- Page 1 USER MANUAL - 01 -...
-
Page 2: Check Packing Contents
Check Packing Contents Bike body Tool Pedal Saddle Battery holder components Instruction Charger Packing list Bike body 1 pcs Tool 1 unit Charger 1 pcs Saddle components 1 unit Battery holder 1 pcs Pedal 1 unit Instruction 1 unit - 02 -... - Page 3 R3 Diagram Front brake Accelerator Rear brake Power indicator Handle Headlight power switch Lifting rod lock catch Horn switch Saddle Reflector Foldable sheet steel Headlight,Horn Foldable pushing rack(Optional) Pedal Storage rack (Optional) Front wheel Rear fender Disc-brake (Optional) Motor Front fender...
- Page 4 R3+/R3S Diagram Taillight E-bike status Accelerator Indicator Power indicator (Power-assisted mode) - 04 -...
-
Page 5: Specifications
Specifications Main Technical Parameters 1290mm×550mm×1100mm Item weight ~17kg Size Folding size 840mm×470mm×650mm Max. load 100kg Tire size 14 inch Max. speed ≤ 20km/h Charging voltage AC220V 50-60Hz Max. Permissible Gradient ~15° Charging time About 180/360min Applicable temperature -10℃ ~40℃ USB output voltage 5V Range ≥... - Page 6 Figure 5 Figure 1 Take R3 out of the package bag, unfold pedals and kickstand. Push the head in vertical direction (see Figure 1 - ① arrow), the folding handle along with the bike head is to be down-and-backward to the slot and then button up (see Figure 2- ②...
-
Page 7: Get Started
Get Started R3/R3+provides riders with three different riding modes. 1.Electricity-assisted mode Set right the head, fold kickstand and fasten frame. Adjust bike head and saddle position to ensure a comfortable riding experience. Find the power switch in the one side of the battery, start it and hold the handle. -
Page 8: Important Note
You need lots of practice to grasp the skill before you ride R3 safely. If you are not skilled, or fail to follow the user guide of this product, it may cause rider or others injury or property loss. Our company only takes the responsibility for product defects or damage, and we are NOT responsible for physical injury or property loss related with using products. -
Page 9: Adjustment And Maintenance
The power should be turned off when parking. For your riding safety and for the R3's superb condition, please maintain and clean it regularly. Adjustment and maintenance: Newly purchased vehicles should be adjusted in good condition, if there is any question, please refer to the aftersales staff. -
Page 10: Battery Usage
AC220V power source for 2~4 hours until the charger is full. The normal charge of the battery: the operation of R3 is also the discharge process of the battery. The battery should be charged immediately after the use of the power-assisted vehicle. - Page 11 R3 is not suitable for long-distance travel. Develop good habits to charge in time. Before ride, please ensure R3 has enough electricity. It is very important to form the habit of charging in time every day so that the battery can serve you a longer period of time.
- Page 12 Foldable Fastening screw ⑩ Foldable sheet steel Figure 11 Figure 10 Figure12 Adjust the heights of the bike head and saddle to the lowest and fold the kick-stand (see figure 10). Open the folding steel sheet to separate the folding steel sheet and fastening screw (see Figure 11). Pull the saddle up (see figure 12- ⑩...
-
Page 13: Download App
*Support Android 4.3 or higher, iOS 7.0 or higher. APP Instructions 1. Turn on R3 power button, and start App as well as Bluetooth. 2. Click the search button and do as the follows to connect (verify password is 11111111). - Page 14 Other Functional Instructions USB charging interface Chargeable (compatible with mobile phones and digital equipment). E-bike status power light Power indicator 100% Indicator Low battery indicator Headlight opening indicator Power indicator Green light-high power When the power indicator is red, it Yellow light-middle power is suggested not to ride.
- Page 15 Fender (optional, if any) A l i g n t h e f r o n t f e n d e r a n d Front fender rear fender to the circular rod Front wheel holes in front and rear wheels. Rear fender Tighten the front fender with a Rear wheel...
