- Page 1 ENGLISH Inductive Guard Tour Reader Usage Manual BP-2012S Guard Tour Reader BP-2012F Guard Tour Reader Please read this manual carefully, before starting to operate the reader.
-
Page 2: Main Features
PC for processing and verification. The main different between BP-2012S and BP-2012F is the BP-2012F has a LCD display window. First-Time Usage Before reading signal cards, first connect with the PC and start the software to calibrate the reader’s internal clock. -
Page 3: Status Indications
Operation Instructions BP-2012S Turning On and Off The system will turn on automatically to perform card reading when it is within the range of a valid signal card. It will automatically shut off when card reading is complete. Reading Cards Position a card in front of the blue reading head. - Page 4 After Reading a Card, 4 Beeps With 4 Flashes The reading was not successful. The reader memory is full, the data needs to be uploaded before more readings can be made. After Reading a Card, 1 Beep With 4 Flashes, Followed By 4 Beeps With 4 Flashes The reading was successful, but the reader’s internal clock should be calibrated with the PC before further readings are made After Reading a Signal Card, The LED Light Flashes Continuously...
- Page 5 BP-2012S/BP-2012F reader could upload the data via communication station from BS-1000, BS-2000, BS-3010/BS-3010M, BS-3300, BS-4000/BS-4000M, BS-6000. Please keep rest of the BP-2012S, BP-2012F readers and EM Cards at lest one foot away from the stations when the readers in the uploading process.
- Page 6 BP-2012S/BP-2012F guard tour reader in its indentation. The reading head of the BP-2012S/BP-2012F should be between the status lights of the BS-3010, and its top should be flush against the inside edge of the BS-3010. The data upload process will be automatically started.
-
Page 7: Working As Card Reader
5 seconds. The interval between signal card readings should be longer than 5 seconds. Working As Card Reader The BP-2012S/BP-2012F guard tour reader can be used as a standard signal card reader used for various applications. Troubleshooting After reading a card, 1 beep with 4 flashings, followed by 4 beeps with 4 flashes The reading was successful, but the reader’s internal clock should be calibrated with the PC before... - Page 8 The LED continuous flashes The battery is low and needs to be charged. Please follow the “BP-2012S Reader Battery Change Instruction” to change the battery. Failed to upload data to the software and followed by 8 beeps with 8 flashes There is an error when uploading data.
- Page 9 When you are uploading the records from BP-20002S or BP-2012F reader into software via BS-1000, please keep rest of the BP-2012S, BP-2012F readers and EM Cards at lest one foot away from the BS-1000 station. Please refer to the following picture for the details...
- Page 10 Further on the above issue when you upload the record from BP-2012S or BP-2012F via BS-2000, BS-3000/BS-3000M, BS-4000/BS-4000M, and BS-6000, also please keep rest of the BP-2012S, BP-2012F readers and EM Cards at lest one foot away from the stations.
- Page 11 BP-2012S Data Sheet Card-Reading Inductive / Non-Contact Card Format 125 Khz EMID Model Size Range BLC-02 86mm×54mm 6.0cm Maximum BLC-40 Φ40mm 4.0cm Reading Range BLC-30 Φ30mm 3.5cm (BlueCard Tags) BLC-22 Φ22mm 3.5cm BLC-6-28 Φ6mm×28mm Power Capacity >330,000 Readings Battery Type...
-
Page 12: Battery Usage Guidelines
Battery Usage Guidelines Always follow your battery manufacturer’s directions fully. Do not attempt to disassemble, recharge, short circuit, or subject the battery to high temperature or fire. Please be sure to read this manual thoroughly before use. Also, refer to the manual of the equipment for which you see this battery pack. - Page 13 Changing the Battery on the BP-2012S/BP-2012F Reader NOTE 1: the battery type used on the BP-2012S reader is type CR123A, which can be purchased in many convenience stores. Below is an example of the battery: NOTE 2: BP-2012F use the exactly same way to change the battery. Please follow the instructions to replace the BP-2012F battery.
- Page 14 Silicone waterproofing ring Open the battery cap and remove the battery (please refer to the document named “BP-2012S Battery Change.doc” for more details). You should be able to see the battery compartment of the reader, revealing its metallic battery contact.
- Page 15 Remove the silicone shock-absorption pad from the inside wall of the battery compartment. (Be sure to replace it after the completion of this process.) Create a circuit between the round metallic contact on the bottom of the compartment and the compartment wall for approximately 2-5 seconds. Replace the silicone shock-absorption pad, the battery, and the battery cap.
- Page 16 The information in this documentation is subjective to change notice and does not represent a commitment on the part of Bluecard Technologies Corp. No part of the this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, for any purpose other than the purchaser’s personal use, without the written permission of Bluecard Technologies Corp.
- Page 17 SAR Exemption Statement : This device measured RF output power is less than the SAR exclusion threshold value for human head and body. Therefore, SAR test is not necessary. Bluecard Technologies Corp.
