: Serial number of the Sunny Boy Serial Number: Current operating mode Mode: Type of grid the Sunny Boy is connected to Grid Type: Error: Description of fault http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 7-17...
  • Page 72 Sunny Boy is in constant voltage MPP mode Derating: Reduction of the grid feeding power due to abnormal heatsink temperatures Disturbance: Grid related fault condition, self clearing Error: Inverter fault, user interaction required Warning: System warning advising further investigation http://www.wholesalesolar.com/inverters.html 7-18 SMA America SB6000U-13:SE2506...
  • Page 73 0 ... 100 Temperature for maximum fan rotation speed. Fan-Test 1 / 0 By setting this parameter to “1“ you can check the function of the fans. This test turns the fans at maximum speed. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 7-19...
  • Page 74 Storage Fixed permanent permanent: changed parameters are stored in EEPROM and are still available after restarting the Sunny Boys volatile: prevents storing the parameters in EEPROM, (i.e. parameters are only saved until next startup.) http://www.wholesalesolar.com/inverters.html 7-20 SMA America SB6000U-13:SE2506...

  • Page 75: Troubleshooting

    • If the system problem persists, contact technical support at: 530.273.4895 In order to better assist you when contacting SMA America, please provide the following information. This information is required for service assistance.
  • Page 76 • Open circuit voltage (Voc) of the module • Number of modules in each string If it becomes necessary to send the Sunny Boy back to the manufacturer for service, please ship it in the original box to avoid damage during shipping. http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 77: Error Messages

    Contact SMA about how to change the grid monitoring parameters of your Sunny Boy. If the grid fre- quency is within the tolerable range and you still observe the failure message “Fac-Bfr“...
  • Page 78 Contact SMA. Error OFFSET Grid monitoring self-test failed. Error The internal test of the Sunny Boy control system firmware failed. Contact SMA in case you observe this failure often. Error Watchdog Watchdog for operation control triggered Error Bfr-Srr...
  • Page 79 Troubleshooting http://www.wholesalesolar.com/inverters.html Error Type Error Code Description Error VacL1-Bfr Voltage is too high or too low VacL2-Bfr VacL1-Srr VacL2-Srr Disturbance XFMR Transformer is connected to the wrong grid. Check the con- nection of the transformer. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 80 Troubleshooting http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 81: Maintenance

    • The fans are mounted to the plate with four nuts each. Position of the nuts Unscrew the four nuts and remove the fans, the spac- ers and filters located behind each fan. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...

  • Page 82: Testing The Fans

    LED’s are out, switch on the inverter. (The Sunny Boy 6000U will not detect the jumper until you cycle power to the inverter.) Jumper position for verifying the operation of the fans Figure 9-1 Jumper Position http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 83: Cleaning The Exhaust Fins

    • Clean the filters and fin plates with a soft brush or cloth. Use mild soap and water if necessary. • When the fins and filters are clean, reinstall them us- ing the above steps in reverse order. http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America...
  • Page 84 Maintenance http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html SMA America SB6000U-13:SE2506...

  • Page 85: Technical Specifications

    • Consult the dealer or an experienced radio/TV technician for help. • The user is cautioned that changes or modifications not expressly approved by SMA America, Inc. could void the user’s authority to operate this equipment. Contact SMA America for more information.

  • Page 86: Sunny Boy Sb6000U Wiring Diagrams

    Technical Specifications http://www.wholesalesolar.com/inverters.html Sunny Boy SB6000U Wiring Diagrams Sunny Boy Connections for 208 and 240 V AC grids 2P 40 Amp (SQUARE D HV361RB) Sunny Boy Connections for 277 V AC grids 1P 30A http://www.wholesalesolar.com/inverters.html 10-2 SMA America SB6000U-13:SE2506...

  • Page 87: Specifications

    21.7 @ 277 VAC Maximum DC Input Current 25 A DC Voltage Ripple Less than 10 % 0.1 W nighttime, < 7 W in operation Power Consumption Ambient Temperature Rating 45°C Enclosure NEMA 3R. (IP54) stainless steel http://www.wholesalesolar.com/inverters.html SB6000U-13:SE2506 SMA America 10-3...
  • Page 88 (430 W x 600 H x 250 D mm) Weight 141 Ibs. (63 kg) Compliance UL1741, E210376, UL 1998, IEEE 519, IEEE 929, ANSI C62.41 D1 & C3, FCC Part 15 A & Specifications subject to change without notice. http://www.wholesalesolar.com/inverters.html 10-4 SMA America SB6000U-13:SE2506...
  • Page 89 http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html...
  • Page 90 http://www.wholesalesolar.com/inverters.html http://www.wholesalesolar.com/inverters.html...
