Quick Installation Guide
Connect the Switch to the Network
I
NSTRUCTIONS FOR INSERTING AND REMOVING MODULES AND POWER SUPPLIES BEGIN ON
C
A T A L Y S T
WS-x5530
100%
WS-U5531-FETX
1
MDIX
PORT 2
10/100Mbps
10/100Mbps
SUPERVISOR ENGINE I I I
CONSOLE
LINK
AUX
0%
LINK
Switch Load
PCMCIA
EJECT
WS-x5530
10/100 FAST ETHERCHANNEL
100%
WS-U5531-FETX
2
MDIX
PORT 2
10/100Mbps
10/100Mbps
SUPERVISOR ENGINE I I I
CONSOLE
AUX
0%
LINK
LINK
Switch Load
PCMCIA
EJECT
10/100 FAST ETHERCHANNEL
3
FAST ETHERNET SWITCHING MODULE
FAST ETHERNET SWITCHING MODULE
FAST ETHERNET SWITCHING MODULE
FAST ETHERNET SWITCHING
MODULE
FAST ETHERNET SWITCHING
MODULE
FAST ETHERNET SWITCHING
FAST ETHERNET SWITCHING
MODULE
MODULE
FAST ETHERNET SWITCHING
MODULE
o
o
AC
FAN
OUTPUT
OK
OK
FAIL
1
Prepare for Installation
2
Rack-Mount the Switch
3
4
Connect the Power
5
Start the System
5 5 0 9
MDIX
MDIX
AC
FAN
OUTPUT
OK
OK
FAIL
P
13.
AGE

Advertisement

Table of Contents
loading

Related Manuals for Cisco Catalyst 5509

Summary of Contents for Cisco Catalyst 5509

  • Page 1 Quick Installation Guide 5 5 0 9 A T A L Y S T WS-x5530 100% WS-U5531-FETX MDIX PORT 2 MDIX 10/100Mbps 10/100Mbps SUPERVISOR ENGINE I I I CONSOLE LINK LINK Switch Load PCMCIA EJECT WS-x5530 10/100 FAST ETHERCHANNEL 100% WS-U5531-FETX MDIX PORT 2...

  • Page 2: Prepare For Installation

    • ESD grounding strap and antistatic mat • Numbers 1 and 2 Phillips screwdrivers and 3/16-inch flat blade screwdriver • Tape measure and level Ensure your safety when installing the Catalyst 5509 switch: • Lift the chassis safely • Cooperate with the natural laws of electricity •...

  • Page 3: Rack-Mount The Switch

    Rack-Mount the Switch Install the shelf brackets and crossbar bracket Secure each shelf bracket to the rack using six (three Shelf bracket per side) 12-24 or 10-32 screws. Attach the crossbar bracket to the back of the shelf brackets using two (one per side) M3 screws. Note: The shelf brackets and crossbar support the chassis in the rack, so no shelf is required.

  • Page 4: Install The Switch In The Rack

    Rack-Mount the Switch (continued) Install the switch in the rack Note: Three people are required to install the switch in an open rack. To make the switch easier to lift, remove the power supplies and modules before installing the switch in the rack. Position one person on each side of the chassis.

  • Page 5: Connect The Switch To The Network

    Connect the Switch to the Network Connect a terminal to the console port Caution To prevent ESD damage to electronic components, always use an ESD wrist strap when handling modules or coming into contact with internal components. Supervisor Engines I and II To connect a terminal to the Supervisor Engine I or II console port, plug an EIA/TIA-232 (RS-232) DCE DB-25-to-DTE DB-25 straight-through...

  • Page 6: Media-Independent Interface (Mii)

    Connect the Switch to the Network (continued) Connect the switch ports to the network Note: If you are not sure which cable and connector to use for a particular module, refer to the Catalyst 5000 Series Module Installation Guide. RJ-45 To connect to modules with RJ-45 interfaces, use Category 5 UTP (100BaseTX, 10/100BaseTX, CDDI, Token Ring, ATM), Category 3 UTP (10BaseT), or Type 1...
  • Page 7 Connect the Switch to the Network (continued) RJ-21 Telco To connect to modules with RJ-21 Telco interfaces, use Category 3 UTP cable with male RJ-21 Telco connectors. SC-Type Fiber Optic To connect to modules with SC-type fiber-optic interfaces, use single-mode or multimode fiber-optic cable with male SC-type connectors.
  • Page 8 Connect the Switch to the Network (continued) MIC-Type Fiber Optic To connect to the FDDI module MMF (WS-X5101), use multimode fiber-optic cable with a male MIC-type connector. To connect to the ATM dual PHY DS3 module ACTIV E LINK (WS-X5166), use 75-ohm RG-59 coaxial cable with male BNC connectors.

  • Page 9: Connect The Power

    Connect the Power Warning Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Caution To prevent ESD damage to electronic components, always use an ESD wrist strap when handling modules or coming into contact with internal components.

  • Page 10: Dc Power Supplies

    Connect the Power (continued) DC power supplies Warning Before performing the following procedure, remove power to the DC-input circuit by turning the circuit breaker OFF. Verify that each power supply is correctly installed in its bay and that the power switches are OFF (0).
  • Page 11 Connect the Power (continued) Replace the terminal block cover. On a new installation, remove the adhesive strip covering the CO ground connector (see figure for connector location). Connect a 10- to 12-AWG, copper conductor, ground wire to the CO ground connector. Use a ground wire lug that is 0.320 of an inch (7.8 mm) or less.

  • Page 12: Start The System

    Start the System Before you start the system, verify the following: • All modules are installed correctly and all interface cable connections are secure. • Each power supply is installed correctly and is connected to a grounded power source. • If two power supplies are present, each power cord is connected to a different line. •...

  • Page 13: Inserting And Removing Modules

    Inserting and Removing Modules Caution To prevent ESD damage to electronic components, always use an ESD wrist strap when handling modules or coming into contact with internal components. Inserting a module into the chassis Align the edges of the module with the card guides on each side of the slot (see figure). Ensure that the ejector levers are in the out position.
  • Page 14 Inserting and Removing Power Supplies Caution To prevent ESD damage to electronic components, always use an ESD wrist strap when handling modules or coming into contact with internal components. Inserting a power supply into the chassis Ensure that the power supply is disconnected and the switch is turned OFF (0). Slide the power supply straight into the power supply bay (see figure).
  • Page 15 Inserting and Removing Power Supplies (cont.) Removing a power supply from the chassis AC power supplies Turn OFF (0) the power switch. Disconnect the power cord from the power source and from the power supply. Use a flat-blade screwdriver to loosen the captive installation screw. Grasp the power supply handle and pull the supply straight out of the bay, supporting the supply with your other hand (see figure).
  • Page 16 Copyright © 1998 Cisco Systems, Inc. All rights reserved. AccessPath, AtmDirector, the CCIE logo, CD-PAC, Centri, Centri Bronze, Centri Gold, Centri Security Manager, Centri Silver, the Cisco Capital logo, Cisco IOS, the Cisco IOS logo, CiscoLink, the Cisco Powered Network logo, the Cisco Press logo, ClickStart, ControlStream, Fast Step, FragmentFree, IGX, JumpStart, Kernel Proxy,...
