Nautel NG1000 Installation Manual

Weather radio transmitter system
Hide thumbs Also See for NG1000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual
NG1000 Weather Radio
Transmitter System
Installation Manual
Document: NG1000-INST
Issue:
0.4 2010-10-12
Status:
Preliminary

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NG1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nautel NG1000

Summary of Contents for Nautel NG1000

  • Page 1 NG1000 Weather Radio Transmitter System Installation Manual Document: NG1000-INST Issue: 0.4 2010-10-12 Status: Preliminary...
  • Page 3 The comparisons and other information provided in this document have been prepared in good faith based on publicly available information. The reader is encouraged to consult the respective manufacturer's most recent published data for verification. © Copyright 2010 NAUTEL. All rights reserved.

  • Page 5: Table Of Contents

    NG1000 Installation Manual Table of contents Contents Release control record About safety Safety precautions About this manual xvii Preparing for installation Unpacking and assembly Connecting to station reference ground Connecting ac power Installing the RF feed cable Installing audio inputs...
  • Page 6 NG1000 Installation Manual Table of contents Commissioning Going on-air Parts and tools Contacting Nautel Parts supplied by Nautel Parts not supplied by Nautel Parts ordering Module replacement program Tools for installation Pre-installation / Installation assistance 10-1 Pre-installation consulting 10-1 Installation and commissioning service...

  • Page 7: Release Control Record

    NG1000 Installation Manual Release control record Issue Date Reason 2010-02-24 Initial release of manual 2010-05-19 Incorporated Engineering review comments 2010-06-11 Incorporated Engineering review comments 2010-10-12 Incorporated customer review comments Issue 0.4 2010-10-12 Page vii...
  • Page 8 NG1000 Installation Manual Page viii Issue 0.4 2010-10-12...

  • Page 9: About Safety

    NG1000 Installation Manual About safety All Nautel transmitters are designed to meet the requirements of EN60215, Safety Requirements for Radio Transmitters. The philosophy of EN60215 is that the removal of any cover or panel that can only be opened using a tool is a maintenance activity, and that any person performing a maintenance activity is expected to be trained for that activity.
  • Page 10 NG1000 Installation Manual Lightning hazards Before opening the transmitter and touching internal parts, remove and solidly ground the antenna connection. WARNING: It is not enough to ground the antenna terminal with the antenna still connected. Even a small impedance in the ground strap will result in lethal voltages during a lightning strike.

  • Page 11: Safety Precautions

    Personnel must be familiar with the transmitter, so that they can avoid physical danger, and be aware of hazards to themselves and the equipment. Nautel offers a number of training courses covering the basic fundamentals of RF systems and transmitters, and the operation and maintenance of the transmitter. For more information about available courses and schedules, go to the Nautel website at http://www.nautel.com/Training.aspx,...
  • Page 12 Operation of safety interlocks (if installed) First aid Nautel does not offer first aid training, since the hazards associated with high voltage and RF energy are not specific to the transmitter. However, the customer should provide first aid training to all per- sonnel who have access to the transmitter site.
  • Page 13 NG1000 Installation Manual Marking hazards Place warning signs close to any hazardous areas or systems (e.g., the feedline or the antenna system). Make the signs large enough that they cannot be missed. Provide signage in all languages used in the region.
  • Page 14 (and to protect the rest of your site equipment and your personnel). For detailed information about lightning protection, see the Nautel Site Preparation Manual, available from your Nautel sales agent, or online from the Nautel website.
  • Page 15 NG1000 Installation Manual Earthquake protection If the transmitter site is in a region that experiences any noticeable earthquake activity, take steps to prevent the transmitter from shifting or rocking during an earthquake. Even during minor earthquakes, rocking or movement of the transmitter is likely to damage the feedline connection, and could even cause a catastrophic failure of the ac power feed into the transmitter.
  • Page 16 NG1000 Installation Manual Page xvi Issue 0.4 2010-10-12...

