ZIEHL TR1200 Quick Manual

Temperature Relays and MINIKA®
Quick Guide TR1200
- Pt 100 thermostat with 12 sensor ports and Interface RS485
Detailed operating manual see:

1 Display and controls

1 LED relay state (yellow)
OFF
Illuminated
2 LED sensors (yellow)
Illuminated
flashes, 8Er18or8Er28
All illuminated
3 Digital display 3 digits (red)
Display of sensor value
Display of error codes e.g.
4 Hindmost decimal point (red)
OFF
Illuminated
flashes
5 LED error (red)
OFF
Illuminated with
8Er88 or
6 Button Up / Down (display mode, normal operation)
Press briefly
Press for > 2s
7 Button Set / Reset (display mode, normal operation)
Press briefly
Press for > 2s
Press for > 10s
8 LED RS485 Interface (yellow)
Rx flashes briefly
Tx flashes briefly
TR1200 12320-0752-04
Mains Monitoring Digital Panelmeters MINIPAN®
http://www.ziehl.com/en/Products/detail/TR1200-39
The relay is released
The relay is picked up
Displays the sensor value belonging to the LED in the digital
display
Sensor error in the corresponding sensor circuit
Displays the value of the warmest sensor in the digital display
8Er98
Display Mode
Menu mode
Parameter mode
8Er18 , 8Er28 ,
8Er98
Change into the menu mode (see Operating instructions Point 8.4)
Displays the stored MAX value (Up) / MIN value(Down) – press also
button Set for ≥ 2s to erase the stored value
Displays the value of next sensor (sensor LED illuminates)
Reset, back to display mode
Displays the software version (e.g. 000)
Unit is receiving data via the RS485 interface
Unit is transmitting data via the RS485 interface
Switching Relays and Controls
normal operation
Sensor error, malfunction, invalid parameter
Page 1 / 8
