- Page 1 GeoRef V2 Series Hardware Operating Instructions (For GeoRef V2E and GeoRef V2G Wuhan Geosun Information Technology Co.,Ltd...
- Page 3 Welcome to use GeoRef V2 series. This book describes how to install, set up and use GeoRef V2E and GeoRef V2G. Please refer to GPac User’s Manual for more information about GPac, the multi-function GNSS data collecting & processing software embedded in the GeoRef V2 series.
-
Page 5: Table Of Contents
Contents Overview ................................1 GeoRef V2 Series Overview ........................2 Innovative Technology .......................... 3 Configuration Advantages ........................4 Notice ..............................5 GeoRef V2 Series Introductions ........................6 Front View ............................. 7 Back View ............................. 8 Interfaces ............................... 9 Main Parts ............................10 Standard Configuration List ......................... - Page 6 Visiting GeoRef V2 Series Handheld....................35 Technical Parameters ............................36 System Configuration .......................... 37 GPS Performance ..........................37 Positioning Accuracy ........................... 37 Interfaces ............................. 37 Power Performance ..........................38 Application Function ........................... 38 Physics ..............................38 Electric Specifications ......................... 38 Troubleshooting..............................
-
Page 7: Overview
Overview C H A P T E R GeoRef V2 Series Overview Innovative Technology Configuration Advantages Notice... -
Page 8: Georef V2 Series Overview
GeoRef V2, GeoRef V2E and GeoRef V2G. This book mainly describes technical parameters and operation instructions of GeoRef V2E and GeoRef V2G. Both GeoRef V2E and GeoRef V2G are integrated with high-accuracy surveying GPS and high performance navigation GPS, as well as 3D electronic compass, high resolution camera, Bluetooth communication and WiFi communication modules. -
Page 9: Innovative Technology
The embedded digital camera can capture the related image on-site directly for convenient attribute annotation while the built-in microphone supports audio information on-site annotation. And the GEOSUN gPac software installed inside will automatically match the image with current GPS position for the convenient background application. -
Page 10: Configuration Advantages
Configuration Advantages Professional Software Support GPac software of Geosun is a professional GNSS data acquisition and processing software suite, which adopts unique high-accuracy data processing algorithm and contains many optional application modules. With gPac, you can easily handle the point, line, plane, annotation and other geographic and images, and realize seamlessly integration of field work and office work. -
Page 11: Notice
Overview Notice Although GeoRef V2 series handheld is made of corrosion-resistant and impact-resistant materials, this kind of sophisticated instrument still needs careful usage and maintenance. Please preserve the handheld in dry environment as possible. To improve the stability and service life, the handheld should avoid being exposed to extreme environment, such as damp, high temperature, low temperature, corrosive gas or liquid, etc. -
Page 12: Georef V2 Series Introductions
GeoRef V2 Series Introductions C H A P T E R Front View Back View Interfaces Main Parts Standard Configuration List Optional Configuration List... -
Page 13: Front View
GeoRef V2 Series Introductions Front View Power Status Indicator Communication Status Indicator Start Charging Radio Mode Flashes alternately in Charging Status: 80% GPRS/3G Green red and orange Fully charged Orange Bluetooth Orange Fully charged Green WiFi Flashes in green Discharging (While Working) Status: 20% Flashes slowly in green... -
Page 14: Back View
GeoRef V2 Series Hardware Operating Instructions Back View Camera Nameplate SIM Card/ Strap Micro SD Card Slot Touch Pen... -
Page 15: Interfaces
GeoRef V2 Series Introductions Interfaces External GPS Antenna Interface SIM Card Slot Micro SD Card Slot I/O Interface... -
Page 16: Main Parts
GeoRef V2 Series Hardware Operating Instructions Main Parts Data Cable Charger & Adapter* Power Charging Cable External GPS Antenna (Optional) External Antenna Connecting Cable (Optional) * We will choose one suitable (USA, England or Europe type, etc.) for you Adapter according to your local requirement. -
Page 17: Standard Configuration List
Data Cable (USB Plug + Serial Port_D-Sub9 Female) Power Charging Cable Micro SD Card (2G Byte, Flash Type) Touch Pen Caravel PP/Net Software dongle GEOSUN CD (Containing all GEOSUN catalogues, software, manual, video) GeoRef V2 Series Bag GeoRef V2 Series Carry Case Optional Configuration List... -
Page 18: Basic Operations
Basic Operations C H A P T E R Taking Out and Putting Back the Touch Pen Power On Power Off Stylus Property Settings Power Management Installing Micro SD Card Installing SIM Card ... -
Page 19: Taking Out And Putting Back The Touch Pen
Basic Operations Taking Out and Putting Back the Touch Pen The touch pen is in the pen slot at the back of the handheld, as shown below. Gently pull the touch pen cap, and take it out. To put back the touch pen, make the cap towards the outside, and then push it until the top of the pen reaches the end of the slot. -
Page 20: Power On
GeoRef V2 Series Hardware Operating Instructions Power On Press the power button for 2 seconds, the handheld will turn on and load WinCE system automatically, as shown below left. The start process will last for about 10 seconds, please be patient. When the start process is completed, the desktop of WinCE system will be as shown below right. - Page 21 Basic Operations Set the double-tap speed. Double tap the grid pattern to set double-tap speed and double tap the file icon to test the double tap setting in Double-Tap page, as shown below left. Calibrate the touch screen. Tap the Recalibrate button to open Calibration page, as shown above right.