  • Page 17: About This Manual

    NG1000 Installation Manual About this manual This manual provides information about installing an NG1000 transmitter. This manual is intended for use by qualified, trained installers. Technical support Nautel offers technical support to customers over the Internet and by telephone. Nautel’s customer support team will answer your questions and work with you to identify and resolve problems.
  • Page 18 The Nautel website provides useful resources to keep you up to date on your NG1000. Nautel User Group (NUG) The website includes a special section that customers can log into in order to access the Nautel customer newsletter, product manuals, frequently asked questions (FAQ), information sheets, and information about field upgrades.

  • Page 19: Preparing For Installation

    8. Assemble your parts and tools. For a list of required tools, see “Parts and tools” on page 9-1. 9. When you are ready to install the NG1000 transmitter system, follow the steps shown in Figure 1.1 on page 1-2.

  • Page 20: Unpacking And Assembly

    NG1000 Installation Manual Preparing for installation Figure 1.1: Flowchart - Installing the transmitter system Unpacking and assembly - see page 2-1 Connecting to station reference ground - see page 3-1 Connecting ac power - see page 4-1 Installing the RF feed cable - see page 5-1...

  • Page 21: Unpacking And Assembly

    Section 2: Unpacking and assembly To install an NG1000 transmitter system, perform the following tasks: 1. Lift and slide the transmitter system cabinet off the base of its crate. Crated and uncrated weights for the transmitter system and ancillary items are shown in Table 2.1.
  • Page 22 NG1000 Installation Manual Unpacking and assembly Figure 2.1: Installing Bandpass Filter/Directional Probe and Dummy Load M4 screws (qty 4) M4 nuts (qty 2) Mounting Plate with Bandpass Filter and Directional Coupler Dummy Load and Bracket 6. Install the dummy load and bracket on the right-hand side (as viewed from the front) of the transmitter system cabinet using six sets of M6 securing hardware (screws, split washers and flat washers) that were left in the side of the cabinet for shipping.
  • Page 23 Moving the cabinet after the levelers have been adjusted may damage the levelers. 9. Using a 3/16-inch T-handle hex tool (Nautel Part # HY83, provided in the ancillary kit), level the transmitter system by adjusting the six levelers in the system cabinet corners and the dummy load bracket (see Figure 2.2 on page...
  • Page 24 NG1000 Installation Manual Unpacking and assembly Figure 2.2: Cabinet Leveler Detail CABINET LEVELERS (located in each corner; four inside cabinet, two on dummy load bracket) 14. Route W8P2 (7/16 DIN connector) through the lower clearance hole in the side of the system cabinet.

  • Page 25: Connecting To Station Reference Ground

    For all conductors (straps, wires, etc.) that must connect to the station reference ground stud, Nautel recommends using an isolated copper bar that is electrically connected to the station reference ground. In this case, terminate all station reference ground connections on the copper bar.
  • Page 26 NG1000 Installation Manual Connecting to station reference ground Figure 3.1: Station Reference Ground Strap Connection Rear Door Conductor From Station (copper strap shown) Reference Ground IMPORTANT ! Do not allow conductor to contact the transmitter chassis at any other point.

  • Page 27: Connecting Ac Power

    Ferrite toroids are fragile. Use care when handling and installing them. 4. Install or verify that the ac surge protector (Nautel Part # UE61, located in the ancillary kit) has been installed between the ac power source and the ac power disconnect switches. Refer to the NG1000 Pre-installation Manual for more details.
  • Page 28 TB1-3 ( N ). Connect the ac ground to TB1-4 ( G ). Secure all wires in their respective terminals. 11. Use provided tyraps (Nautel Part # HT29) and tyrap mounts (Nautel Part # HAC15 and HT52) from the ancillary kit’s equipment hardware kit (Nautel Part # 216-5130) to neatly route and secure ac cables inside the system cabinet.
  • Page 29 NG1000 Installation Manual Connecting ac power Figure 4.1: Ac Input Entry Options (Top or Rear) Front of System Cabinet PRIMARY AC DISTRIBUTION ASSEMBLY (A5) SECONDARY AC DISTRIBUTION ASSEMBLY (A6) 7/8 in. HOLES FOR TOP AC ENTRY Partial Rear View of System Cabinet 1-3/8 in.
  • Page 30 NG1000 Installation Manual Connecting ac power Figure 4.2: Ac Input Terminal Block Connections A5, A6 DETAIL (as viewed from the rear) L1...L2 .N .GND ..AC PRESENT Page 4-4 Issue 0.4 2010-10-12...

