Onyx MD116 Manual

Mobile medical assistant
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M obi l e M e di c a l As s i s t a nt
O N Y X - M D 1 1 6
ONYX-MD116
" LCD with LED Backlight
11.6
Intel® Apollo Lake processor
Dual smart card readers for multiple-care workflow
Instant vehicle docking system
Mobile Medical Assistant
ONYX-MD116 Manual 1st Ed
November, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD116 and is the answer not in the manual?

Questions and answers

Related Manuals for Onyx MD116

Summary of Contents for Onyx MD116

  • Page 1 O N Y X - M D 1 1 6 ONYX-MD116 ” LCD with LED Backlight 11.6 Intel® Apollo Lake processor Dual smart card readers for multiple-care workflow Instant vehicle docking system Mobile Medical Assistant ONYX-MD116 Manual 1st Ed November, 2017...
  • Page 2 ONYX Healthcare Inc., assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein ONYX Healthcare Inc. reserves the right to make changes in the product design without notice to its users...
  • Page 3 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 Acknowledgments ® ® Intel Pentium is registered trademarks of Intel Corporation.  ® ®...

  • Page 4: Packing List

    O N Y X - M D 1 1 6 Packing List Before you begin installing your Mobile Medical Assistant, please make sure that the following items have been shipped: ONYX-MD116 Mobile Medical Assistant  ONYX-MD116 Docking Station(model: OPM-T016) ...
  • Page 5 Onyx Healthcare Inc. 2F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.) TEL: +886-2-8919-2188 FAX: +886-2-8919-1699 E-mail: sales@onyx-healthcare.com http://www.onyx-healthcare.com Worldwide Offices: Onyx Healthcare, USA Inc. 324W. Blueridge Ave., Orange,, CA 92865, USA Tel : +1-714-792-0774 Fax: +1-714-792-0481...
  • Page 6 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 Email: usasales@onyx-healthcare.com Onyx Healthcare EUROPE B.V. Primulalaan 42, 5582 GL Waalre, Netherlands Tel : +31-(0)499-745600 Email: eusales@onyx-healthcare.com...
  • Page 7 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 Safety & Warranty 1. Read these safety instructions carefully. 2. Keep this user's manual for later reference. 3.
  • Page 8 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 12. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient over-voltage.
  • Page 9 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 16. If any of the following situations arises, get the equipment checked by service personnel: a.
  • Page 10 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 Classification 1. Degree of production against electric shock: not classified 2. Degree of protection against the ingress of water: IPX0 3.
  • Page 11 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 This device complies with Part 18 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference...
  • Page 12 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 UL Module Description ONYX-MD116 module is developed to suitable for the Classification Mark requirement...
  • Page 13 M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 Safety Symbol Description The following safety symbols are the further explanations for your reference.

  • Page 14: Table Of Contents

    1.2 Feature .................1-3 1.3 Specification ..............1-4 1.4 Dimension ..............1-8 Chapter 2 Hardware Installation 2.1 Safety Precautions ............2-2 2.2 Quick Tour of ONYX-MD116 ........2-3 2.3 Mounting…………………………………………………… 2-6 2.4 Turn On and Boot up into Windows…………………….2-6 2.5 Turn off……………………………………………………….2-6 Chapter 3 Driver Installation Appendix A Miscellanea A.1 General Cleaning Tips..........

  • Page 15: Chapter 1 General Information

    M obi l e M e di c a l As s i s t a nt O N Y X - M D 1 1 6 Chapter General Information...

  • Page 16: Introduction

    ONYX-MD116 includes all the features of a powerful computer into a slim and attractive chassis. It has a 11.6” 600 nits TFT display with 1920 x 1080 resolution. ONYX-MD116 owns Dual smart card reader to support ID check.

  • Page 17: Feature

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 1.2 Feature Intel® Apollo Lake N4200 Quad Core Processor  Supports One DDR3 SODIMM up to16GB  Built-in RFID and Dual Smart Card Security ...

