IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important safety instructions. Read all safety and operating
instructions before operating the uninterruptible power systems (UPS). Adhere to all
warnings on the unit and in this manual. Follow all operating and user instructions. This
equipment can be operated by individuals without previous training.
This product is designed for commercial/industrial use only. It is intended for use with lift
support and other designated "critical" devices. Maximum load must not exceed that shown
on the UPS rating label. The UPS is designed for data processing equipment. If uncertain,
consult your dealer or local representative.
This UPS is designed for use on a properly grounded (earthed), 220/230/240VAC, 50 or
60Hz supply. The factory default setting is 220VAC/50Hz. Installation instructions and
warning notices are in this manual.
The UPS 06-20@220/230/240VAC is designed for use with a three-wire input (L,N,G).
WARNING
THE BATTERY CAN PRESENT A RISK OF ELECTRICAL SHOCK AND
HIGH SHORT CIRCUIT CURRENT. FOLLOWING PRECAUTIONS
SHOULD BE OBSERVED BEFORE REPLACING THE BATTERY.
Wear rubber gloves and boots.
Remove rings, watches and other metal objects.
Use tools with insulated handles.
Do not lay tools or other metal objects on the batteries.
If the battery is damaged in any way or shows signs of leakage, contact your local
representative immediately.
Do not dispose of batteries in a fire. The batteries may explode.
Handle, transport and recycle batteries in accordance with local representative.
WARNING
ALTHOUGH THE UPS HAS BEEN DESIGNED AND MANUFACTURED
TO ENSURE PERSONAL SAFETY, IMPROPER USE CAN RESULT IN
True Online 6-20k UPS User Manual
Important Safety Instructions
1
Advertisement
Table of Contents
Related Manuals for INVT HT1106S
Summary of Contents for INVT HT1106S
- Page 1 Important Safety Instructions IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important safety instructions. Read all safety and operating instructions before operating the uninterruptible power systems (UPS). Adhere to all warnings on the unit and in this manual. Follow all operating and user instructions. This equipment can be operated by individuals without previous training.
-
Page 2: Important Safety Instructions
Important Safety Instructions ELECTRICAL SHOCK OR FIRE. TO ENSURE SAFETY, OBSERVE THE FOLLOWING PRECAUTIONS: Turn off and unplug the UPS before cleaning it. Clean the UPS with a dry cloth. Do not use liquid or aerosol cleaners. Never block or insert any objects into the ventilation holes or other openings of the UPS. -
Page 3: Table Of Contents
Contents CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..................... 1 1. ELECTROMAGNETIC COMPATIBILITY ..................3 2. INTRODUCTION ..........................4 3. SYSTEM DESCRIPTION ........................7 3.1 T (TVSS) EMI/FRI F ........7 RANSIENT OLTAGE URGE UPPRESSION ILTERS 3.2 R (PFC) C ............... 7 ECTIFIER OWER ACTOR ORRECTION... - Page 4 Contents 7.2 P ........................23 ARALLEL PERATION 7.3 MAINTENANCE BYPASS OPERATION MODE ............... 24 8. BATTERY MAINTENANCE ......................27 9. NOTES FOR BATTERY DISPASAL AND REPLACEMENT PROCEDURES ......28 9.1 B ........................28 ATTERY ISPOSAL 9.2 B ..................28 ATTERY EPLACEMENT ROCEDURES 10.
