- Page 1 Microwave Oven User Manual Model：FMWO 32 NH I...
-
Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation. Specifications FMWO 32 NH I Model: 230V~50Hz Rated Voltage: Rated Input Power(Microwave):... -
Page 4: Important Safety Instructions Warning
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 1. Warning: Liquids and other foods must not be heated in sealed containers since they are liable to explode. - Page 5 8. When heating food in plastic or paper containers,keep an eye on the oven due to the possibility of ignition. 9. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames. 10.
- Page 6 18. Do not use this oven near water, in a wet basement or near a swimming pool. 19. The temperature of accessible surfaces may be high when the appliance is operating. The surfaces are liable to get hot during use.Keep cord away from heated surface, and do not cover any vents on the oven.
- Page 7 28.Steam cleaner is not to be used. 29.During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. 30.Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a temperature-sensing probe.) 31.WARNING: The appliance and its accessible parts become hot during use.Care should be taken to avoid...
-
Page 8: To Reduce The Risk Of Injury To Persons Grounding Installation
To Reduce the Risk of Injury to Persons Grounding Installation DANGER Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death.Do not disassemble this appliance. WARNING Electric Shock Hazard Improper use of the grounding can result in electric shock.Do not plug into an outlet until appliance is properly installed and grounded. - Page 9 CLEANING Be sure to unplug the appliance from the power supply. 1. Clean the cavity of the oven after using with a slightly damp cloth. 2. Clean the accessories in the usual way in soapy water. 3. The door frame and seal and neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.
- Page 10 UTENSILS CAUTION Personal Injury Hazard It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven."...
-
Page 11: Materials You Can Use In Microwave Oven
Materials you can use in microwave oven Utensils Remarks Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls. -
Page 12: Materials To Be Avoided In Microwave Oven
Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may trimmed utensils cause arcing. -
Page 13: Setting Up Your Oven
SETTING UP YOUR OVEN Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray Turntable ring assembly Instruction Manual A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window... - Page 14 Installation and connection 1.This appliance is only intended for domestic use. 2.This oven is intended for built-in use only.It is not intended for counter-top use or for use inside a cupboard. 3. Please observe the special installation instructions. 4.The appliance can be installed in a 60cm wide wallmounted cupboard(at lease 55cm deep and 85cm off the floor).
-
Page 15: Installation Instructions
Installation Instructions Please Read the Manual Carefully Before Installation SCREW TRIM-KIT PLASTIC COVER Please Note Electrical connection The oven is fitted with a plug and must be only connected to a properly installed earthed socket. In accordance with the appropriate regulations, the socket must only be installed and the connecting cable must only be replaced by a qualified electrician. -
Page 16: Built-In Furniture
BUILT-IN FURNITURE It is advisable to physically measure the actual product dimensions before cutting out for installation. The built-in cabinet shall not have a rear wall behind the appliance. Please measure the actual product before cutting out for installation. The dimensions provided below are for proudmount cut outs. -
Page 17: Install The Oven
INSTALL THE OVEN Do not trap or kink the power cord. Make sure that the oven is installed in the center of the cabinet. Trim-kit plastic cover Screw Installation Hole 2. Open the door; fix the oven to the cabinet with screw at the installation hole of trim kit.Then fix the trim-kit plastic cover to the installation hole. -
Page 18: Operation Instructions
Operation Instructions This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking. 1.Clock Setting 1) In waiting state, press " CLOCK/KITCHEN TIMER" once, "00:00" displays. Hour figures flash. 2) Turn " " to adjust the hour figures, the input time should be within 0--23. 3) Press "... - Page 19 3. Gri l l Co o k i n g 1) Press the "GRILL /COMB I." key once, and "G-1" displays. Press "START/+30SEC./CONFIRM " to confirm. Turn " " to adjust the cooking time. (The time setting should be 0:05- 95:00.) Press "...
- Page 20 1) Press the "CONVE CTION" key once 2) The convection temperature displays The temperature can be chosen from 150 degrees to 240 degrees. 3) Press the " START/+30SEC./CONFIRM " to confirm the temperature. 4) Press the " START/+30SEC./CONFIRM " to start preheating.When the preheating temperature arrives, the buzzer will sound twice to remind you to put the food into the oven.
-
Page 21: Kitchen Timer
5) Press "STA RT/+30SEC./CONFIRM" to confirm; 6) Turn " " to adjust the cooking time of 7 minutes; 7) Press "STA RT/+30SEC./CONFIRM" to start cooking. 8. K ITCHEN TIMER 1) In waiting state, press " KITCHEN TIMER/CLOCK " once, "00:00" displays. 2) Turn "... - Page 22 Auto menu Chart Menu Power Weight(g) Display AUTO REHEAT 100% 1(approx.230g) 100% approx 460g POTATO approx 690g 100% MEAT 100% VEGETABLE FISH 50(with cold water 450g) 100(with cold water 800g) PASTA 150(with cold water 1200g) 200ml 400ml 100% SOUP 600ml Conve.
- Page 23 11. Defrost by W.T. 1) Press "WEIGHT/TIME DEFROST" pad once, the oven will display "d-1". 2) Turn " " to select the weight of food. At the same time, "g" will lights, The weight should be -2000g. 3) Press "STA RT/+30SEC./CONFIRM" key to start defrosting. 12.
-
Page 24: Troubleshooting
Trouble shooting Normal Radio and TV reception may be interfered when microwave oven operating. It is similar to the Microwave oven interfering interference of small electrical appliances, like TV reception. mixer, vacuum cleaner, and electric fan. It is normal. In low power microwave cooking, oven light may Dim oven light. - Page 25 Unpack the packing box, and check the packing list grill wire (PCS) glass tray(PCS) roller ring(SET) screw(PCS) screw cover(PCS) user manual(PCS)
- Page 28 Franke Kitchen Systems Services E-mail:KS-AsiaExport.cn@franke.com www.franke.com...
