PRE AMPLIFIER Contents Contents Welcome Unpacking Before Use Safety Instruction Operation Features Front Panel Rear Panel RACK Connection Block Diagram Specification Service and Warranty IPP-8213... -
Page 3: Welcome
Welcome Welcome you from management and staffs of INKEL PA. All of the staffs here at INKEL PA have dedicated to provide excellent products of value, and we are glad that you have purchased one of our products. We sincerely trust that this product will provide satisfactory service, but if anything goes up you do not satisfy completely, we will endeavor to make things right. -
Page 4: Safety Instruction
These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of diposal. Note for the battery symbol (bottom two symbol examples): The sign Pb below the symbol for batteries indicates that this batteries contains lead. IPP-8213... -
Page 5: Operation
PHANTOM POWER FOR CONDENSOR MICROPHONE Designed to use condenser MIC on channel 1 and 2 and supply voltage is DC +18V. DUCKING Ducking function available on channel 1 and 2 enable their sound sources to be broadcasted prior to the others. IPP-8213... -
Page 6: Front Panel
This is the master control to adjust mixed signal from each input channel. 8. 3-BAND EQUALIZER (INPUT CHANNEL) It has been designed as 3-band equalizer to adjust input signal to much richer sound. (HIGH: 10kHz, MID: 1kHz, LOW: 100Hz) IPP-8213... -
Page 7: Rear Panel
MIC circuit, and it may cause defeats of 7. REC OUT JACK speaker. As UNBALANCE output to record mixed signal, its output level is -10dBV/10kΩ. IPP-8213... -
Page 8: Rack Connection
PRE AMPLIFIER RACK Connection IPP-8213... -
Page 9: Block Diagram
PRE AMPLIFIER Block Diagram IPP-8213... -
Page 10: Specification
Operation Temperature -10℃ ~ +40℃ Storage Temperature -20℃ ~ +60℃ ■ GENERAL Power Source AC 100V - 120V, 220V- 240V, 50/ 60Hz, DC 24V Power Consumption Weight 7.5kg Dimension 482(W)×88(H)×280(D)mm ※ Specifications and design are subject to change without notice. IPP-8213... -
Page 11: Service And Warranty
SERVICE AND REPAIR For replacement parts, service and repairs please contact the INKEL PA distributor in your country. INKEL PA does not release service manuals to consumers, and advice users to not attempt any self repairs, as doing so voids all warranties.
