Quick Installation Guide of BOSSW213
※ To avoid users without access right through your BOSSW213 ,
suggest that use security mechanism like WEP, WPA or set
ID/password for web configuration login IP address 192.168.1.254.
Preparation
1
At lease one PC with IEEE802.11b/g WLAN client installed.
2
One straight-through Category 5 Ethernet cable, used to link WAN interface to xDSL or CM for
Internet connection.
3 BOSSW213
Check package contents:
BOSSW213
DC 7.5V Power Adapter
User's manual CD-ROM
1.8M RJ-45 Cable Line (Option)
Collect Installation Information:
WAN configuration (Contact your ISP or network administrator for these information)
DHCP Client
Static IP
IP Address
Subnet Mask
Default Gateway
DNS Address
PPPoE
User Name
Password
PPTP
IP Address
Subnet Mask
Server IP Address
User Name
Password
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
1 of 11
