Onyx MD101 Manual

Mobile medical assistant tablet 10.1" lcd with led backlight intel cherry trail z8350 processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M o b i l e M e d i c a l A s s i s t a n t
O N Y X - M D 1 0 1
T a b l e t
Main model: ONYX-MD101
Series Model: xxxONYX-MD101xxxxxxxxxx(x=0~9, A~Z,
a~z or blank or middle bar; for marketing purpose only and no
impact safety related constructions and critical components)
10.1" LCD with LED Backlight
®
Intel
Cherry Trail Z8350 Processor
Mobile Medical Assistant Tablet
ONYX-MD101 Manual 1st Ed
Jul, 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onyx MD101

Summary of Contents for Onyx MD101

  • Page 1 10.1” LCD with LED Backlight ® Intel Cherry Trail Z8350 Processor Mobile Medical Assistant Tablet ONYX-MD101 Manual 1st Ed Jul, 2017...
  • Page 2 The material in this document is for product information only and is subject to change without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy, ONYX Healthcare Inc., assumes no liabilities resulting from errors or...
  • Page 3 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Acknowledgments ® ®...

  • Page 4: Packing List

    T a b l e t Packing List Before you begin installing your Medical Tablet PC, please make sure that the following items have been shipped: ONYX-MD101 Mobile Medical Assistant Tablet  Medical Power Adapter 15V/2.4A  Utility DVD-ROM, which contains Drivers and Utilities ...
  • Page 5 2F, No.135, Lane 235, Pao-Chiao Rd., Hsin-Tien City, Taipei 231, Taiwan, R.O.C. TEL: +886-2-8919-2188 FAX: +886-2-8919-1699 E-mail: sales@onyx-healthcare.com http://www.onyx-healthcare.com Worldwide Offices: Onyx Healthcare, USA Inc. 324W. Blueridge Ave., Orange,, CA 92865, USA Tel : +1-714-792-0774 Fax: +1-714-792-0481 Email: usasales@onyx-healthcare.com Onyx Healthcare EUROPE B.V.
  • Page 6 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Onyx Healthcare (Shanghai) INC. 20F, unit D, GEM Building, No. 487 Tianlin Road, Shanghai, China...
  • Page 7 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Safety & Warranty 1.
  • Page 8 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t 13. Never pour any liquid into an opening. This could cause fire or electrical shock.
  • Page 9 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t 16. If any of the following situations arises, get the equipment checked by service personnel: a.
  • Page 10 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Classification 1. Degree of production against electric shock: not classified 2.
  • Page 11 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t This device complies with Part 18 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must...
  • Page 12 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t UL Module Description ONYX-MD101 modules are developed to suitable for the Classification Mark requirement...
  • Page 13 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Safety Symbol Description The following safety symbols are the further explanations for your reference.

  • Page 14: Table Of Contents

    1.3 Specification ..............1-4 1.4 Dimension ............... 1-8 Chapter 2 Hardware Installation 2.1 Safety Precautions ............2-2 2.2 Quick Tour of the ONYX-MD101 ........2-3 2.3 Turn On and Boot up into Windows…………………….2-7 2.4 Turn off……………………………………………………….2-7 Chapter 3 Driver Installation Appendix A Miscellanea A.1 General Cleaning Tips ..........

  • Page 15: Chapter 1 General Information

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Chapter General Information...

  • Page 16: Introduction

    ONYX-MD101 is designed for this purpose. With the integration of ECG devices, e.g. GE V100, and intuitive software UI, ONYX-MD101 is working as a Gateway to transfer and document all the data liked NIBP,...
  • Page 17 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t high mobility 6.

  • Page 18: Feature

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t 1.2 Feature Intel®...

  • Page 19: Specification

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t 1.3 Specification Main System Specifications Intel®...
  • Page 20 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Liyhium-Ion Battery Battery Fan less System Cooling...
  • Page 21 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Front Panel Design Power Button : x1 Volume Keys: x2 Control Button...
  • Page 22 Weight Note: All ONYX LCD products are manufactured with High precision technology. However, there are a small number of defective pixels in all LCD panels that are not able to change color. This is a normal occurrence for all LCD displays from all manufacturers and should not be noticeable or objectionable under normal operation.
  • Page 23 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Touch Screen Specification Touch Type Brand EP1010MLM2...

  • Page 24: Dimension

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t 1.4 Dimension...

  • Page 25: Chapter 2 Hardware Installation

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Chapter Hardware Installation...

  • Page 26: Safety Precautions

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 27: Quick Tour Of The Onyx-Md101

    T a b l e t 2.2 Quick Tour of the ONYX-MD101 Before you start to set up ONYX-MD101, take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illustrated in the figures below.
  • Page 28 O N Y X - M D 1 0 1 T a b l e t When you turn the ONYX-MD101 around and look at its rear cover, it contains an 8MP camera and high quality of stereo speakers. ONYX-MD101 comes with a VESA cradle, which is equipped a standard...

  • Page 29: Turn On And Boot Up Into Windows

    This section is for Windows operating system only. If you are installing a different operating system, please contact your vendor for installation details. Your ONYX-MD101 will begin loading Windows OS once you push the power button to turn power on. After less than one minute, Windows desktop screen will appear.
  • Page 30 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Chapter Driver Installation...
  • Page 31 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t There are several installation ways depending on the driver package under different Operating Systems.

  • Page 32: Appendix A Miscellanea

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Appendix Miscellanea...

  • Page 33: General Cleaning Tips

    Try not to put any food, drink or cigarette around the computer. ONYX Healthcare Inc. has tested and verified these cleaning disinfectants, CIDEX, Viraguard, Control III Disinfectant Germicide, Caviwipes, Dispatch Disinfectant Cleaner CLH69101, Puregreen 24 Disinfectant, can be used with the ONYX-MD101. Use of any other disinfectants will void the warranty.

  • Page 34: Cleaning Tools

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t A.2 Cleaning Tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals.
  • Page 35 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t  Foam swabs - Whenever possible it is better to use lint free swabs such as foam swabs.

  • Page 36: Scrap Computer Recycling

    For the computers that are no longer useful or work well, please contact with worldwide distributors for recycling. The worldwide distributors show on the following website: http://www.onyx-healthcare.com.tw/Contact.php Note: Follow the national requirement to dispose unit...

  • Page 37: Compliance Information

    M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Appendix Compliance Information...
  • Page 38 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t B.1 FCC Statement Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
  • Page 39 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t Reorient or relocate the receiving antenna. ...
  • Page 40 Devices, ONYX-MD101 (FCC ID: RZ5-MD101) have been tested against these SAR limits to maintain compliance with FCC/CE RF exposure requirements. This equipment complies with FCC/EU RF radiation exposure limits set forth for an uncontrolled environment. The highest SAR value for the ONYX-MD101 device is 0.14 W/kg.
  • Page 41 M o b i l e M e d i c a l A s s i s t a n t O N Y X - M D 1 0 1 T a b l e t B.3 CE Statement This equipment complies with the requirements relating to electromagnetic compatibility, the essential protection requirement of Electromagnetic Compatibility (EMC) Directive 2014/30/EU on the...
