TOM Child Bed (115,140)
st
2006/1
Edition
ASSEMBLY MANUAL
_________________________________________________________________
LINET, spol. s r. o.
Tel.: + 420 312 / 576 111
Želevčice 5
Fax: + 420 312 / 522 668
274 01 Slaný
Czech Republic
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LINET TOM 115
Summary of Contents for LINET TOM 115
- Page 1 ____________________________________________________ TOM Child Bed (115,140) 2006/1 Edition ASSEMBLY MANUAL _________________________________________________________________ LINET, spol. s r. o. Tel.: + 420 312 / 576 111 Želevčice 5 Fax: + 420 312 / 522 668 274 01 Slaný Czech Republic...
-
Page 2: Necessary Tools
________________________________________________ This Assembly Manual can be used for complete assembly of children beds TOM 115 (points 1 – 13, 19, 20), TOM 140 (points 1 – 20). It is recommended to process the assembly with at least two workers. NECESSARY TOOLS... - Page 3 _________________________________________________ 2. Than place the side part A to a Foot Head floor (we recommend to use the side side cardbox support pad to prevent damage of powder coating) Important – you must keep the correct position of mattress platform – head side (with wide handle attached on it) must be placed on head side of side part A.
- Page 4 ________________________________________________ … Position near to the foot bed _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 5 _________________________________________________ 4. Put the foot bed end on the frame and fix it by the blind nut M10. _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 6 ________________________________________________ 5. Thread the head bed-end over the handle of mattress platform. 6. Put the head bed end on the screw and fix it by the nut M10. _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 7 _________________________________________________ 7. Two workers will pick the second side part B up and place it on the bed frame. 8. Fix and tighten the bed ends to a side part B by blind nuts M10 _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 8 ________________________________________________ …remove the blue ribbon and tighten the imbedded hexagonal screws. _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 9 _________________________________________________ 9. Take the riveted guide rail and touch it to a feet of the bed (with stop screws near to the feet) and tighten this guide rail with a M10 screw and nut from both sides. 10. Do it the same with second riveted guide rail on the other side of the bed.
- Page 10 ________________________________________________ 12. Remove the blue ribbon from imbedded screws in lower part of the bed and tighten the hexagonal screws. 13. Tighten all the lower M10 screws and check the solidness of mattress platform. 14. Screw the threaded bar used for adjustment of back-rest to a silon part K _________________________________________________________________...
- Page 11 _________________________________________________ 15. Put the silon washer on the other side of threaded bar. 16. Lift up the back-rest and put the end of threaded bar on the hanger on the mattress platform. 17. Put the silon bushing X, distance coated tube Y and the control wheel Z (which match with the hole on the threaded bar) and secure the position with a spring...
- Page 12 ________________________________________________ 18. Screw the two nuts to an end of threaded bar (approx. 1,4 cm from the end) and tighten them (counterpart) _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 13 _________________________________________________ 19. Screw and tighten both handles of mattress platform. _________________________________________________________________ TOM Child Bed 2006, 1 Edition...
- Page 14 21. Check all joints and functions of the bed before use. If you will have any problems with assembly, please contact our service dept. LINET spol. s r.o. Želevčice 5, 274 01 Slaný, Czech Republic − Service and Claim Department Tel.: +420 312 576 260...
