NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Chapter 1. Unpacking Information 1.1 Check List Thank you for choosing Netsys NV-720S Before installing the router, please verify the contents inside the package. Package Contents: 1 x Managed VDSL2 CPE 1 x QR code for user’s...
• Do not install phone lines strapped together with AC power lines, or telephone office line with voice signal. • Avoid installing this device with radio amplifying stations nearby or transformer stations nearby. • Please note that the voice spectrum allowed by the NV-720S internal splitter is 0 KHz ~ 120 KHz.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 2.3 General Rules Before making any connections to the router, please note the following rules: • Ethernet Port (RJ-45) All network connections to the router Ethernet ports must be made using Category 5 UTP or above for 100 Mbps, Category 3, 4 UTP for 10Mbps.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 2.4 Connecting the Router The router has four Ethernet ports which support connection to Ethernet operation. The devices attached to these ports must support auto-negotiation /10Base-T / 100Base-TX unless they will always operate at half duplex. Use any of the Ethernet ports to connect devices such as Monitor systems, Servers, Switches, bridges or routers.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 2.5 Connecting the RJ-11 / RJ-45 Ports The line port has 1 connector: RJ-11 . It is used to connect with NV-700L (CO) using a single pair phone cable to NV-720S (CPE) bridge side (point to point solution).
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 2.6 VDSL2 Application The router’s line port supports up to 3km for data service across existing phone wiring. It is easy-to-use and do not requires installation of additional wiring. Every modular phone jack in the home can become a port on the LAN. Networking devices can be installed on a single telephone wire that can be installed within a suitable distance.
Page 15
NV-720S is equipped with a wireless LAN interface compliant with the standard IEEE 802.11 protocol. To boost its performance even further, the NV-720S is also loaded with an advanced wireless technology to lift up the data rate up to 300 Mbps. You can...
Page 16
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 What is WEP? Wired Equivalent Privacy (WEP) is an easily broken security algorithm for IEEE 802.11 wireless networks. Introduced as part of the original 802.11 standard ratified in September 1999, its intention was to provide data confidentiality comparable to that of a traditional wired network.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Chapter 3. Hardware Description This section describes the important parts of the wireless VDSL2 router. It features the front and rear panel. Wireless Router Outward...
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 3.1 Front Panel The front panel provides a simple interface monitoring of the router. (Figure 3.1) shows the front panel of the NV-720S Figure 3.1 NV-720S Front Panel 3.2 Front Indicators The wireless router has Nine LED indicators.
Page 19
Notes: 1. It is normal for the connection between two Routers to take up to 3 minutes, due to NV-700L/NV-720S to establish a link mechanism in auto-negotiation, that detects and calculates CO and CPE both PBO and PSD level, noise levels and other arguments for getting a better connection.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 3.3 Rear Panel The rear panel provides the physical connectors connected to the power adapter and any other network device. (Figure 3.2) shows the rear panel of the NV-720S. Figure 3.2 Rear Panel...
Page 21
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 And the table shows the description. (Table 3-2) Table 3-2 Description of the router rear connectors Connectors Type Description The reset button allows users to reboot the VDSL2 or load the default settings.
Page 22
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Before installing power and device, please read and follow these essentials: Use separate paths to route wiring for power and devices. If power and device wiring paths must cross, make sure the wires are perpendicular at the intersection point.
Chapter 4. Configuring the NV-720S via Web Browser The NV-720S provides a built-in HTML based management interface that allows configuration of the NV-720S via Internet Browser. Best viewed using Chrome or Firefox browsers. In order to use the web browser to configure the device, you may need to allow: •...
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 4.1 BASIC Setup Login webpage The IP address is 192.168.1.1 , username and password are admin. Figure 4.1 Login Password...
Page 25
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Display status The status page displays some information. When the device is running. For example: Device Information:...