-
Page 22: Power Management
GeoRef V2 Series Hardware Operating Instructions Power Management Charging Connect the power adapter to the power cable, and then connect the other end Lemo port of the power cable to the I/O port of the handheld, as shown below. The handheld will be on charging once the power is connected. -
Page 23: Smart Charging
Basic Operations Methods and requirements: Commonly there will be some power left in the battery before users start to use it. Please firstly run out of all the power before first charging. Please charge the handheld for 12 hours continuously for the first three times, and later on 6 to 8 hours charging is enough. -
Page 24: Power Saving Mode
GeoRef V2 Series Hardware Operating Instructions Note: This is because the charging voltage detected by WinCE is a little higher than the real battery voltage. Constant pressure charging is important for full charging. Please complete the whole charging process to ensure the working time. Power Saving Mode In default condition, screen backlighting will be turned off automatically if no operation (press keys or tap touch screen) has been carried out within 1 minute. -
Page 25: Installing Sim Card
Basic Operations You can remove the Micro SD card by lightly pressing the card to make it half pop-out, and then pull it out gently. Note: Micro SD card (TF card) is a small-size external flash memory card. It is usually used in cell phone, PDA etc. -
Page 26: Serial Port Settings
GeoRef V2 Series Hardware Operating Instructions You can remove the Micro SD card by lightly pressing the card to make it half pop-out, and then pull it out gently. Note: Please close the plug to isolate the handheld from water and dust. Serial Port Settings Double tap the Communication Mode Settings icon in the Control Panel, as shown... -
Page 27: Bluetooth And Wifi Settings
Basic Operations Serial port 1 can be set as radio (PC) or GPRS. The default is radio (PC). Serial port 2 can be set as surveying GPS (COM1) or navigation GPS (COM1). The default is surveying GPS (COM1). ... -
Page 28: Bluetooth Settings
GeoRef V2 Series Hardware Operating Instructions Tap the Turn On button in the Bluetooth area you can enable the Bluetooth. When the Bluetooth is enabled, you can tap the Turn Off button in the Bluetooth area to disable it. Similarly, Tap the Turn On button in the WiFi area you can enable the WiFi. When the WiFi is enabled, you can tap the Turn Off button in the WiFi area to disable it. - Page 29 Basic Operations Tap the Scan Device button, the handheld begins to scan Bluetooth devices within 10 meters, and shows them in the Scan Device page, as shown below left. Double tap the device to connect, select the Trusted item in the appeared menu, as shown below right. The Bluetooth Manager dialog box appears, as shown below left, tap the Yes button.
- Page 30 GeoRef V2 Series Hardware Operating Instructions When the other device finishes confirmation, the symbol turns to , which means the matching is successful, as shown below left. After the matching is successfully set up, if a file is transmitted from the other device, the Bluetooth file transmission window pops up automatically, as shown below right.
-
Page 31: Bluetooth Dial-Up Connection
Basic Operations Bluetooth Dial-up Connection Usually, while scanning the devices, several items will be shown for the same device. For example, the Nokia device shows in the left picture below. To implement its Bluetooth Dial-up function, please double tap the item with the icon ahead, and then select the Trusted item, and input the matching password. - Page 32 GeoRef V2 Series Hardware Operating Instructions Select the matching device in the Modem dialog box, and tap the Configure button. Then a Bluetooth authority request will appear in the other device. When the request is accepted by the other device, pops up the Device Properties dialog box, as shown below left.
-
Page 33: Wifi Settings
Basic Operations WiFi Settings When WiFi is enabled, the icon appears in the task bar, as shown below left. Double tap the icon , the UFMP1 dialog box appears, tap the Wireless Information tag, as shown below right. The system will search surrounding WiFi networks automatically, and list them in the... - Page 34 GeoRef V2 Series Hardware Operating Instructions Wireless Information page. Double tap the WiFi network to connect, pops up the Wireless Network Properties dialog box, as shown below left. Select the encryption method and the authentication type, input the network password, and tap the OK button to finish. Users can check the signal status and signal strength in the Wireless Information page, and check the assigned IP address in the IP Information page.
