- Page 1 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual 8AL90850USBAed01 -10/2013...
- Page 2 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel- Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.
- Page 3 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual Regulatory information European Union Declaration of Conformity This equipment is in compliance with the essential requirements of R&TTE Directive 1999/5/EC.The Declaration of Conformity may be obtained from your installer. PRODUCT DISPOSAL INFORMATION (EN)
- Page 4 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual must accept any interference received, including interference that may cause undesired operation. Modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 5 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual Regulatory information Canada This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 6 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual 8AL90850USBAed01...
-
Page 7: Table Of Contents
1.11 INSTALLATION PROCEDURES ............... 13 1.12 UNPACKING ..................... 14 ADJUSTING THE ANTENNA POSITION ..............15 MOUNTING THE G.729 DAUGHTERBOARD ............19 MOUNTING THE 8340 Smart IP-DECT AP AGAINST A WALL/CEILING ....21 LEDs .......................... 24 LED Status ......................24 LED Colours ...................... 25... - Page 8 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual PREFACE This manual is applicable for the 8340 SMART IP-DECT AP, DECT Transceiver. Please note that some product models or features described in this manual may not be available in all world regions.”...
- Page 9 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual 8AL90850USBAed01...
-
Page 10: 8340 Smart Ip-Dect Ap General
This installation Manual is valid for installing a DECT transceiver (8340 Smart IP-DECT AP) to a wall in horizontal or vertical position. The 8340 Smart IP-DECT AP is designed for indoor use. When installing an 8340 Smart IP-DECT AP outdoors, please use the... -
Page 11: Site Requirements
Temperature range 8340 Smart IP-DECT AP: 0 to 45 C. The 8340 Smart IP-DECT AP should not be exposed to sunlight! The outside temperature range for the 8340 Smart IP-DECT AP (all types) mounted in the Outdoor Cabinet is as follows: ... -
Page 12: Cable Specifications For 8340 Smart Ip-Dect Ap Types
CABLE SPECIFICATIONS FOR 8340 Smart IP-DECT AP Types The cabling to the 8340 Smart IP-DECT AP External antennas should be “Category 5” or “Category 6” Ethernet cabling. The interface is defined as an SELV interface according EN60950-1. For this reason the safety restriction as given in the next chapter should be... -
Page 13: Internal Electrical Isolation
8340 Smart IP-DECT AP external antennas in the 8340 Smart IP-DECT AP. G.729 DAUGHTER BOARD By default the G.729 Daughter Board is installed on the 8340 Smart IP-DECT AP. The 8340 Smart IP-DECT AP does support the G.729 codec, G.711u law and G.711a law. ... -
Page 14: Installation Procedures
Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual When the 8340 Smart IP-DECT AP is mounted horizontally, the antenna position must be changed (see chapter 2). Figure 2. 8340 Smar IP-DECT AP mounted horizontally 1.11 INSTALLATION PROCEDURES The installation of an Outdoor Cabinet comprises the installation of: ... -
Page 15: Unpacking
1.12 UNPACKING PROCEDURE: “Unpacking”. Actions Open the card board box and take the 8340 Smart IP-DECT AP out. Check the 8340 Smart IP-DECT AP for any damage. Continue with one of the following Chapters: When you mount the 8340 Smart IP-DECT AP vertically, the antenna position will normally be OK, and when you do not need to install the G.729 Daughter... -
Page 16: Adjusting The Antenna Position
This chapter is not applicable for the 8340 Smart IP-DECT AP External antennas. Note: You only need to change the antenna position when you mount the 8340 Smart IP-DECT AP horizontally! In all other cases you don’t need to change the antenna position. - Page 17 Open the cabinet CAREFULLY! Make sure that you shift the cover of the antenna’s carefully from the antenna’s. Take the antenna cover from the 8340 Smart IP-DECT AP cover. To put the antennas in vertical position, bend them carefully as shown in Figure 5.
- Page 18 Installation Manual Figure 5. Bend Antennas carefully into vertical position. After the antennas are put in the vertical position, close the 8340 Smart IP-DECT AP cabinet again. In other words, put the 8340 Smart IP-DECT AP cover back into position and secure the screws at the rear side of the cabinet. See Figure 6.
- Page 19 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual Make sure that the antennas are properly locked into the locks in the 8340 Smart IP- DECT AP cover. Figure 7. Detail of Antenna in lock. Move the antenna cover carefully over the antennas in the vertical position and make sure that the antennas do not bend.
-
Page 20: Mounting The G.729 Daughterboard
LED Light conductor Figure 9. Light conductor for LEDs Now you should have the 8340 Smart IP-DECT AP PWB and the G.729 Daughter Board as separate items. Remove the protection foil from the sticky part on the G.729 Daughter Board. - Page 21 Main Board. Figure 11. Mounting the G.729 Daughter Board onto the Main board. Put the 8340 Smart IP-DECT AP together in the reverse order as it was disassembled, mounting the PCB into the cabinet and assembling the cabinet. Do not forget to mount the two screws back into the rear side of the cabinet.
-
Page 22: Mounting The 8340 Smart Ip-Dect Ap Against A Wall/Ceiling
MOUNTING THE 8340 Smart IP-DECT AP AGAINST A WALL/CEILING PROCEDURE: “Procedureformountingthe8340 Smart IP-DECT AP to the wall”. Actions Remove the mounting plate from the 8340 Smart IP-DECT AP cabinet. Push clip up, to take mounting plate off. Figure 12. How to take the mounting plate off. - Page 23 If necessary, mount the RJ45 connector to the cable using the tool for mounting an RJ45 connector plug to a Category 5 or Category 6 cable. Lead the cable to the 8340 Smart IP-DECT AP cabinet and connect the RJ45 connector. Push the cable into the groove.
- Page 24 Installation Manual Push the cabinet onto the mounting plate. Note: When pushing the 8340 Smart IP-DECT AP on to the mounting plate, make sure that you hear/feel a distinct click. This indicates that the 8340 Smart IP-DECT AP is firmly mounted to the mounting plate.
-
Page 25: Leds
LEDs LED Status The 8340 Smart IP-DECT AP is equipped with two LEDs. Top LED – Yellow This LED represents the status of the 8340 Smart IP-DECT AP. LED Status (Top LED, Yellow) Meaning No power 0,5 seconds On - 0,5 seconds... -
Page 26: Led Colours
Network status display and showing network activity 8340 Smart IP-DECT AP operational Table 2. Lower LED status on the 8340 Smart IP-DECT AP. LED Colours The colour of the top LED might be different depending on the operational mode. The following operational modes are distinguished: ... -
Page 27: Aspecifications
When in Outdoor Box = IP66 Relative Humidity ......... : 5 . . . 95 % PoE Specifications: Voltage at 8340 Smart IP-DECT AP via PoE 36 ..57 V. DC PoE Class ............ : Class 2 ... - Page 28 Alcatel-Lucent 8340 Smart IP-DECT AP Installation Manual Note: Country selection is determined by the DAP Controller Type! See section 1 .2 COUNTRY SELECTION. 8AL90850USBAed01...
