Page 1: User Manual
DIGITAL DOOR VIEWER USER MANUAL Warranty Limitations: Mul-T-Lock reserves the right to invalidate the product's warranty if without prior consent the product's functionality or appearance has been altered; or if the product is used in an environment or manner not specified within this document. -
Page 3: Package Contents
Incorrect usage and extreme environmental conditions may cause memory loss on the SD card. Mul-T-Lock in not responsible for data loss and strongly recommends retaining copies of backup video. -
Page 4: Installation Instructions
Installation instructions If there is an existing door viewer, remove and replace with the camera front facing. If a door viewer does not exist, drill a 14mm hole in the door at the required height and then insert the camera. The washer should be fitted between the camera and the door. -
Page 5: Installation And Replacement Of Batteries
Installation and replacement of batteries: Installation 1. Slide the lid upward and then outward —as shown in diagram. 2. Insert batteries according to the “+” “-” sign on the lid. 3. To close the lid, simply reverse the action. To avoid damage: 1.Never use force when opening and closing the lid. -
Page 6: Button Functions
Screen operating instructions Part specifications Button functions Basic function Additional function Upward shift Downward shift Menu Left shift (only in menu setting) Selection key for replay mode during normal use Right shift (only in menu setting) Begin video key in normal use Power button Backside of screen case 7. - Page 7 Camera operating instructions Part specifications: Camera front view Camera side view 1.Camera 2. Doorbell button 3. Data wire Menu interface instructions: 00000 2011-01-01...
-
Page 8: Memory Card Installation
Icon Function N˚: Photo shooting mode Mode icons Video shooting mode Playback mode for photos or videos This icon shows that the TF card is TF card plug-in icon plugged in and recognized by the system This icon shows the normal doorbell mode Doorbell status icon This icon shows the DND(Do not... - Page 9 Select the setting the date key and press the menu button to enter. “ ”keys to select the digits to be set, then use the “ ” keys to adjust the numbers. If you want to add date and time information on the photos, set the time and date display to ON.
- Page 10 When viewing the exterior, photos or videos can be taken simultaneously. When the screen is on, press “ ” to take a photo. To take a video, press the “ ” until the instruction icon appears prompting a switch into video mode. Press“ ”to start shooting, one more press of “...
- Page 11 - Camera /Video ON/OFF: The camera and video functions can be enabled and disabled, using the ON/OFF mode. Press the menu button and enter the camera menu. When in ON mode the device will automatically take a photo of the exterior when the doorbell in pressed, when set to OFF, the device will not automatically take a photo.
- Page 12 Not fixing the doorbell camera with the sticker may result in the device moving, which could cause damage. Fig 3 The Mul-T-Lock name and the muscleman logo, are registered/pending trademarks of Mul-T-Lock Ltd. in various countries. © 2012 Mul-T-Lock Technologies Ltd. Cat. No. 89102666-A...