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Restore Default Settings Select “Management”->”Settings” ->”Restore Default” If Click “Restore Default Settings”, the device will reboot in 10 seconds. Warning: The settings will restore the factory defaults expect WAN connection and TR069 Settings.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 4.2 WAN/TR069 Setup Create ATM+BRIDGE WAN Connection WAN Service page, HGW has three mode: ATM/PTM/ETH, each compare ADSL/VDSL/GE_WAN, according different network to setup. For example, below pic is ATM mode...
Page 32
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Create PTM +PPPoE WAN Router Connection WAN Service page, DSL mode chooses PTM, select Route+PPPoE, setup PPPoE user account and password, choose Service Type is TR069_Internet, this WAN Connection can suffer internet and can use TR069.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 4.3 Wi-Fi Setup Basic Setup After login choose Basic Setup >Wireless > Basic Configuration 2.4GHz, You can see 2.4GHz configuration display right part. Make sure Enable Wireless is enable, and you can change SSID if you want name unique SSID.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Security Setup Choose Basic Setup >Wireless > Security Setting, you can change security type in this page.
Page 38
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 SSID1 to SSID4 is setting 2.4GHz Wi-Fi, please confirm SSID number in here is same with Basic Configuration page.
Page 39
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 In Authentication this label, you can change security type. Normally, test Wi-Fi thought put would not set any security type.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Advanced Setup In Advanced Setup > Wireless > Advanced Configuration 2.4GHz need careful some option. In Mode label: can choose 802.11 b/g/n mode. Bandwidth can set 20/40 MHz. Test Wi-Fi thought put can follow pic setting is fine.
Page 42
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 In this page you can notice enable or disable GI(Security Interval) both different. In first pic wasn’t enable GI, you can see Wi-Fi link rate would not be highest speed. And second pic was enabling short GI, the link rate would be highest.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 4.4 IGMP setup According to the WAN setting, if you want to test IGMP function on Router mode, you only need to enable IGMP function basic on the WAN SETUP.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 4.5 USB setup Insert a U disk into the USB interface, then login 192.168.1.1,select “Application”->” Storage Service”->”Storage Device Info”. Confirm the system has mounted the U disk.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Click “Refresh”, Make sure the status is complete. TFTP Server Below is picture for how to enable TFTP Server function.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 4.6 SNMP Setup Below is picture for how to enable SNMP function, device support SNMP V1/V2.
Page 49
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Download “MG-SOFT MIB Browser”. below is picture for how to use the software. Connect Remote SNMP agant.
Page 50
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Select OID:1.3.6.1.2.1.1.3 System Up Time...
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Appendix A: Cable Requirements A.1 Ethernet Cable A CAT 3~7 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the router. A 10Base-T cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10Base-T cable is referred to as an RJ-45 connector and it consists of eight pins.
Page 52
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
Page 53
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 A.2 Telephone wire Standard telephone wire of any gauge or type-flat, twisted or quad is used to connect the Modem to the telephone network. A telephone cable typically consists of three pairs of wires, one of which is used for transmission. The connector at the end of the telephone cable is called an RJ-11 connector and it consists of six pins.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Appendix B: Product Specification Key Features & Benefits Adopts ARM Cortex A9 dual-core processor Supports G.993.5 Vectoring and ADSL2+ Supports G.998.4 G.INP Supports Dying Gasp Supports ATM and PTM transmission mode auto detection ( ADSL backward compatible)
Page 55
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Supports DHCP Server/ DHCP Relay/ DHCP Client/ DHCPv6 Client/ DHCPv6 Server/ DNS/ DNS Proxy or Relay/ DNSv6 Proxy or Relay/ NTP Client/HTTP1.1 server Supports Multicast IP table/IGMP v3 Proxy and Snooping Supports IEEE802.1q Tag VLAN Support IEEE 802.1p VLAN Priority and mapping to DSCP...
Page 56
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Product Specification IEEE802.3/802.3u/802.11b/802.11g/802.11n standards Standards: ITU-T G992.1/G992.3/G992.5/G993.1/G993.2/G993.5/G997.1/G998.4 standards Wireless Frequency Range 2.4GHz Single band 4 x RJ-45 10/100Mbps Ethernet port 1 x RJ-11 for VDSL2 line port 2 x 2dBi external Antennas Physical Interface:...
