Page 7: Important Safety Instructions
IGITAL ONTROL NCORPORATED Important Safety Instructions All operators must read and understand the following safety precautions and warnings and must ® review this operator’s manual and the operator’s manual for their DigiTrak guidance system before using the Aurora display. If you have any questions about the operation of Aurora, please contact DCI Customer Service for assistance. - Page 8 IGITAL ONTROL NCORPORATED The accuracy of data generated by a DigiTrak Guidance System may be affected by a variety of factors, including (but not limited to) interference (passive or active) or other environmental conditions, improper use of the DigiTrak guidance system by the end user, failure to follow instructions found in the operator’s manual for the DigiTrak guidance system, and failure to properly calibrate the DigiTrak Guidance System.
-
Page 9: Care And Maintenance
IGITAL ONTROL NCORPORATED Care and Maintenance Touchscreen Interface Avoid operating Aurora while wearing gloves not specifically designed for use with touchscreens, as the response will be poor and foreign material on the gloves may damage the touchscreen. Use the soft pad of your fingertip to tap the display, or use gloves with a touchscreen-compatible fingertip. -
Page 10: General
IGITAL ONTROL NCORPORATED General Turn off the display when not in use. Store the display in its case, away from extremes of heat, cold, and moisture. Test to confirm proper operation prior to use. Inspect the display daily and contact DCI if you see any damage or problems. Do not disassemble or attempt to repair. -
Page 11: Introduction
IGITAL ONTROL NCORPORATED Introduction Panel Mounted AP8 Freestanding AF8 Freestanding AF10 DigiTrak Aurora Displays ® ® ® The Aurora DigiTrak Series Display is a multifunction touchscreen device that is compatible with SE F Series™, and Falcon DigiTrak guidance receivers. A receiver is used during horizontal directional drilling operations to locate and track a transmitter installed in the drill head. -
Page 12: Getting Started
IGITAL ONTROL NCORPORATED Getting Started Following are the basic steps for setting up your Aurora display for drilling. For complete details on the safe setup, operation, and features of your Aurora, please review the rest of this manual. Keep the separate Quick Start Guide (QSG) that came with your Aurora with you while you drill. The QSG is also available on your Aurora through the Help menu. -
Page 13: Installing Your Display
IGITAL ONTROL NCORPORATED 1. Speaker 2. Power/screen lock button 3. USB port Aurora Panel Mounted AP8 Installing Your Display An 8-inch panel mounted Aurora (model AP8) should be installed by your DigiTrak dealer. To install the AP8 yourself, refer to the MFD/Aurora Installation Guide, available at www.DigiTrak.com. After your panel mounted Aurora is installed, continue with the next section, Main Menu. -
Page 14: Main Menu
IGITAL ONTROL NCORPORATED Main Menu Power On Aurora automatically turns on and displays the Home screen when it receives power. To temporarily lock the screen so you can wipe it clean without making selections, press and release the power button on the back. A padlock displays beside the DCI logo in the upper left of the screen to indicate the screen is locked. -
Page 15: Applications
IGITAL ONTROL NCORPORATED Applications From the Home screen, tap Main Menu once. Application icons appear in the top tab. Main Menu, Applications Tab Notice how the Main Menu icon in the taskbar below now has a frame around it. The frame shows which application or screen is currently displayed. -
Page 16: Settings
IGITAL ONTROL NCORPORATED 1. Roll remains visible 2. Pitch remains visible 3. Predicted depth remains visible 4. A frame indicates Strip Chart is the currently displayed window Strip Chart Setup Window Strip Chart monitors and graphs fluid pressure , temperature, and pullback tension data over time. -
Page 17: Device
IGITAL ONTROL NCORPORATED Icon Operation Page Device Network Alarms Pitch History Receiver Peripherals Update To exit each Settings window described in the following sections, tap Main Menu or Home in the Taskbar. Device On the Settings tab, tap Device and select from the tabs on the left to set the following: Date, time, and time zone Units: temperature, distance, pitch angle, fluid pressure, and pull force (shown below) Language... -
Page 18: Network
IGITAL ONTROL NCORPORATED Once you have your Aurora set just the way you like it, use Profiles to save your own personal profile. Or, set different profiles for typical drilling jobs. Names may not contain the following special characters: " < > , : * / \ _ - ? |. Aurora has preset profiles for each of its onboard languages;... - Page 19 IGITAL ONTROL NCORPORATED When Aurora powers on, it will not automatically reestablish previous Wi-Fi connections. To reconnect, select Enable Wi-Fi and choose a network. To disconnect, choose a Connected network, then tap OK. To turn Wi-Fi completely off, clear the Enable Wi-Fi check box. Aurora is compatible with the mobile "hot spot"...
