  • Page 1 ENGINEER.qxd 16/10/01 13:14 Page 1...
  • Page 2 ENGINEER.qxd 16/10/01 13:14 Page 2...

  • Page 3: Table Of Contents

    ENGINEER.qxd 16/10/01 13:14 Page 3 Contents Introduction ..... . 2 Mains Safety ....2 Good Working Practice .

  • Page 4: Introduction

    Page 2 Introduction The eurosec control panel is supplied as a blank fronted end station complete with LCD RKP. Up to 3 additional may be fitted if required. The unit is fully programmable by the installation and comes pre-programmed with a set of factory defaults that will suit most installations. Seven...

  • Page 5: Installation

    ENGINEER.qxd 16/10/01 13:14 Page 3 Control Panel & RKP Location Consideration needs to be given to the location of the Control Panel & LCD RKP with regards The surface that the unit(s) are to be fixed to should be firm, vibration free, damp free and fire resistant.

  • Page 6: Wiring

    ENGINEER.qxd 16/10/01 13:14 Page 4 General Detector Wiring We would strongly suggest that you adopt a colour scheme for the detector wiring of your system. This will enable you to quickly determine the source of any problems that may occur. The security industry does not have recommended colour schemes because of the nature of the wiring, one suggested scheme is given below.

  • Page 7: Wiring Passive Infra-Red Detectors

    ENGINEER.qxd 16/10/01 13:14 Page 5 Fig. 2 Wiring Single Contact Fig. 3 Wiring Double Contact (on the same zone) Wiring Passive Infra-Red Detectors It is essential when using Passive Infra-Red Detectors that you refer to the manufacturers instruction as to the positioning and settings of the detector. This section is intended as a guide to the wiring of the detectors.

  • Page 8: General Bell Box Wiring

    Sample Bell Box Connections Below is shown general and sample bell box connections for some of the popular bell boxes that are available. Fig.6A General bellbox Fig.6B connections eurosec control panel terminals Tamper Feed Novagard Delta eurosec control bellbox connections panel terminals...
  • Page 9 ENGINEER.qxd 16/10/01 13:14 Page 7 Fig.6E Fig.6F CQR Integra HS Texecom Azura eurosec control bellbox connections bellbox connections eurosec control panel terminals Common panel terminals (Select AT Return) SAB TMP SAB TMP AT Return Bell Hold - Bell Hold -...

  • Page 10: Wiring Notes

    ENGINEER.qxd 16/10/01 13:14 Page 8 Wiring Notes Fig. 7 Control Panel Connections The 680 Ohm resistor (provided) must be fitted across 12v & D1 at the last RKP in line. Maximum current draw from the panel MUST NOT EXCEED 1Amp. This includes all Bells, Sounders, Speakers, Detectors &...

  • Page 11: Programming

    ENGINEER.qxd 16/10/01 13:14 Page 9 Terminology Various terms are used throughout this manual that may be unique to the eurosec control panel. This section gives brief details of this terminology. Zones 12Hr Alert A zone programmed as 12Hr is active when Internal Speaker only.

  • Page 12: Engineer Programming Mode

    ENGINEER.qxd 16/10/01 13:14 Page 10 Engineer Programming Mode Several options are available via the Engineer code (1234 factory default). These are Setting and Unsetting of the system. Engineer/User Options System Test Delete Zone(s) Chime On/Off Program Code Set Time/Date View Log Program Engineer Options Details of items a and b are given in the user manual.

  • Page 13: Programmable Engineer Options

    ENGINEER.qxd 16/10/01 13:14 Page 11 Press No the display will show:- Program ..Zones ? Press Yes the display will show:- Select 1 . . 8 Select a number corresponding to the zone you wish to program.
  • Page 14 ENGINEER.qxd 16/10/01 13:14 Page 12 Press No the display will show:- Program ..Entry / Exit Press Yes the display will show:- F - Exit Time Default Full Set Exit Time is 30 seconds to change press No followed by time required then Yes.
  • Page 15 ENGINEER.qxd 16/10/01 13:14 Page 13 Press No the display will show:- Program ..Bell & Panic ? Press Yes the display will show:- Ring Time Default Bell Time is 20 Minutes to change press No followed by the required time then Yes.

  • Page 16: Engineer / User Mode

    ENGINEER.qxd 16/10/01 13:14 Page 14 Press No until the required mode is displayed for 2 Mode PGM1 then press Yes. The display will show*:- SW12V Press No until the required mode is displayed for PGM2* then press Yes. The display will show:- Chan.

  • Page 17: Engineer Reset

    ENGINEER.qxd 16/10/01 13:14 Page 15 Engineer Reset (After an Alarm) If the Reset Mode(s) has been programmed for Engineer follow the steps below to reset the system. The user must first unset the system. Details in user manual. Enter the engineer code followed by RESET. It should be noted that if the Tamper reset has been programmed for Engineer Reset the display will show Service Due...

  • Page 18: Resetting To Factory Defaults

    As soon as the display becomes active enter 1 4 7 No. Changing Log Modes The Eurosec CP8 LCD has two log modes. These are:- 256 events without Time & Date stamps 64 events with Time & Date stamps (Default setting) To change the Log Mode:- Remove all power from the system.

  • Page 19: Troubleshooting

    ENGINEER.qxd 16/10/01 13:14 Page 17 Fault Action Control Panel will not power up from the Check / Replace fuse in fused spur or mains mains supply connection block. Also check all connections for trapped insulation. Display shows zone fault and panel will Remove zone wires from the problem zone at not set after the exit time has expired.
  • Page 20 ENGINEER.qxd 16/10/01 13:14 Page 18 Fault Action Tamper is not tripped when a detector Check to see if all tampers are wired in series. cover is removed. If detector tampers have been wired in parallel they will all have to be removed before the tamper would trigger.

  • Page 21: Specifications

    ENGINEER.qxd 16/10/01 13:14 Page 19 Power Input: 230v a.c +/- 10% @50Hz No. of Zones: CP8 = 8 LCD Max Loop Resistance: 2K Ohms Loop Delay Time: 300 milliseconds Fuses: Mains Fuse: 200mA slow blow F2 Misc Fuse: 250mA quick blow F1 System Fuse: 1A quick blow Low Voltage Output:...

  • Page 22: System Details

    ENGINEER.qxd 16/10/01 13:14 Page 20 Customer Name Customer Address Tel No: Fax No: Installation Date Installing Engineer(s) Control Panel Location RKP Location(s) Zone 1 Location Zone 5 Location Zone 2 Location Zone 6 Location Zone 3 Location Zone 7 Location Zone 4 Location Zone 8 Location Notes...

  • Page 23: Changing The Engineer Code

    ENGINEER.qxd 16/10/01 13:14 Page 21 Changing the Engineer code The engineer code may only be changed by use of the current engineer code. If the engineer code starts with a 9 the code will be ‘locked in’ defaulting the panel will have no effect on the engineer code. To program the engineer code proceed as follows:- Enter the Engineer Code (1234 default) followed by No Do You Want to.
  • Page 24 ENGINEER.qxd 16/10/01 13:14 Page 22 Supplied By:- Technical Helpline 01706 510200 PR5203 Rev1.2...
