Page 1: User Manual
Outdoor Wireless Access Subscriber Modem REM Series User Manual 70-00121-01-00 Page 1 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 2 All rights reserved October 20, 2009. The information in this document is proprietary to Redline Communications Inc. This document may not in whole or in part be copied, reproduced, or reduced to any medium without prior consent, in writing, from Redline Communications Incorporated.
-
Page 3: Table Of Contents
- Subscriber General Configuration ........29 4.3.12 tr069 - Auto Configuration Servers Support ........30 Appendices ..................31 System Technical Specifications ............31 Subscriber Upgrade Procedure .............. 32 70-00121-01-00 Page 3 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 4 Table 18: CLI - system - System Commands............. 29 Table 19: CLI - tr069 - Auto Configuration Servers Support Commands .... 30 Table 20: Specifications - Indoor Wireless Subscriber Modem ......31 70-00121-01-00 Page 4 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
-
Page 5: Important Safety Notices
Redline Communications assumes no liability for the customer’s failure to comply with these requirements. Important Warning Symbols The following symbols may be encountered during installation or troubleshooting. -
Page 6: Safety Advisories
Operation of any electrical equipment in such an environment constitutes a definite safety hazard. Only qualified maintenance personnel may remove equipment covers to replace internal subassemblies, components, or perform internal adjustments. 70-00121-01-00 Page 6 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 7: Fcc Interference Statement
FCC RF exposure limit and such usage must be prohibited (unless such co-transmission has been approved by FCC in the future). 70-00121-01-00 Page 7 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 8: Europe - Eu Declaration Of Conformity
Hereby, [name of manufacturer], declares that this [type of equipment] is in English compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. 70-00121-01-00 Page 8 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 9 Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse Svenska med de väsentliga egenskapskrav och övriga relevanta bestämmelser som [Swedish] framgår av direktiv 1999/5/EG. 70-00121-01-00 Page 9 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
-
Page 10: Security Features
Manual REM Outdoor Subscriber Security Features Redline Communications wireless systems and provide security setting that can be adjusted by the operator to meet specific applications. Redline recommends these parameters be set according to industry recognized security practices. Considerations include confidentiality, integrity, and availability of information. -
Page 11: Overview
Congratulations on your purchase of the Redline Communications 802.16e Wave 2 outdoor (REM2500M 2.5 GHz or REM3500M 3.5 GHz) wireless broadband personal modem. Redline Communications is a world leader in design and production of wireless broadband systems. The RedMAX 4C subscriber is a complete Mobile WiMAX (IEEE 802.16e-2005) compliant broadband wireless subscriber. -
Page 12: Time Division Duplexing (Tdd)
Guarantees throughput only. Applicable to mission critical Rate Service data applications that are not latency-dependent. Best Effort No guaranteed minimum throughput. Does allow setting a maximum data rate. 70-00121-01-00 Page 12 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 13: Unit Features
Subscriber with integrated antenna. PoE power adapter AC power cord (NA, UK, or EU). Power-over-Ethernet (PoE) power adaptor. Outdoor (ruggedized) Ethernet cable. Universal mounting bracket (assembly Lightning/surge protection. required). 70-00121-01-00 Page 13 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 14: Ethernet Port (And Cable)
Installation Guidelines manual (70-00068-01-XX). Refer to the Redline Limited Standard Warranty and RedCare service agreements. Figure 3: Outdoor Ethernet Cable - Cable Connection 70-00121-01-00 Page 14 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 15: Grounding Connection
Figure 4: Optional Redline-Supplied PoE Power Adaptor Table 5: System - Ethernet Data Port Link/Act LEDs Port Power Output Solid Connected Power is active Blink Not connected Out of range 70-00121-01-00 Page 15 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 16: Cli Commands
From all modes, you can directly display and modify (if applicable) each of the parameters. Enter 'exit' or CTRL-Z to return to root mode. All commands are case- sensitive. 70-00121-01-00 Page 16 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 17: Table 6: Cli - Generic Commands
Statistics for authentication (EAP), Ethernet, and wireless interface. statistics Access the Management Status data structure status System software version settings system Communication between CPE and Auto Configuration Servers (ACS). tr069 70-00121-01-00 Page 17 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 18: Bsidtable - Base Station Id Table