-
Page 20: Alarms
IGITAL ONTROL NCORPORATED Alarms On the Settings tab, tap Alarms and select from the tabs on the left to set warning and critical levels for temperature, fluid pressure, and pullback tension alarms. Excessive temperature, pressure, or tension typically indicates a drilling problem that should be resolved immediately to avoid damage to equipment and/or infrastructure. -
Page 21: Pitch History
IGITAL ONTROL NCORPORATED Pitch History On the Settings tab, tap Pitch History , then select Enable Pitch History. Pitch History Settings Tap the blue arrow buttons or drag the slider control to adjust the values for Target Pitch and Pitch Tolerance up or down. -
Page 22: Receiver
IGITAL ONTROL NCORPORATED Pitch Tolerance is the amount of deviation from the target pitch that you want to define as acceptable. This is represented by the yellow band above and below the red target pitch line on the graph. Stay within the yellow band to remain within the defined tolerance, shown here at ±1.5%. -
Page 23: Peripherals
IGITAL ONTROL NCORPORATED Peripherals On the Settings tab, tap Peripherals to set the following: ® Enable or disable a Multi-Function Cable Box (MFCB) used for cable and SST steering tool transmitters Set SST heading reference (shown below) Set cable transmitter roll offset Peripherals Settings For detailed information on using the MFCB or SST transmitter, see the appropriate operator’s manual, available at www.DigiTrak.com. - Page 24 IGITAL ONTROL NCORPORATED To Update Your Aurora To check for updates over a wireless network, tap Network Refresh If a DCI representative has provided updates on a USB flash drive, insert the drive in the USB port and tap USB Refresh to view available updates.
-
Page 25: Help
IGITAL ONTROL NCORPORATED To Delete an Application To delete an existing application, tap Delete in the appropriate row. Application with Delete Icon Help From the Home screen, tap Main Menu once. Help icons appear in the bottom tab. Main Menu, Help Tab Safety Warnings provides important information on the cautions and responsibilities associated with horizontal directional drilling. -
Page 26: Drilling With The Home Screen
IGITAL ONTROL NCORPORATED Drilling with the Home Screen The Home screen appears automatically when Aurora powers on. It shows all the information needed for drilling, such as transmitter pitch and roll, telemetry channel, and Target Steering data (when active). 1. Status bar 2. -
Page 27: Roll Offset
IGITAL ONTROL NCORPORATED Roll Offset Roll offset (RO) is an electronic compensation to match the transmitter’s 12 o’clock position to the drill head’s 12 o’clock position. Roll offset enabled on the receiver for a standard transmitter will display on Aurora automatically. To enable roll offset for a cable transmitter, tap Main Menu , Peripherals , and then the Roll Offset ... -
Page 28: Depth Readings
IGITAL ONTROL NCORPORATED Depth Readings When the receiver takes a depth reading at the locate line (LL), Aurora adds the blue Depth Bar, which provides transmitter depth and pitch information beside the roll indicator: 1. Depth timer 2. HAG on 3. - Page 29 IGITAL ONTROL NCORPORATED A depth reading taken at the rear locate point (RLP) will still cause the predicted depth to display, since the receiver does not distinguish between the FLP and RLP, however, the data will be inaccurate. When the receiver takes a predicted depth reading at the FLP, the screen adds the blue Depth and Distance Bars, which provides transmitter pitch and predicted depth and distance information beside and below the roll indicator.
-
Page 30: Target Steering
IGITAL ONTROL NCORPORATED Target Steering ® Instructions for setting up the receiver for Target Steering can be found in the operator's manual for your system. Most of the setup for Target Steering is done by the receiver operator. This section discusses how to use Target Steering data on the Aurora display. - Page 31 IGITAL ONTROL NCORPORATED This Target Steering screen shows the following scenario: 1. Side view 2. Toward drill rig 3. Ground 4. Transmitter 5. Receiver 6. Target depth 7. Projected destination 8. Target 9. Rear view Transmitter, Target, and Receiver The steering indicator shows that the drill head is heading above and to the left of the target. To bring the ball back on target, rotate the drill head so the red marker in the ball points toward the target.
