User Manual for all Spex Arm and Thigh Supports (product code begins with '1156-')
Revision: ArmThighSupport20170320
User Name:
Serial Number:
S
Arm & Thigh Supports
installation & user manual
IMPORTANT CONSUMER INFORMATION NOTICE:
This manual contains important instructions that must
be passed on to the user of this product. Please do not
remove this user manual before delivery to the end user.
SUPPLIER: This manual must be given to the user of this
product.
USER/CAREGIVER: Before using this product, read
entire manual and save for future reference. Transit
Safety section MUST be read before used in a vehicle.
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SPEX Arm & Thigh Supports
Summary of Contents for SPEX Arm & Thigh Supports
- Page 1 User Manual for all Spex Arm and Thigh Supports (product code begins with ‘1156-’) Revision: ArmThighSupport20170320 ® Arm & Thigh Supports installation & user manual IMPORTANT CONSUMER INFORMATION NOTICE: This manual contains important instructions that must be passed on to the user of this product. Please do not User Name: remove this user manual before delivery to the end user.
-
