Connecting Wireless LAN and Network Devices
With your wireless and network devices (smartphone, laptop, for instance) you can
use FRITZ!Powerline 540E as an access point to the home network and the Internet.
You can connect devices using a LAN cable or wirelessly.
If you have adopted the wireless LAN settings of the FRITZ!Box (see page 9), the
following applies:
 FRITZ!Powerline adopted the name (SSID) and the network key of the FRITZ!Box's
wireless network. When a wireless connection is established, wireless devices
automatically select the wireless network (FRITZ!Powerline 540E or FRITZ!Box)
with the stronger radio signal.
 If you move to a different location in your home
with a wireless device (notebook, for instance),
the device switches automatically between the
two wireless networks.
If you did not adopt the wireless settings of the
FRITZ!Box in FRITZ!Powerline 540E, establish
wireless connections as follows:
1. Remove FRITZ!Powerline 540E from the outlet
and take note of the network key printed
on the back of the device.
2. Select your FRITZ!Powerline 540E's wireless network
on the wireless device and enter the network key.
10
FRITZ!Powerline 540E
v2
Powerline device password:
ABCD-EFGH-IJKL-MNOP
Network key (WPA2):
3779 8981 1562 8981 1234
00:00:00:00:00:00
Powerline-MAC:
D022.454.40.000.001
Serial no.:
Article no.: 2000 2667
230V~; 0,1A; 50Hz
Button functions:
WLAN • WPS: Status display, wireless device registration
Powerline • Security: Status display, device registration
AVM GmbH, 10547 Berlin
Example Do not use this
network key
The FRITZ!Powerline 540E User Interface
Open the FRITZ!Powerline 540E user interface in your web browser by entering
 fritz.powerline, if FRITZ!Powerline 540E is connected with a FRITZ!Box.
 192.168.178.2, if FRITZ!Powerline 540E is
 the
address>. The IP address is assigned by your Internet router as soon as
<IP
one or more FRITZ!Powerline 540E adapters are located in your home network.
In the user interface you can, for instance, configure wireless LAN settings, switch
on and off wireless LAN, Powerline and the LEDs, change the operating mode, or
perform a FRITZ!OS update.
Access the Home Network
FRITZ!Powerline 540E can establish acccess to the home network of your FRITZ!Box
or your Internet router via a powerline, a wireless LAN or a LAN bridge (connection)
herstellen. The recommended and preconfi gured access method is the Powerline
Bridge. When access is established via a wireless bridge, FRITZ!Powerline 540E can
work as a pure wireless repeater to expand the radio network of your Internet router.
With the LAN bridge FRITZ!Powerline 540E expands your Ethernet home wiring.
The type of access can be switched in the FRITZ!Powerline 540E user interface For
more information, see the instructions in the FRITZ!Powerline 540E PDF manual at
http://en/avm.de/service/manuals/fritzpowerline.
not connected with a router yet.