-
Page 5: Electromagnetic Compatibility
Introduction 1. ELECTROMAGNETIC COMPATIBILITY * Safety IEC/EN 62040-1-1 * EMI Conducted Emission..IEC/EN 62040-2 Category C3 Radiated Emission....IEC/EN 62040-2 Category C3 *EMS ESD........IEC/EN 61000-4-2 Level 4 RS........IEC/EN 61000-4-3 Level 3 EFT........IEC/EN 61000-4-4 Level 4 SURGE......IEC/EN 61000-4-5 Level 4 Low Frequency Signals....:IEC/EN 61000-2-2 Warning: This is a product for commercial and industrial application in the second environment-installation restrictions or additional measures may be needed to prevent disturbances. -
Page 6: Introduction
Introduction 2. INTRODUCTION Congratulations on your choice of the UPS uninterruptible power system(UPS), the UPS comes in nominal power ratings of 6000VA,10000VA,15000VA and 20,000VA. It is designed to provide conditioned power to microcomputers and other sensitive electronic equipment. When it is generated, alternating current is clean and stable. However, during transmission and distribution it may be subject to voltage sags, spikes and complete power failure that may interrupt computer operations, cause data loss and even damage equipment. - Page 7 Introduction 6K long backup model 10K long backup model 6K standard model 10K standard model 15K,20K long backup model Fig 2. Rear View True Online 6-20k UPS User Manual...
- Page 8 Introduction Function instructions: SNMP card slot Dry contactor slot USB port RS232 Parallel ports Fans Reserved customer function External battery connector. Optional for standard model. 10. Internal maintenance bypass 11. Input breaker 12. Cable entry protector 13. Terminal cover True Online 6-20k UPS User Manual...
-
Page 9: System Description
System Description 3. SYSTEM DESCRIPTION 3.1 Transient Voltage Surge Suppression (TVSS) and EMI/FRI Filters These UPS components provide surge protection and filter both electromagnetic interference (EMI) and radio frequency interference (RFI). They minimize any surge or interference present in the utility line and keep the sensitive equipment protected. 3.2 Rectifier/Power Factor Correction (PFC) Circuit In normal operation, the rectifier/power factor correction (PFC) circuit converts utility AC power to regulated DC power for use by the inverter while ensuring that the waveform of the... -
Page 10: Battery Charger
System Description 3.4 Battery Charger The battery charger utilizes energy from the utility power and precisely regulates it to continuously float charge the batteries. The batteries are being charged whenever the UPS is connected to utility power. 3.5 DC-to-DC Converter The DC-to-DC converter utilizes energy from the battery system and raises the DC voltage to the optimum operating voltage for the inverter. -
Page 11: Product Specification And Performance
Production Specification and Performance 4. PRODUCT SPECIFICATION And PERFORMANCE 4.1 Model Description This manual is applicable to the following models: Model No. Type Standard 10KS 10KL Long backup time 15KL 20KL “L” Model: Long backup time 4.2 Product Specification and Performance 1. - Page 12 Product Specification and Performance Output Voltage Power Frequency Distortion Overload capacity Crest ratio Regulation Factor tolerance. 110% load: transfers to Bypass mode after minutes THD<1% 130% load: transfers to ±0.1% Full load Bypass mode after ±1% 0.9 lag normal (Linear minute maximum Load)
-
Page 13: Installation
Installation 5. INSTALLATION The system should be installed and wired only by qualified electricians in accordance with applicable safety regulations. ° ° ° NOTICE：UPS operation in sustained temperature outside the range of 15-25 C (59 reduces battery life. 5.1 Unpacking and Inspection 1) Unpack the packaging and check the package contents. - Page 14 Installation other insulated wire which complies with AWG Standard for the UPS input and output wirings. 4) For 15kL/20kL UPS, it is recommended to select the UL1015 6AWG(25mm ) wire or other insulated wire which complies with AWG Standard for the UPS input wires and output wirings.
- Page 15 Installation For 15KL/20KL,connect the input 3 line wires to input A/B/C separately as fig.4. Or connect 1 input wire to input C. (a）Cables entry (b) Wiring connection Fig 4. Input and Output Terminal Block Wiring Diagram of 15KL/20KL NOTICE：You must make sure that the input and output wires and the input and output terminals are connected tightly.