1. A 'Detected BS table reset' log message is generated. 2. An 'Add/Delete detected BS…' log message is generated if a new entry has been added. 3. A frequency scan is initiated. 70-00121-01-00 Page 18 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 19: Buzzer - Antenna Alignment Tool
CPE(collectRadio ->)#>get Press any key to exit ... ♥0.0☺♥0.0☻☺0♥-79.0♦☺0♥0.0☺♥0.0☻☺0 ... End of collecting data time <50 - 10000> Change or display the current data output rate (ms). 70-00121-01-00 Page 19 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 20: Ethtag - Ethernet Tagging
Display the priority assigned to added VLAN tagged packets. value Display the VLAN ID. monitor Continuously display the mode (active), priority, and VLAN ID (value) fields. Press any key to stop updates. 70-00121-01-00 Page 20 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 21: Interface - Ethernet Port And Wireless Settings
1/8. Bandwidth setting determines the FFT size. configcapabilities <authpolicysupport> <openloopsupport> View and modify the wireless interface authentication settings. authpolicysupport <0 | 1> 70-00121-01-00 Page 21 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 22 Bandwidth= 7000 kHz FftSize= 1024 CyclicPrefix= 8 PS FrameSize= 5000 us Note: The bandwidth setting controls the FFT size and cyclic prefix. * Not supported by 1.8 GHz CPE. 70-00121-01-00 Page 22 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
-
Page 23: Loadimage - Download And Activate Software Image
<backup> <restore> Use an FTP server to save and restore the subscriber configuration. set <domain.name> Enter a new realm domain. Example: CPE# realm tier1.com show Display current realm. 70-00121-01-00 Page 23 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 24: Rfconfig - Configure Rf Settings
Actual Tx power (dB). Refer to specifications. txfixedgain <0|1> Tx power scan during network entry. 0 - Enable 1 - Disable txfixedpower <value> Transmitter gain value (dB). This may be a decimal number. 70-00121-01-00 Page 24 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 25 If the scanning results table becomes empty, the scanning process is restarted. 70-00121-01-00 Page 25 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
-
Page 26: Statistics - Display Statistics
-------------------------------------------------- Local-TX | 2581 -------------------------------------------------- Etm-TX | 2581 Dropped=30 interface <eth0> <wman> Display Ethernet or wireless statistics. eth0 <clear><show> Ethernet statistics. clear Reset all counters to zero. 70-00121-01-00 Page 26 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 27 CPE#>statistics packetflows show PACKET FLOW SYNTHESIS ================================================== Module | Input Output Loss (unit=packet) =======================UPLINK===================== ETM-RX | 2649 2649 -------------------------------------------------- UQSS UMSS ======================DOWNLINK==================== -------------------------------------------------- ETM-TX | 2648 2648 70-00121-01-00 Page 27 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
-
Page 28: 4.3.10 Status - Display Status Information
MAC packet data units sent totalpaddingcount ranging requests sent (including initial) totalrngreqcount bursts transmitted totaltxburstcount transmit actual power txactualpower 70-00121-01-00 Page 28 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 29: 4.3.11 System - Subscriber General Configuration
Display system settings. swver Display current software version. Example: Enter the following command to display version: CPE# system show swver Active Software Image= 2.2.5 Passive Software Image= 2.2.4 70-00121-01-00 Page 29 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 30: 4.3.12 Tr069 - Auto Configuration Servers Support
Use an FTP server to save and restore the subscriber configuration. set <enable> Enable and disable tr069 mode. enable <0 | 1> Set tr069 mode. 0 - Disable tr069. 1 - Enable tr069. show Display current tr069mode. 70-00121-01-00 Page 30 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 31: Appendices
20 x 20 x 7.5 cm (8 x 8 x 2.5 in) Weight: 1.8 Kg (4 lb) (does not include mounting bracket) Antenna: Two cross polarized integrated antennas (14 dBi gain) Power Consumption: 5 W Maximum 70-00121-01-00 Page 31 of 34 October 20, 2009 Proprietary Redline Communications © 2009... -
Page 32: Subscriber Upgrade Procedure
Opening FTP connection..Done Downloading image ....................……………… Done Programming update..Done Erasing setup partition. Done. Writing setup partition. Done. Erasing boot block. Done Programming boot block. Done Flash programming complete. SUI#>reboot 70-00121-01-00 Page 32 of 34 October 20, 2009 Proprietary Redline Communications © 2009... - Page 33 User Manual REM Outdoor Subscriber 70-00121-01-00 Page 33 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
- Page 34 302 Town Centre Suite 100 Markham, Ontario Canada L3R 0E8 www.redlinecommunications.com 70-00121-01-00 Page 34 of 34 October 20, 2009 Proprietary Redline Communications © 2009...