  • Page 31: Installing The Rf Feed Cable

    2. Verify the RF feed cable is in place and is cut to the required length. 3. Get two ferrite toroids (Nautel Part # LA53, 61 mm outer diameter, 35 mm inner diameter) from the ancillary kit. These toroids are large enough to accommodate the coaxial cable’s 7/ 16 DIN connector.
  • Page 32 NG1000 Installation Manual Installing the RF feed cable Figure 5.1: RF Feedline Connection SYSTEM RF OUTPUT CONNECTOR (7/16 DIN - female) U1 - PORTS 2, 4 TOP (PORTS 1, 3 BOTTOM) Front of System Cabinet Page 5-2 Issue 0.4 2010-10-12...

  • Page 33: Installing Audio Inputs

    Installing audio inputs This section describes how to route audio input wiring to the NG1000 transmitter system. Planning Make sure you have read and fully understood the audio input information provided in the NG1000 Pre-installation Manual before proceeding. Routing cables Figure 6.1 on page...
  • Page 34 NG1000 Installation Manual Installing audio inputs Figure 6.1: Routing Audio Input Cables RECOMMENDED AUDIO INPUT ENTRY SURGE PROTECTOR Page 6-2 Issue 0.4 2010-10-12...

  • Page 35: Installing Control And Monitoring Wiring

    See Figure 7.1 on page 7-2. Route all cables through a ferrite toroid (Nautel Part # LXP38, 38 mm outer diameter, 19 mm inner diameter), provided in the ancillary kit. Note: Ferrite toroids are fragile. Use care when handling and installing them.
  • Page 36 Connect the 15-pin D-sub connector to the AUX I/O (A1J11A) connector. See Figure 7.3 on page 7-4. A connector (Nautel Part # JS101) is provided in the ancillary kit for this purpose. Page 7-2...
  • Page 37 NG1000 Installation Manual Installing control and monitoring wiring Figure 7.2: Phone Line Connections CUSTOMER PHONE LINE FROM ACCESS TOP OF CABINET SCREW U8 - ACCESS COVER OPENED HEX-HEAD SECURING SCREW U8 - ‘DO NOT REMOVE’ COVER REMOVED PARTIAL REAR VIEW...
  • Page 38 NG1000 Installation Manual Installing control and monitoring wiring Figure 7.3: System Connections PARTIAL REAR VIEW OF SYSTEM CONTROLLER A1 EXTERNAL WIRING Auxiliary I/O FROM TOP OF CABINET (see Pre-Install Manual for connection details) Denotes Nautel installed wiring AUDIO Denotes user...

  • Page 39: Commissioning Tasks

    NG1000 Installation Manual Commissioning tasks Section 8: Commissioning tasks WARNING: Before applying ac power and turning on the transmitter system, you must customize some circuits to the station's power source and operating requirements. Do not perform this pre- commissioning unless you are a station engineer or a competent electronics technician.

  • Page 40: Commissioning

    Ensure that changeover is inhibited. See the NG1000 Operating and Maintenance Guide. 4. Check the alarm and status indications on the system controller’s UI. See the NG1000 Operating and Maintenance Guide. 5. Press the LOCAL control button.

  • Page 41: Going On-Air

    2. Verify audio input levels using the system controller’s UI. 3. Use the system controller’s UI to begin transmitter operations. For detailed instructions, refer to the NG1000 Operating and Maintenance Manual. Issue 0.4 2010-10-12 Page 8-3...
  • Page 42 NG1000 Installation Manual Commissioning tasks Page 8-4 Issue 0.4 2010-10-12...