- Page 35 Basic Operations Double tap the UFMP1 icon , pops up the following dialog box. Select “Specify an IP address”, input the IP address, subnet mask and default gateway, tap the OK button to finish.
-
Page 36: Using The Electronic Compass
GeoRef V2 Series Hardware Operating Instructions Using the Electronic Compass Find the Compass icon in the Control Panel interface, as shown below left. Double tap the Compass icon, the compass interface appears, as shown below right. The electronic compass is able to provide the accurate direction for user even with pool satellite signals, and in low-speed or static status. -
Page 37: Installing, Uninstalling Or Updating Gpac Software
Basic Operations Warning: To avoid data loss, please do not try this operation if it’s not necessary. Make sure the backup of software and data have been done before this operation. Installing, Uninstalling or Updating GPac Software For details, please refer to the gPac User’s Manual. Upgrading the Firmware Method 1: Connect V2 Series to PC with data cable. - Page 38 GeoRef V2 Series Hardware Operating Instructions Click the Explore button of Microsoft ActiveSync to open R2 series resource browser. Copy the latest version firmware file to “Storage Card”. In the power off status, keep pressing the “ESC” button and press the power button, the handheld will turn on and the interface of “Updating the firmware, please wait…”...
-
Page 39: Connecting To Pc
Connecting to PC C H A P T E R Installing Microsoft ActiveSync Hardware Connection Setup with PC Microsoft ActiveSync Automatic Connection Visiting GeoRef V2 Series Handheld... -
Page 40: Installing Microsoft Activesync
GeoRef V2 Series Hardware Operating Instructions Installing Microsoft ActiveSync GeoRef V2 series is compatible with ActiveSync 4.5 or later. You can download the latest version from the Microsoft website at: http://www.microsoft.com/download/en/details.aspx?id=15 After installing the Microsoft ActiveSync, click the Start > Program menu item, find and run Microsoft ActiveSync. -
Page 41: Microsoft Activesync Automatic Connection
Connecting to PC Microsoft ActiveSync Automatic Connection After the data cable has been connected, Microsoft ActiveSync on the computer will recognize the handheld device and connect automatically. Then select “No” if it asks “Set Up a Partnership Yes or No?” and click Next, the connection will be completed successfully. If it is the first time of connection, the driver will be required. -
Page 42: Technical Parameters
Technical Parameters C H A P T E R System Configuration GPS Performance Positioning Accuracy Interfaces Power Performance Application Function Physics Electric Specifications... -
Page 43: System Configuration
Technical Parameters This chapter describes the technical parameters of Geosun GeoRef V2 series. The specifications are subject to change without notice. System Configuration Operating System: Windows CE 6.0 Microprocessor: 1GHz industrial-grade processor Storage: 512 MB DDR2 SDRAM, built-in 512MB flash memory ... -
Page 44: Power Performance
GeoRef V2 Series Hardware Operating Instructions Power Performance Battery: Built-in 7.4V Li-Ion battery, 4400mAh Continuous operating time: Just GPS: 9 hours GPS + GPRS/3G: 7 hours Application Function Wireless communication V2E: Built-in GPRS wireless communication module; V2G: Built-in 3G (WCDMA) wireless communication module ... -
Page 45: Troubleshooting
Troubleshooting C H A P T E R Common Troubleshooting ActiveSync Common Problems... -
Page 46: Common Troubleshooting
GeoRef V2 Series Hardware Operating Instructions Common Troubleshooting Problem Cause Solution Can’t turn on. Low battery. Recharge the battery. Working temperature is beyond the allowed Bring the handheld into the environment range (-20 ℃ ~ 60 ℃). where the temperature is in the allowed range. -
Page 47: Activesync Common Problems
Check "Allowing the USB connection" in File > enabled in ActiveSync. Connection Settings. Microsoft USB driver is Install Microsoft USB driver. not installed. If the problem you encounter still cannot be solved, please contact us. Geosun will offer you excellent after-sales service. -
Page 48: Index
GeoRef V2 Series Hardware Operating Instructions Index 3G High-speed Remote Wireless Integrated Handheld Design, 4 Communication, 3 Intelligent Speech Technology, 3 Application Function, 38 Interfaces, 9, 37 Back View, 8 Main Board, 37 Battery, 4, 38 Main Parts, 10 Bluetooth Settings, 21 Micro SD Card, 11, 37 Calibrate the touch screen, 15 Microprocessor, 37... -
Page 49: Contact Us
Thank you for using our GeoRef V2 series. We will do our best to provide you the best pre-sales and after-sales service. Please feel free to contact us for any usage condition or advice about GeoRef V2 series. Wuhan Geosun Information Technology Co.,Ltd Add: 5F West Research building, No.312 Luoyu Rd Hongshan District, Wuhan 430070, China.