-
Page 16: Operating Procedure For Connecting The Long Backup Time Model Ups With The
Installation 9） After having completed the installation, make sure the wiring connection is correct. 10） Please install the output breaker between the output terminal and the load, and the breaker should with leakage current protective function if necessary. 11) To connect the load with the UPS, please turn off all the loads first, then perform the connection and finally turn on the loads one by one. -
Page 17: External Battery
Installation charging. 1. The nominal DC voltage of external battery pack is 192VDC. Each battery pack consists of 16 pieces of 12V maintenance free batteries in series. To achieve longer backup time, it is possible to connect multi-battery packs, but the principle of “same voltage, same type”... - Page 18 Installation Fig.5 communication cables connection Strictly follow the stand-alone wiring requirement to perform the input wiring of each UPS. 3) Connect the output wires of each UPS to an output breaker panel. 4) Each UPS need an independent battery pack. 5) Please refer to the wiring diagram in the next page, and opt suitable breaker.
- Page 19 Installation (a)Wiring Diagram of 6K(L/S)/10K(L/S) True Online 6-20k UPS User Manual...
- Page 20 Installation UPS2 output breaker UPS2 battery breaker UPS2 input breaker UPS1 output breaker UPS1 battery breaker UPS1 input breaker (b)Wiring Diagram of 15KL/20KL Fig.6 wiring diagram True Online 6-20k UPS User Manual...
- Page 21 Installation Operation 1) To perform the general operation, follow the stand-alone operating requirement. 2) Startup: The units transfer to INV mode simultaneously as they start up sequentially in Line mode. Shutdown: the units shut down sequentially in INV mode. When the last one completes the shutdown action, each unit will shut down the inverter simultaneously and transfer to Bypass mode.
-
Page 22: Controls And Indicators
Controls and Indicators 6. CONTROLS And INDICATORS Fig.8 Display Panel Description of Panel Controls Description 1.Press on/off to start inverter when rectifier is OK NOTE Not available when UPS is set in automatically start mode 2.Press on/off directly when there is no main input, press again ON/OFF to start UPS 3. - Page 23 Controls and Indicators flicker--rectifier starting, red--rectifier fault, flicker--rectifier alarm, dark—rectifier is not working Inverter indicator: green--inverter normal, green flicker--inverter is starting or tracking with bypass(ECO), red—inverter fault and load is not on inverter, red flicker—inverter fault and load is on inverter, dark—inverter is not working Bypass indicator: green—bypass is normal, dark—UPS is in normal mode and bypass is normal, red—bypass fault, red...
- Page 24 Controls and Indicators Display Function Submenu Output information: Output Voltage, current, frequency, PF information Load information: Active power, apparent power, percent Alarms, S-code, firmware version, system Status of UPS information Set: language, contrast, communication set(SNT, Modbus), Modbus set Set and function Function: function 1(transfer to bypass/escape, fault clear, mute on/off), function 2(battery test, maintenance test, stop test)
-
Page 25: Operation
Operation 7. OPERATION 7.1 Operation Mode 1. Turn on the UPS in normal mode 1) After you make sure that the power supply connection is correct, and then close the battery breaker (this step only for long backup time model), after that close the input breaker. -
Page 26: Maintenance Bypass Operation Mode
Operation This UPS system has parallel machine function, if you want to add single machine to parallel system, please follow operational process of joining new machine; if you must remove UPS, please follow operational processes of removing parallel machine. 2. How to install a new parallel UPS system: 1) Before installing a new parallel UPS system, user need to prepare the input and output wires, the output breaker, and the parallel cables. - Page 27 Operation To transfer the UPS to Maintenance Mode, the following procedures should be followed. Check the status before the Maintenance Mode. Before transferring to the Maintenance Mode, the circuit breakers (CB) are in the following status: Input and Output are closed (in the on position); the Maintenance Bypass is open, as it is shown in the figure above;...
- Page 28 Operation the UPS transfers to Bypass Mode with warning and wait until the LED indicator for bypass goes green (b) Close the Maintenance Bypass CB; (c) Open the CB for output and input and disconnect the battery( For the standard UPS type , pull out Battery terminal of positive and negative ;...