  • Page 43: Parts And Tools

    Parts supplied by Nautel Ancillary parts kit An ancillary parts kit is shipped with the NG1000. This kit contains items needed during the installation process. The kit includes toroids, screws, miscellaneous hardware, some remote control/ monitoring cables and some installation tools.

  • Page 44: Parts Not Supplied By Nautel

    See “NG1000 transmitter manuals” on page xvii. Parts not supplied by Nautel Some parts and materials required to complete installation are not supplied by Nautel. The parts you need vary with the installation requirements. The list of parts you normally provide yourself during installation include: A suitable 50 Ω...

  • Page 45: Tools For Installation

    NG1000 Installation Manual Parts and tools Tools for installation The tools you need during transmitter installation include the following: • Digital voltmeter (recommend 1000 V, CAT-III rating) • Philips screwdrivers, sizes #1 and #2 (cordless # 2 recommended for opening packing crates) •...
  • Page 46 NG1000 Installation Manual Parts and tools Page 9-4 Issue 0.4 2010-10-12...

  • Page 47: Pre-Installation Consulting

    Extended warranties - see page 10-7 Pre-installation consulting Nautel field support specialists are available to answer questions and work with you to ensure that your site will be ready for the installation of your NG1000 transmitter. For support, contact Nautel Cus- tomer Service and request assistance (“On-site support”...
  • Page 48 Ac power wiring for the transmitter has been installed and connected at the breaker panel or the building’s service entrance. If local electrical codes allow Nautel personnel to connect the transmitter to the ac supply, using the customer's cable, that task is included in this service.

  • Page 49: Online Documentation

    Nautel training programs are made up of individual modules that can be 'mixed and matched' to meet the customer’s specific training needs. All Nautel training courses are available at the Nautel Training Center.

  • Page 50: Standard Warranty

    Nautel for repair. The repairs will be made without charge to the Customer. 4. Where warranty replacements or repair are provided under items 2 or 3, Nautel will pay that part of the shipping costs incurred in returning the part/assembly to the Customer.
  • Page 51 7. Nautel shall have the privilege of investigating whether failures have been caused by factors beyond its control. 8. Nautel shall in no event be liable for any consequential damages arising from the use of this equipment. 9. When requesting a warranty repair/replacement, please provide complete and accurate information.
  • Page 52 Pre-installation / Installation assistance Module exchange service In order to provide Nautel customers with a fast and efficient service in the event of a problem, Nautel operates a factory rebuilt, module exchange service which takes full advantage of the high degree of module redundancy in Nautel equipment.

  • Page 53: Extended Warranties

    Extended warranties Nautel's standard 13-month warranty provides excellent coverage and satisfies most customers’ needs. However, if you want extended coverage, Nautel offers one and two-year Extended Warranty Plans to cover electrical and mechanical repairs or replacements for all Nautel equipment.
  • Page 54 If Nautel’s service technicians are unable to solve the problem over the telephone, Nautel will give you an RMA number. You then return the module or circuit board to a Nautel service facility so that Nautel can provide a replacement. (Do not ship a component back to Nautel until you have an RMA number.)

  • Page 55: List Of Terms

    NG1000 Installation Manual List of terms Section 11: List of terms This section defines some of the terms that are used in Nautel documentation. A reduction in RF output power, caused by the occurrence of multiple shutbacks within a Cutback. pre-defined period.
  • Page 56 NG1000 Installation Manual List of terms Page 11-2 Issue 0.4 2010-10-12...

  • Page 58: Issue 0.4 2010-10-12

    Toll Free: +1.877.6NAUTEL (6628835) (Canada & USA only) Fax: +1.902.823.3183 Nautel Inc. 201 Target Industrial Circle Bangor, Maine USA 04401 Phone: +1.207.947.8200 Fax: +1.207.947.3693 Customer Service (24 hour support) +1.877.628.8353 (Canada & USA only) +1.902.823.5100 (International) Email: support@nautel.com Web: www.nautel.com © Copyright 2010 NAUTEL. All rights reserved.
