Logik L4SCAN11 Instruction Manual

Logik L4SCAN11 Instruction Manual

Portable a4 scanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Portable A4 Scanner
Instruction Manual
L4SCAN11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L4SCAN11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Logik L4SCAN11

Summary of Contents for Logik L4SCAN11

  • Page 1 Portable A4 Scanner Instruction Manual L4SCAN11...

  • Page 2: Table Of Contents

    Contents Unpacking ......................3 System Requirements ..................4 Product Overview ....................5 Indicator Signaling .....................6 Stand Along (for scanning)....................6 USB Connect (for recharge battery only or read/copy file) ..........6 Installing and Charging Battery ................7 Battery Status .........................7 Operation ......................9 Select the Scan File Format ....................10 Scan an Original ........................11 Power off the Scanner .......................12 Connecting to a Computer ................

  • Page 3: Unpacking

    Thank you for purchasing your new Logik Portable A4 Scanner. These operating instructions will help you use it properly and safely. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues.

  • Page 4: System Requirements

    System Requirements • Windows® XP / Vista™ / Windows® 7 Support Windows OS only. • Pentium® IV 2.4 GHz or equivalent AMD Athlon® • 512 MB DDR RAM or above • 500MB free hard disk space • 32-bit color display at 800x600 with DirectX 3D support •...

  • Page 5: Product Overview

    Product Overview Power Button Custom Button Battery Indicator Function Indicator Feeding Slot SD Slot USB Slot PC Connection Port Battery Cover 10. Roller Releaser...

  • Page 6: Indicator Signaling

    Indicator Signaling Stand Along (for scanning) LED 1 LED 2 Indicator Power Status Battery Function Power Off Green Blink Power On Initial Green Orange Battery full and ready for scan. The file format is JPEG. Green Orange Blink Scanning Orange Green Battery is medium and the file format is PDF.

  • Page 7: Installing And Charging Battery

    Installing and Charging Battery Slide open the battery compartment cover. Place the lithium battery as indicated. Follow the polarity indicated on the scanner. Slide the battery compartment cover back on. Plug the mains adaptor to the scanner. Plug the mains adaptor into the mains socket. Charge the scanner for 14 hours the first time you charge it.
  • Page 8 Handling the Batteries • Improper or incorrect use of batteries may cause corrosion or battery leakage, which could cause personal injury or damage to property. • Install the batteries correctly by following the polarity (+ and -) indications in the battery compartment. •...

  • Page 9: Operation

    Operation Insert a memory card into the memory card slot or a flash disk into the flash disk slot. TO PC CARD The SD card is the high priority when you insert the SD card and flash disk together. TO PC Press and hold the button for about 0.5 seconds.

  • Page 10: Select The Scan File Format

    Select the Scan File Format This scanner support JPG and PDF (B &W) scanned file formats. The default format is JPG and the Function Indicator light orange. Press the button and change the file format to PDF format. The Function Indicator emit as green.

  • Page 11: Scan An Original

    Scan an Original Insert your photo, document or name card with the side to be scanned facing upward and in correct orientation, place the left edge of the original against the left edge of the feed slot, and then adjust the guide lever so that it is against the right side of the original.

  • Page 12: Power Off The Scanner

    Power off the Scanner After all originals were scanned, press and hold button until the indicator blank. Now you can safely remove the memory card or flash card from the scanner. Important: Insert only one photo at a time, and insert the next one only when the previous one is done, and the indicator light stops blinking.

  • Page 13: Connecting To A Computer

    Connecting to a Computer You may use the scanner as a memory card reader by connecting it to the computer through the USB cable, so that you can freely copy, paste or delete files to and from the memory card. The images in the card can also be downloaded to the computer by other computer devices.

  • Page 14: Disconnect The Scanner From A Computer

    When the scanner connects successfully with a computer, a Removable Disk (F) (F represents the removable drive letter) will be shown in Windows Explorer. If a memory card or flash disk is inserted to the scanner, the Removable Disk will be replaced with the name of the memory card or flash disk.

  • Page 15: Arcsoft Bizscanner

    Arcsoft BizScanner This simple application uses advanced OCR technology and scans the images of your business cards. It quickly and easily captures contact information from business cards and adds it to the application’s database, saving you a great deal of time and effort by eliminating the need to manually type in names, phones, and other key information.
  • Page 16 Install completely.

  • Page 17: Run Bizscanner

    Run BizScanner There are several ways that you can launch BizScanner: • Double click ‘BizScanner’ icon on the desktop or right-click the icon and select “open”. • Click Start All Programs ArcSoft BizScanner BizScanner.

  • Page 18: Start To Use Bizscanner

    Start to Use BizScanner Input Business Cards Input - Switch to “Input Business Cards” to quickly and easily capture contact information from business cards. Input business cards main screen:...
  • Page 19 Toolbar The Toolbar provides the following functions for you to input business card images: Import from Import images of business cards from a BizCard Scanner professional BizCard scanner. Before using this function, make sure that a BizCard scanner is properly connected to your computer.
  • Page 20 Manage Business cards Manage - Switch to “Manage Business Cards” to manage the application’s database and preview all imported business cards. Manage business cards main screen:...
  • Page 21 Toolbar The toolbar provides several functions for you to manage the database. Email Send selected business cards as email attachments. For each card, the original image and a vCard file are attached. Export Export the selected business cards as a specified format as listed in the drop-down list.
  • Page 22 Card Display Provides two modes for you to preview all business cards. More than one card can be selected at the same time. List View - Displays detailed information in a table format. E-mail and website addresses are displayed in hyperlink format. Click to send an e-mail or visit the website.
  • Page 23 In each view, you can also right-click the business card to display an additional menu: • Move to Category Move the selected business card to another category. • Edit Modify the details of the business card in the pop-up window. You can also double-click the business card to go to the Edit screen.

  • Page 24: Maintenance

    Maintenance Calibrating the scanner If the scanned image color looks unnatural, the scan engine may need calibrating in order for the sensor to resume its original precision. To calibrate the scan engine: Connect the power supply to the scanner. Insert the SD card or flash disk and move the guide lever to the end of right side.

  • Page 25: Cleaning The Sensor Glass

    Cleaning the Sensor Glass If debris is present, the scanned image may have streaks or scratches, the sensor glass may need cleaning in order for the glass to resume its original clean. To clean the sensor glass: With the scanner powered off and disconnected from the power supply Press the Roller Releaser to reveal...

  • Page 26: Hints And Tips

    Hints and Tips If you have problems with the operation of the product, please check the following troubleshooting hints. Question Answer There are strange • Are there scratches on the original, or is the original lines on the scanned clean? Remove any stains or dust from the original before image, or the image scanning.

  • Page 27: Specifications

    Specifications Model L4SCAN11 Scanner type Sheet-fed scanner / single page Carriage Color CIS (8.25 inch) Boot on time Less than 7 seconds Memory card slot SD / SDHC / Flash Disk Button 2 (Power / Custom) Acceptable paper Size 2” x 2” ~ 8.5” x 11. 69"...

  • Page 28: Safety Warnings

    Safety Warnings Please read all the instructions and familiarise yourself with the features and operation of your scanner before using the appliance. Make sure you read all the safety notes carefully and retain for future reference. • Never operate the scanner inside of an aircraft or anywhere else where operation of such devices is restricted.
  • Page 29 NOTE: If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number Pouch 2P6-PS003-D0161 USB Cable 052-USB0A-X0800 Lithium Battery 060-3450A-AGX10 Calibration Card 2P8-PS003-0001 Mains Adapter 060-CAP00-50513 CIS Cleaning Swab 2AX-PS003-00001 Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.