-
Page 29: Battery Maintenance
True Online 6-20k UPS User Manual Battery Maintenance 8. BATTERY MAINTENANCE The UPS only requires minimal maintenance. The batteries used for standard models are value regulated, sealed lead-acid, maintenance free battery. When being connected to the utility power, whether the UPS is turned on or not, the UPS keeps charging the batteries and also offers the protective function of overcharging and over-discharging. -
Page 30: Notes For Battery Dispasal And Replacement Procedures
Battery Maintenance 9. NOTES for BATTERY DISPASAL and REPLACEMENT PROCEDURES 9.1 Battery Disposal Before disposing of batteries, remove jewelry, watches and other metal objects. Use rubber gloves and boots, use tools with insulated handles. If it is necessary to replace any connection cables, please purchase the original materials from the authorized distributors or service centers, so as to avoid overheat or spark resulting in fire due to insufficient capacity. -
Page 31: Troubie Shooting
Trouble Shooting 10. TROUBIE SHOOTING This section describes checking the UPS’s status. This section also indicates various UPS symptoms a user may encounter and provides a troubleshooting guide in the event the UPS develops a problem. Use the following information to determine whether external factors caused the problem and how to remedy the situation. - Page 32 Trouble Shooting Seq. Items Solution Reserved Reserved Reserved Input phase Fault over current Check rectifier IGBT Input phase broken, DC bus is shorted, or Fault over current IGBT drivers are lost, input voltage display is wrong Input phase Fault over current Output voltage Check if inverter IGBT is...
- Page 33 Trouble Shooting Seq. Items Solution installed. Positive bus over Fault UPS requires service voltage Negative bus over Fault UPS requires service voltage Fan Fault Fault At least one of fans fail. Reserved Reserved Positive Fault UPS requires service under voltage Negative Fault UPS requires service...
- Page 34 Trouble Shooting Seq. Items Solution Bypass SCR or Fault UPS requires service. relay fault Reserved Reserved frequency Check bypass input Fault over track range frequency is abnormal Reserved Reserved Over load time Fault Reserved Reserved shutdo Manual shutdown normal INV protect Fault Transfer times...
- Page 35 Trouble Shooting Seq. Items Solution Fault shorted or opened. Reserved Parallel Check whether parallel Fault connection fault connection cable disconnect. Reserved Reserved Reserved Shutdown open output breaker, check if load is Output shorted Fault effective or short internally, check if output connector is shorted.
-
Page 36: Annex A. Rated Parameters Set On Lcd
Rated Parameters Set on LCD Annex A. Rated Parameters Set on LCD 1. Power on LCD 2. Press button together for 3 seconds, enters in rated setting menu as below 3. Press button “ENTER” to activate setting function as below. Shadow means the current parameter can be set now. - Page 37 Rated Parameters Set on LCD 6. Press “ENTER” button to confirm output voltage selection and activate frequency setting. Press to select the rated frequency. 50Hz and 60Hz are available for selection. 7. Press “ENTER” button to confirm frequency selection, and the current parameters are shown on LCD as below 8.
-
Page 38: Annex B. Inteligent Slot
Rated Parameters Set on LCD Annex B. Intelligent Slot (a) DB9 connector (b)Phoenix Terminal Intelligent Slot Description： Pins Function Denotation UPS Faults Low Voltage: UPS Fault Normal warning Low Voltage: UPS unusual Far-away cut off Utility usual：UPS cut off Rectifier and Inverter; Battery Mode: cut off the whole system High Voltage: Far-away cut off the machine Power Supply... -
Page 39: Annex C. Epo
Rated Parameters Set on LCD Annex C. EPO EPO is used to quickly cut off machine under emergency, the function is triggered by customer’s connector. By shorting common-open point NO with +24V, EPO function is effective. Far-away EPO connector denotation: Pins Name Denotation...
