ATC SUNRAY Plus Instruction For Use, Installation And Assembly

Hide thumbs Also See for SUNRAY Plus:
Table of Contents

Advertisement

Quick Links

SUNRAY Plus
Electric Heaters
INSTRUCTIONS FOR USE, INSTALLATION AND ASSEMBLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUNRAY Plus and is the answer not in the manual?

Questions and answers

RYSZARD
June 3, 2025

I NEED WEELS FOR ATC SUNRAY

0

Related Manuals for ATC SUNRAY Plus

Summary of Contents for ATC SUNRAY Plus

  • Page 1 SUNRAY Plus Electric Heaters INSTRUCTIONS FOR USE, INSTALLATION AND ASSEMBLY...

  • Page 3: Table Of Contents

    Contents 1. Location 2. Electric Connection 3. Mounting 4. Operation 4.1. Key Pad Functions 4.2. LCD Display 4.3. Setting 4.4. Operating Mode Selection 4.5. Configuration 4.6. Automatic Mode 4.7. Programming Function 4.8. Program Creation 4.9. Program Copy Function 4.10. Time Adjustment 4.11.

  • Page 4: Location

    Thank you for choosing SUNRAY PLUS heaters, with their modern design, state-of-the-art technology, great reliability and quality construction. ATC SUNRAY PLUS heaters and all their materials and components have passed strict controls to ensure their quality. Before starting your heater, please read these instructions carefully as they will ensure the correct working order of the appliance with the utmost features and to your fullest satisfaction.

  • Page 5: Mounting

    (Note the 585mm dimension is from the skirting and not the floor) nº Dimensions Model supports SP500 Sunray Plus 500W SP750 Sunray Plus 750W SP1000 Sunray Plus 1000W SP1500 Sunray Plus 1500W SP1800 Sunray Plus 1800W (*)The first number corresponds to the number of plastic brackets on which the radiator hangs and the second number corresponds to the number of metal locking brackets which fixes the radiator to the wall.

  • Page 6: Operation

    4. OPERATION 4.1. Keypad functions The keypad is made up of 4 buttons. ode / Program button (+) button 0h 2 4 6 8 10 12 14 16 18 20 22 24 (-) button Start / Stop button Press the button quickly to switch the radiator on and off and keep the button held down to adjust the “Economy”...

  • Page 7: Setting

    4.3. Setting The “Comfort” temperature can be adjusted in 0.5ºC intervals. This is displayed by pressing the (+) or (-) button. If the (+) or (-) button is kept pressed down for more than 1 sec. the temperature setting can be increased or decreased in 0.5ºC intervals every second.

  • Page 8: Configuration

    4.5. Configuration. To enter Configuration mode: Press the button for 5 seconds. Each time it is pressed after this it will go to the next parameter. If no action is taken on these parameters for 120 seconds, it will return to normal display mode.

  • Page 9: Automatic Mode

    4.6. Automatic mode Display example: Characteristics: The screen display informs users as to whether the appliance is in automatic mode and displays the current program. The day of the week is displayed on the left of the screen and the current time flashing at the bottom.

  • Page 10: Program Copy Function

    The adjustment is made for each day. Press button to go from one day to the next, which is indicated by the figures 1 to 7 located on the left of the screen. Press quickly to go to the next day and save the program.

  • Page 11: Characteristic Table

    This heating apparatus holds a specific amount of special oil. Repairs where it is necessary to open the oil tank must only be made by the manufacturer or ATC. ATC should be contacted in case of any oil leakage A Fused Spur must be included in the wiring to the heater...
