Summary of Contents for Green Point igh
- Page 2 Green Point products are constructed with careful attention to detail, using only h quality materials, assuring peak performance over time.
-
Page 3: Read Before Installing
4. The igh switch requires a neutral wire for operation. 5. It is recommended to use a non-metallic wall plate with the igh switch. - Page 4 10. Do not paint on the switch. 11. Operate between temperatures of -10 °C and 50 °C. 12. The igh switch may feel warm to the touch during normal operation. 13. Shut OFF power through the main circuit breaker when connecting or disconnecting lights or appliances.
-
Page 5: General Product Description
The system is composed of 5 main components: Smart Switch Sensor Keypad IR Bridge Internet Gateway System Connectivity Autonomous Room Autonomous Room Thin Gateway Client Dimmer Sensor Switch Sense Switch Shutter Keypad Switch Power Switch Internet network Igh RF protocol Ring... -
Page 6: Key Features
Functions Key features: Automated functionalities Integrated scheduler (up to 16 schedulers) Remote control via other products Manual control with the front touch panel LED indicators Operating Modes There are 3 operating modes, Automatic, Eco and Manual, that can be toggled manually, remotely or in accordance with 16 preconfigured schedulers, allowing maximum adaptation to the user’s lifestyle. - Page 7 Internal Capabilities RF transceiver capabilities: The internal transceiver works on ISM Band (433.050 - 434.790 MHz). The transceiver communication range is up to 10 m depending on the number of walls in the way. Real time power consumption metering: The measurement of the power consumption is done via DSP - Digital Signal Processing.
- Page 8 Switch Power Specification Dimmer Switch – IGHH: 230V – 50Hz 400W/360VA Maximum power per gauge 600W The Dimmer Smart Switch is designed only for use with permanently installed lighting fixtures. Do not use it to control motorized appliances or receptacles. It can be used as dimmer for any approved dimmable lights or as a regular switch for non- dimmable light.
-
Page 9: Installation Instructions
Installation Instructions SHOCK HAZARD! Turn OFF the power to the branch circuit at the circuit breaker in your electrical service panel. Ensure power is OFF before you install this device. All wiring connections must be made with the POWER OFF to avoid personal injury... - Page 10 5. Insert the Switch into the switch box, being careful not to pinch or crush wires. 6. Mount the wall plate. 7. Turn ON the power to the circuit in the fuse box or circuit breaker and test the system. **This switch may be used in new installations or to replace an existing wall switch.
-
Page 11: Assembly Diagram
Assembly Diagram Wall Mount Switch installation You can insert/extract the switches from the front, facilitating the assembly and wiring operations even when the frame is fixed on the box. The switch can be removed from the frame by means of a screwdriver. -
Page 12: Dimmer Switch
Dimmer Switch – IGHH Description of terminals Electric Wires Connection Diagram 1 Neutral Load Line Neutral Load Line Typical Dimmer Wiring Schematic Diagram 2... - Page 13 Shutter Switch – IGTH Description of terminals Electric Wires Connection Diagram 1 Neutral Load Up Down Typical Shutter Wiring Schematic Diagram 2...
- Page 14 Power Switch – IGPH Description of terminals Electric Wires Connection Diagram 1 Line Load Neutral Typical Power Wiring Schematic Diagram 2...
- Page 15 Sense Switch – IGSH Description of terminals Electric Wires Connection Diagram 1 Line Load Neutral Typical Sense Wiring Schematic Diagram 2...
- Page 16 – IGXX Alternative Switch Description of terminals Electric Wires Connection Diagram 1 Neutral Load Line Neutral Load Line Typical Alternative Switch Wiring Schematic Diagram 2...
-
Page 17: Advanced Operations
Operating Instruction The switch is operated with touch technology. Touching the front area of the switch activates the commands. LED Indicators Blue – Power Red – TX/Error Green – Auto Orange – Eco Red- RCV White- Schedulers ON Advanced Operations ... - Page 18 Dimmer Switch- IGHH ON/OFF A short touch on the top/bottom area of the switch turns ON/OFF the lights. Dimming A long touch on the top/bottom area of the switch adjusts the light intensity. Modes Touching the middle area of the switch toggles between the modes.
- Page 19 Shutter Switch- IGTH UP/DOWN A short touch on the top/bottom area of the switch opens/closes the shutters/blinds. Precise Activation A long touch on the top/bottom area of the switch adjusts the shutters to an exact position. Modes Touching the middle area toggles between the modes.
- Page 20 Power Switch- IGPH ON/OFF A touch on the top/bottom area of the switch turns ON/OFF the appliance. Modes Touching the middle bottom area of the switch toggles between the modes. Sense Switch- IGSH ON/OFF A touch on the top/bottom area of the switch turns ON/OFF the appliance.
- Page 21 Alternative Switch - IGXX Touch panels of the alternative switch will be the same as the primary switch.
-
Page 22: Specifications
Signal (Frequency): ISM BAND (433.050 - 434.790 MHz) WARRANTY Green Point Products warrants this product to be free from manufacturing defects for a period of one year from the original date of consumer purchase. This warranty is limited to the repair... -
Page 23: Regulatory Compliance
Regulatory Compliance The IGHH, IGTH, IGSH, IGPH, IGXX – switch units have been tested and found to comply with specifications for CE marking and standards per EMC and radio communications and safety Compliance. Safety EN60669-2-1: 2004 + A1: 2009 + A12: 2010 + AC: 2007 Switches for household and similar fixed electrical installations - Part 2-1: Particular...
