I
NSTALLATION

Installation

Television Location

Optional Cable Connections

AC Power Supply Cord

Cable / Antenna

4
This unit is intended to be used with an optional stand or entertainment
center. Consult your dealer for available options.
r
Avoid excessive sunlight or bright lights, including reflections.
r
Keep away from excessive heat or moisture. Inadequate ventilation
may cause internal component failure.
r
Fluorescent lighting may reduce Remote Control transmitting range.
r
Avoid magnetic equipment, including motors, fans, or external speakers.
Shielded audio and video cables should be used between components. For
best results:
r
Use 75-ohm coaxial shielded cables.
r
Use appropriate input and output connectors that match your
component connectors.
r
Avoid long cables to minimize interference.
CAUTION: TO PREVENT
MATCH WIDE BLADE OF PLUG TO WIDE SLOT OF
AC OUTLET AND FULLY INSERT. DO NOT USE A
PLUG WITH A RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADE CAN BE FULLY INSERTED TO
PREVENT BLADE EXPOSURE.
PROTECT POWER CORDS FROM BEING WALKED ON, ROLLED OVER,
CRIMPED, BENT
CONVENIENCE RECEPTACLES, AND THE POINT WHERE THEY EXIT
FROM THE APPARATUS.
For proper reception, either a cable or antenna connection is required.

Cable Connection

Connect the cable
cable company.
Note: A cable converter box may be required for
proper reception. Check with your local cable
company for compatibility requirements.

Antenna Connection

• For proper reception of VHF/UHF channels, an external
antenna is required. For best reception an outdoor antenna
is recommended.
• Antenna Mode must be set to TV.
Note:
Cable Mode is preset at the factory.
Antenna users must change to TV Mode
in the SETUP Menu.
ELECTRIC
OR PINCHED, PARTICULARLY
supplied by
SHOCK,
Polarized plug
AT
your local
Incoming Cable from
Cable Company
75 Ohm VHF/UHF
on back of TV
Incoming Cable from
Home Antenna
PLUGS,
