Summary of Contents for TeleCare24 teleCARE SC
- Page 1 Installation Instructions Switch / Speech Module teleCARE With Socket 50 mm 6 mm 140 mm 2003-08-19 / Ver. B Details are subject to change without notice TD 91605GB...
- Page 2 Installation Instructions Switch / Speech Module teleCARE With Socket Bed Light 1 Bed Light 2 teleCARE SC GND(*) L-RD Bed Light 1 Bed Light 2 teleCARE M GND(*) L-RD L-YL(*) (*) = depending on the application L-RG(*) 2003-08-19 / Ver. B...
- Page 3 Installation Instructions Switch / Speech Module teleCARE With Socket Positioning of the teleCARE Peripherals 2003-08-19 / Ver. B Details are subject to change without notice TD 91605GB...
- Page 4 Installation Sheet teleCARE Switch Module Programming Solder Pad Settings Top button (red) output on 'S' Factory placed (Default setting) Ω resistor 0Ω teleCARE Nurse Call System Top button (red) output on 'R' Factory placed Ω resistor 0Ω teleCARE Nurse Call System Yellow button output on 'S' and 'R' (Default Setting) teleCARE...
- Page 5 teleCARE Switch Module Dismantling Instructions To remove the face plate of the teleCARE switch modules a screw- driver with a point of approximately 6mm wide is to be used. Insert the point of the screwdriver into the groove at the side of the switch module, between the face plate and the backplate (or surface mounting frame) at about 10mm from one of the top corners.