  • Page 18: Specification

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 1.3 Specification Hardware Specifications Processor Processor Intel® Apollo Lake Processor DDR3L SO-DIMM x1, Default 4 GB (Up to 16 GB) System Memory Microsoft®...
  • Page 19 Back Light Life Time >50,000 Hrs Note: All ONYX LCD products are manufactured with High precision technology. However, there are a small number of defective pixels in all LCD panels that are not able to change color. This is a normal occurrence for all LCD displays from all manufacturers and should not be noticeable or objectionable under normal operation.
  • Page 20 Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 Mechanical Specifications Close-frame Architecture Color Dark Gray Mounting / Holder VESA 75/100mm, Screw type:M4*8mm Construction 3mm ABS + PC TYPE Plastic housing Rear cover magnesium Dimension (WxHxD) 312 (W) x 239 (H) x 37 (D) mm...
  • Page 21 Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 Environmental Specifications 0°C ~ 40°C (32°F ~ 104°F) Operating Temperature Operating Humidity 30% to 75% RH, non-condensing Operating Pressure 700 to 1060 hPa Storage Temperature...
  • Page 22 Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 3300 mAh x2 Battery USB 3.0 (Type-A) x1, USB 2.0 (Type-A) x1 Ethernet Ethernet Gigabit LAN x1 Intended use OPM-T016 were mobile docking station, and intended to provide stable platforms for...

  • Page 23: Dimension

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 1.4 Dimension Chapter 1 General Information...

  • Page 24: Chapter 2 Hardware Installation

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 Chapter Hardware Installation Chapter 2 Hardware Installation...

  • Page 25: Safety Precautions

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 26: Quick Tour Of Onyx-Md116

    O N Y X - M D 1 1 6 2.2 Quick Tour of ONYX-MD116 Before you start to set up ONYX-MD116, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illustrated in the figures below.
  • Page 27 I/O port in left and right side, as shown in Picture 2-2. (The I/O section includes various I/O ports, including a DC-IN Jack, 1 Ethernet ports, 2 USB ports.). Top side have 2 smart card reader. Picture 2.2 Rear view of ONYX-MD116 Series IO Port Chapter3 Award BIOS Setup 3...
  • Page 28 Below picture 2-3/2-4 show the Docking front and rear view. In front view have 2 USB port and Battery charging hole. Back side have DC-IN Jack and phoenix connector/ Line-out/ RJ 45 port. Picture 2.3: ONYX-MD116 Docking front side Chapter3 Award BIOS Setup 3...
  • Page 29 Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 Picture 2.4: ONYX-MD116 back side view Chapter3 Award BIOS Setup 3...

  • Page 30: Mounting

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 2.3 Mounting ONYX-MD116 Docking be mounted with 75mm x 75mm or 100mm x 100mm VESA holes in the rear cover by wall-mount or desktop stand. VESA Holes 2.4 Turn On and Boot up into Windows OS...

  • Page 31: Turn Off

    When the battery cannot be detected and connected with adapter, the LED Indicators will be bright blue. 2.5 Turn off Turning off ONYX-MD116 properly is important for system reliability. There are two ways to turn off the system. 1. On the start menu, click “shut down” and select “OK”...

  • Page 32: Chapter 3 Driver Installation

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 Chapter Driver Installation Chapter3 Driver Installation 3...
  • Page 33 Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 There are several installation ways depending on the driver package under different Operating Systems. Please follow the sequence below to install the drivers: For Windows 10: Step 1 –...

  • Page 34: Appendix A Miscellanea

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 Appendix Miscellanea Appendix A Miscellanea A-1...

  • Page 35: General Cleaning Tips

    ONYX Healthcare Inc. has tested and verified these cleaning disinfectants, CIDEX, Viraguard, Control III Disinfectant Germicide, Caviwipes, Dispatch Disinfectant Cleaner CLH69101, Puregreen 24 Disinfectant, can be used with ONYX-MD116. Use of any other disinfectants will Appendix A Miscellanea A...

  • Page 36: Cleaning Tools

    Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 void the warranty. A.2 Cleaning tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals.
  • Page 37 Sl i m M e di c a l Pa ne l PC O N Y X - M D 1 1 6 circuitry to corrode.  Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations.

  • Page 38: Scrap Computer Recycling

    For the computers that are no longer useful or work well, please contact with worldwide distributors for recycling. The worldwide distributors show on the following website: http://www.onyx-healthcare.com.tw/Contact.php Note: Follow the national requirement to dispose unit Appendix A Miscellanea A...
