LALABY 2 IN 1 SWING USER'S MANUAL
Jafim Imports CC T/A Anchor International
No. 12 Kimberlite Road, Theta Ext 5, Booysens Reserve,
Johannesburg 2091,South Africa
+2711 835 2520
www.chelino.co.za
Sky Dream Baby Ltd. Co.
No. 10 (Chelino Store), Bahar-e-jonoobi Street, Inqlab Street, Tehran, Iran
0098-21-8830-5695
www.chelino.ir
Advertisement
Related Manuals for Chelino LALABY 2 IN 1 SWING
Summary of Contents for Chelino LALABY 2 IN 1 SWING
- Page 1 LALABY 2 IN 1 SWING USER’S MANUAL Jafim Imports CC T/A Anchor International No. 12 Kimberlite Road, Theta Ext 5, Booysens Reserve, Johannesburg 2091,South Africa +2711 835 2520 www.chelino.co.za Sky Dream Baby Ltd. Co. No. 10 (Chelino Store), Bahar-e-jonoobi Street, Inqlab Street, Tehran, Iran 0098-21-8830-5695 www.chelino.ir...
- Page 2 Due to variations on the styles and designs of our products, the photographs and illustration shown in this instruction manual and box are generic, Therefore product fabric, color and design may vary from images shown, Chelino reserves the right to alter product specifications. Contents: Parts List &...
- Page 3 Assembly instruction 1)Assemble base support front tube and rear tube (Fig.1.).Ensure the pop pins are locked in place so the front and rear tubes are secured. 2) Connect the swing control module wire with the battery compartment wire. Place the swing control module on the base support tube.
- Page 4 3) Ensure that the two adjustable backrest supports are attached to the seat support frame. Assembly as shown in Fig.4. If not - follow Fig.4. to do it. Ensure that it was done properly and that pop pins are locked. 4) Insert the seat frame front tube and backrest tube into the seat support frame.
- Page 5 6) After proper assembly seat frame should look like in the Fig.8. 7) In order to mount seat pad, padding and toy bar - follow as shown in pictures as below.
- Page 6 FUNCTIONS 8) In order to adjust the backrest - press simultaneously buttons on both adjustable backrest moldings and set it in one of 3 possible positions. 9) Bouncer can be rotated 360 degrees around bouncer axis. 10) In order to lock swinging possibility of bouncer - set it to the central position and then move slider up (Fig.11). Never block swinging when the bouncer is turned ON! 11) In order to insert safety belts follow figures: B, H-M from point 7.
- Page 7 SWINGING UNIT 12) Swinging unit and all functions were described and shown below (Fig.13.): - In order to turn the bouncer on - press button - POWER. - Buttons „-” i „+” (1) are used to control swinging speed of the bouncer. Press „+” to increases the swinging speed, „-” to decrease swinging speed.
-
Page 8: Batteries Replacement
FALL HAZARD: Discontinue use of swing while infant can roll over or push up on hands and knees. Never place the swing on countertops, table, on or near steps or on other elevated surfaces. ALWAYS use on the floor. SUFFOCATION HAZARD: NEVER use on soft surface, such as a bed, sofa, or cushion, as seat may tip over and cause suffocation. - Page 9 Booysens Reserve, 2091, Johannesburg, Gauteng, RSA. Please note, that any repair which will needs to be made to this product must be done at the Chelino workshop which is situated at 12 Kimberlite Road, Theta Ext, Booysens Reserve, 2091, Johannesburg, Gauteng, RSA. Our offices hours are Monday to Thursday from 9:00 am to 13:00 pm and 14:00 pm to 16:30 pm and Fridays from 9:00 am to 12:00 pm and 14:00 pm to 16:30 pm.
- Page 10 17. This product is fit to carry a child weighing no more than 8kgs. 18. Chelino takes no responsibility and will not be held liable for any damage or injury caused by using this product or if this product is used for any other purposes other than its intended purpose.