-
Page 32: Target Steering In Interference Areas
IGITAL ONTROL NCORPORATED While drilling, monitor the yellow steering indicator ball closely, make small steering adjustments, and watch and wait for the results. The closer the drill head is to the receiver, the more sensitive the steering indicator becomes. As it approaches the target, reduce the amount of the turn. When the indicator is centered on the target and surrounded by a green ring, the drill head is correctly positioned on the intended bore path to drill toward the target. -
Page 33: Understanding The Steering Indicator Ball
IGITAL ONTROL NCORPORATED Understanding the Steering Indicator Ball As shown previously, the yellow steering indicator ball (projected destination) being to the left of the target does not necessarily mean the drill head is also currently to the left of the target. While each example below requires a different amount and duration of steering correction, all need to move the same direction: right and down. -
Page 34: Turning Target Steering Off
IGITAL ONTROL NCORPORATED Turning Target Steering Off The flashing Target Steering icon in the Status bar indicates when Target Steering data is being received, even if you are on a different screen. If you are viewing the Target Steering screen when Aurora stops receiving Target Steering information from the receiver, the display will stop showing data. -
Page 35: Working With Tensitrak
IGITAL ONTROL NCORPORATED Working with TensiTrak ® When Aurora detects tension data provided by a TensiTrak pullback and pressure monitoring system, it automatically displays the TensiTrak tension gauge. 1. Current pullback tension 2. Maximum pullback tension 3. Tension history 4. Fluid pressure 5. -
Page 36: Working With The Mfcb
IGITAL ONTROL NCORPORATED Working with the MFCB For instructions on making the power and data connections between the Multi-Function Cable Box (MFCB) and Aurora, please read the MFCB Operator's Manual, available at www.DigiTrak.com. Enabling the MFCB Until you have made the proper power and data connections between the MFCB and Aurora, the check box to Enable MFCB on the MFCB tab of the Peripherals screen (shown below) will be grayed out as unavailable. -
Page 37: Using A Cable Transmitter
IGITAL ONTROL NCORPORATED After the MFCB is correctly connected and enabled, Aurora replaces the transmitter battery icon at the top right of the screen with a display of the voltage and amps at both the MFCB and transmitter. This new portion of the screen functions as an on/off button for using the MFCB. Upon first use after Aurora is turned on, this MFCB button will be bordered and shaded in red, indicating the MFCB is not yet sending power to the transmitter. -
Page 38: Setting A Heading Reference
IGITAL ONTROL NCORPORATED When Aurora detects that a steering tool is connected to the MFCB, it adds a heading indicator to the display. 1. Heading reference (tap and hold to set) 2. Deviation from heading reference 3. Current heading 4. Heading indicator Home Screen with SST Heading Indicator and MFCB Power Readings As shown in the above image, roll accuracy for SST changes from a 24-position to a much more accurate... - Page 39 IGITAL ONTROL NCORPORATED SST Heading Reference Screen Tap and hold the heading indicator on the Home Menu shortcut screen. Heading Indicator ® ® DigiTrak Aurora Display Operator's Manual...
-
Page 40: Appendix A: System Specifications
IGITAL ONTROL NCORPORATED Appendix A: System Specifications Power Requirements Device Operational Voltage Operational Current DigiTrak Aurora AF10 Display 2.10 A max 10–28 V (nominal) DigiTrak Aurora AP8/AF8 Display 1.75 A max Environmental Requirements Category Value Relative humidity <90% Operating temperature -20 to 60°... - Page 41 19625 62nd Ave S, Suite B103 Kent Washington 98032, USA 425.251.0559, 800.288.3610 dci@digital-control.com, www.DigiTrak.com DCI Standard Warranty DCI warrants that it will either repair or replace any product that fails to operate in conformity to DCI’s published specifications at the time of shipment due to a defect in materials or workmanship during the warranty period for that product, subject to the terms set forth below.
- Page 42 IGITAL ONTROL NCORPORATED DCI may make changes in design and improvements to products from time to time. DCI shall have no obligation to upgrade any previously manufactured DCI product to include any such changes. THE FOREGOING IS THE SOLE WARRANTY FOR DCI PRODUCTS (OTHER THAN THE 5-YR/750-HR EXTENDED WARRANTY FOR FALCON 15/19”...
- Page 43 IMPORTANT: PLEASE READ THE TERMS AND CONDITIONS OF THIS LICENSE AGREEMENT CAREFULLY BEFORE USING THE AURORA PRODUCT. This End-User License Agreement ("license") is an agreement between DIGITAL CONTROL INCORPORATED (“DCI”) and the entity or ® individual (“you”) that purchases the AURORA product from an authorized distributor of DCI products.
- Page 44 IGITAL ONTROL NCORPORATED 7. Support Services. This license does not obligate DCI to provide you with any support services related to the SOFTWARE. However, registering your AURORA with DCI through access.DigiTrak.com will entitle you to one year of free upgrades for the SOFTWARE. 8.
- Page 45 IGITAL ONTROL NCORPORATED eliminate such invalidity and unenforceability. The other provisions of this license will remain in full force and effect. This license may only be modified in writing, signed by an authorized representative of you and DCI (which will require a new registration on access.DigiTrak.com by such purchasing person or entity).
