- Page 1 1GB/2GB/4GB MP3 Player Instruction Manual L1GMP309 L2GMP309 L4GBMP310...
- Page 3 Congratulations on the purchase of your new Logik MP3 Player. It has many exciting features to make your listening to music experience more enjoyable. We recommend that you spend some time reading this instruction manual in order to fully understand these features.
-
Page 4: Table Of Contents
Contents Product Overview ..........5 Unpacking the MP3 Player ........... 5 Identification of Parts and Controls ........6 Battery Installation ..............7 Battery Level Indication ............7 Connecting to a Computer ........8 System Requirements ............8 Loading Files from a Computer to the MP3 Player ..8 Basic Operation ............. -
Page 5: Product Overview
Product Overview Unpacking the MP3 Player Remove all packaging from the MP3 player. Retain the packaging. If you dispose of it please do so according to local regulations. The following items are included: MP3 Player Earphones Instruction Manual... -
Page 6: Identification Of Parts And Controls
Identification of Parts and Controls 5 6 7 10 11 1. Earphones jack 2. USB cap for USB connector 3. USB connector 4. Display screen Left/Previous button Volume up button Right/Next button Play/Pause button • To play/pause the music/recording playback • Press and hold to enter the main menu • Press and hold to unlock when the buttons are locked... -
Page 7: Battery Installation
Battery Installation 1. Remove the USB cap. 2. Remove the battery compartment cover on the back of the MP3 player by sliding it in the direction of the arrow. 3. Insert a AAA battery (not supplied) into the battery compartment. Install the batteries correctly by following the polarity (+ and -) indications in the battery compartment. -
Page 8: Connecting To A Computer
Connecting to a Computer System Requirements Your computer system must meet the following requirements: • Pentium 200MHz or above • Microsoft Windows 2000 / XP / Vista® • 120MB of available hard disk space • USB port supported Loading Files from a Computer to the MP3 Player Files can be transferred directly to the MP3 player by using the USB connector. -
Page 9: Basic Operation
Basic Operation Power On/Off the MP3 Player Make sure the battery power level is sufficient and the earphones are connected. • Press and hold the button to power on. • Press and hold the button to power off. Unlock All Buttons All the buttons will automatically lock if the MP3 player remains idle for a short period of time. -
Page 10: Listening To Music
Listening to Music Playing Music Make sure the battery power level is sufficient and the earphones are connected correctly. 1. Press and hold the button to enter the main menu. buttons to select Music. Then 2. Press the press the button to display the following screen. -
Page 11: Setting The Music Playing Mode
Setting the Music Playing Mode 1. While playing music, press the button to set the Music Playing mode. 2. Press the buttons and then the button to access the following: Repeat To set the music repeat mode. Use the buttons to select among: Normal, Repeat One, Repeat All, Random, and Intro. -
Page 12: Managing The Audio Files
Managing the Audio Files 1. To manage your audio files, make sure the music is paused and then press the button. 2. Press the buttons and then the button to access the following: Local folder To view all audio files from local folder. Use the buttons to select an audio file or a folder, and then press the... -
Page 13: Voice Recording
Voice Recording Recording a Voice 1. Press and hold the button to enter the main menu. buttons to select Record. Then 2. Press the press the button to display the following screen. Time Elapsed / Total Time REC Type Recording No. -
Page 14: Playing Voice Recordings
Playing Voice Recordings 1. Press and hold the button to enter the main menu. buttons to select Voice. Then 2. Press the press the button to display the following screen. Music repeat mode Track No. / Time Elapsed / Total Tracks Total Time Battery REC Type... -
Page 15: Setting The Voice Playing Mode
Setting the Voice Playing Mode 1. While playing voice, press the button to set the Playing Voice Recordings mode. 2. Press the buttons and then the button to access the following: Repeat To set the music repeat mode. Use the buttons to select among: Normal, Repeat One, Repeat All, Random, and Intro. -
Page 16: Managing The Voice Files
Managing the Voice Files 1. To manage your voice files, make sure the music is paused and then press the button. 2. Press the buttons and then the button to access the following: Local folder To view all record files from voice folder. Use the buttons to select voice folder, and then press the... -
Page 17: Folder Navigation
Folder Navigation In the File View mode, you can browse all the files stored in the MP3 player. 1. Press and hold the button to enter the main menu. buttons to select Folder. Then 2. Press the press the button to display the following screen. -
Page 18: Customising The Settings
Customising the Settings The system settings let you customise and configure your MP3 player. 1. Press and hold the button to enter the main menu. buttons to select Settings. Then 2. Use the press the button to display the following screen. - Page 19 buttons to select Sleep time to Use the power off automatically after the preset time. The available options include: 0m, 10m, 20m, 30m, 40m, 50m, 60m, 70m, 80m, 90m, 100m, 110m, 120m. Press the button to confirm. Version To view software version. Reset Reset all settings back to default settings.
-
Page 20: Hints And Tips
Hints and Tips If a problem does occur, it may often be due to something very minor. The following table contains various tips. Cannot • The battery may be exhausted. power on Replace battery with a new one. Files • Check if the driver is installed cannot be correctly in the computer. -
Page 21: Specifications
Specifications Model L1GMP309 / L2GMP309 / L4GMP310 Audio MP3/WMA/WAV Format MP3 bit 8~320Kbps Rate WMA bit 5Kbps-384Kbps rate S/N rate ≥80dB Dynamic ≥80dB (1 KHz) range Distortion <0.2% Power out 2*5mW Natural, Rock, Pop, Classic, Soft, Jazz Recorded format Size (L*W*H) 85*28*20.5mm... -
Page 22: Safety Warnings
Safety Warnings • Retain the manual. If you pass the unit onto a third party make sure to include this manual. Damage • Please inspect the unit for damage after unpacking. • Do not continue to operate the unit if you are in any doubt about it working normally, or if it is damaged in any way - switch off and consult your dealer. - Page 23 Earphones • For traffic safety, do not use earphones while driving or cycling. • Listening to loud sounds for prolonged periods of time may permanently damage your hearing. • Before putting on earphones, turn the volume down then put the earphones on and slowly increase the volume until you reach a comfortable listening level.
- Page 24 This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
