- Page 1 GPS6000-PRO GNSS Time Receiver User Manual Version 1.1...
-
Page 2: Rohs Compliance
GPS6000-PRO, please visit our web site at: For further information and/or to view a copy of the World Time www.worldtimesolutions.com/support.html Solutions Limited Waste Electrical and Electronic Equipment Policy, please visit our web site at: www.worldtimesolutions.com/recycle.html GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... -
Page 3: Scope Of Supply
• 1 x lightning arrester • 1 x 8m antenna coax cable • 1 x 1m arrester coax cable • 1 x 5m output cable • 1 x user manual GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... - Page 4 • GPS6000-OUT-15: 15m (49ft) output cable • GPS6000-OUT-50: 50m (164ft) output cable • GPS6000-OUT-150: 150m (492ft) output cable • GPS6000-PRO-GPS: GPS6000-PRO with GPS only support • GPS6000-PRO-GLONASS: GPS6000-PRO with GLONASS only support GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1...
- Page 5 The multi-strike fast response lightning arrester connects between the antenna and the GNSS decoder. The lightning arrester protects the GNSS decoder and attached systems from damage due to a lightning strike. Figure 2.4 - The lightning arrester GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1...
-
Page 6: System Installation Overview
RG-58C/U coax) CABLE DELAY OFFSET GNSS decoder ANTENNA STATUS GPS6000 - GNSS TIME DECODER Output cable (Belden 9502 / structured cabling) Time server Figure 3.1 - System installation overview GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... -
Page 7: Installing The Antenna
The GPS6000-PRO is supplied as standard with an 8m (26ft) pre-terminated RG-58C/U TNC to TNC coaxial cable for connection to the lightning arrester. Longer antenna cables are optionally available if required. GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... - Page 8 (not supplied) are suitable for the application. Figure 3.3 below details the enclosure bracket fixing dimensions. 2 x 5.5mm fixing points. 81.5mm centre spacing Figure 3.3 - GNSS decoder enclosure mounting dimensions GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1...
-
Page 9: Cable Connections
White / Green Blue Blue White / Blue White / Blue Orange Green White / Brown White / Brown Brown Brown Table 3.2 - RJ45 / 8P8C structured cabling wiring detail GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... - Page 10 16m to cable length add 32m to cable length add 64m to cable length add 128m to cable length Figure 3.4 - The cable delay offset switch bank GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1...
- Page 11 Figure 3.6 - Example 59m cable delay offset A NOTE REGARDING THE CABLE DELAY OFFSET ACCURACY: The GPS6000-PRO advances the time data by 5 nsec for every additional metre added to the cable delay offset value. This 5 nsec per metre value has been chosen as a good approximation to the velocity of propagation for RG-58C/U (at 66%, or 5.05 nsec/m).
-
Page 12: System Operation
GNSS tracking), the computed reference location is stored and the GPS6000-PRO moves to high-accuracy timing mode. In this mode, the GPS6000-PRO is able to provide time data accurate to within 30 nsec of UTC. Note that if your GPS6000-PRO has previously performed a full self-survey and the location has not changed, a new self-survey will not be performed. -
Page 13: Synchronisation Status
The GPS6000-PRO fully integrates with your time server, providing real time diagnostics and active antenna monitoring. Please refer to the user manual for your time server for further details. GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... - Page 14 Operating temperature: -40ºC to +80ºC Dimensions: 78 x 66mm (3.05” x 2.61”) Antenna mount: Antenna mount: 105mm (4.13”) stainless steel antenna mount Lightning arrester: Lightning arrester: Multistage, multi-strike fast response GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1...
-
Page 15: Appendix A: Specifications
25m (82ft) antenna cable GPS6000-OUT-15: 15m (49ft) output cable GPS6000-OUT-50: 50m (164ft) output cable GPS6000-OUT-150: 150m (492ft) output cable GPS6000-PRO-GPS: GPS6000-PRO with GPS only support GPS6000-PRO-GLONASS: GPS6000-PRO with GLONASS only support GPS6000-PRO - GPS Time Receiver - User Manual - Version 1.1... - Page 16 World Time Solutions Limited The Gatehouse, Gatehouse Way, Aylesbury, Buckinghamshire, HP19 8DB, United Kingdom +44 (0) 1296 331428 - sales@worldtimesolutions.com www.worldtimesolutions.com...