Page 57
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Power Input: Input Voltage: 12 VDC/1A (Commercial-grade power adapter) EMI Compliant: FCC EMC: EMS Compliant: CE mark 0° C ~ 50° C (32° F ~ 122° F) Fan-less, free air coolin g Operating Temperature: Storage Temperature: -20°...
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Appendix C: Router/Bridged Mode select This appendix describes how to select the router/bridged mode, The NV-720S default mode is router mode, please refer to the following steps to select the router mode or switch mode. Selecting the Router mode: 1.
Page 59
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 2. Click the WAN Service link (WAN Setup) on the left navigation bar to specify the WAN Setup. Please Select as the DHCP Mode. Figure C-2 WAN Setup 3. Please refer to the section 4.2 for configuring the WAN type; the user can configure the Dynamic IP Address, Static IP Address,...
Page 60
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Figure C-3 Configuring WAN Type Click Apply for applying the changes. Click Back to exit from this page without saving the changes.
Page 61
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Select the Bridged mode: 1. To configure the bridged mode settings, click the IPv4 Configuration link (LAN Setup) on the left navigation bar. And click Apply at any time during configuration to save the information that you have entered. A screen is displayed as shown in Figure C.4...
Page 62
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 2. Click the WAN Service link (WAN Setup) on the left navigation bar to specify the WAN setup. A screen is displayed as shown in Figure C.5...
2.4 Verify that the proper cable type is used and its length does not exceed specified limits. 2.5 Check the router on the attached device and cable connections for possible defects. 2.6 Make sure that the phone wire must be connecting NV-720S first, when powered on. 2.7 Replace the defective router or cable if necessary.
Page 66
VDSL setting failure or phone cable length is over the specification limit. 3.1 Please make sure that the phone wire must be connected between CO side and NV-720S (CPE) when both are power on. CO side will do link speed function depending on phone wire length, therefore if CO side can’t detect NV-720S (CPE) over phone wire while both power on,...
Page 67
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 The protocol was standardized in the International Telecommunication Union telecommunications sector (ITU-T) as Recommendation G.993.2. It was announced as finalized on 27 May 2005, [1] and first published on 17 February 2006. Several corrections and amendments were published in 2007 through 2011.
Page 68
TCP window size must be set to max. 64k, the parameter as iperf –c server IP address –i 1 –t 50 –w 65535 for client side. I just bought a Netsys NV-720S to replace my Quest DSL modem for my home. I was told any VDSL2 7. Question: modem would work and give me higher communication speeds.
Page 69
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 error will show when applied. Please deactivate and activate once the settings have been changed. We need to set up a default gateway on a NV-720 pair which is in Bridge mode, as they want to 8.
Page 70
ADSL2 IP DSLAM. I have purchased a kit of NV-700L and NV-720S to extend the property Wi-Fi network. They will sit in the property LAN which is served by a modem router and off an ADSL telecom connection. Each NV unit will have a fixed IP LAN address.
Page 71
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 two antennas is the Gain pattern shape (the 5dBi Gain pattern shape is butterfly and the 2dBi Gain pattern shape is chubbier), and also the 5dBi antenna has higher penetrating power (ex. Through walls).
Page 72
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 System Diagnostics Power and Cooling If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply as explained in the previous section. However, if the unit power is off after running for a while, check for loose power connections, power losses or surges at the power outlet.
Page 73
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Physical Configuration If problems occur after altering the network configuration, restore the original connections, and try to track the problem down by implementing the new changes, one step at a time. Ensure that cable distances and other physical aspects of the installation do not exceed recommendations.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Appendix E: Compliance Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 75
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 The telephone company may make changes in its facilities, equipment, operations or procedures that could affect the proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service.
Page 76
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 CE Mark Warning In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. WEEE Warning To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol.
NV-720S ADSL2+/VDSL2 Wi-Fi USER’S MANUAL Ver. A.2 Warranty The original product that the owner delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.
