Page 18
Line Lock Out Function START Line Lock Out Function STOP START...
Page 19
If the control lamp is lit: The restart cut-out is active. The machine will not start if the battery is fi tted whilst the machine is switched on. Switch the machine off and then on again.
Page 21
The control lamp fl ashes: To protect the tool, please let it continue rotating with no-load, or lamp is off; Load-dependent motor reduce the load until the protection: if the motor is overloaded, it will trip the overload protection and the tool will automatically stop rotating. To continue working, switch the machine off and then on again.
TECHNICAL DATA Cordless Angle Grinder BEWS18-115 X BEWS18-125 X Battery voltage......................18 V ....... 18 V Rated speed ......................9000 min ...... 9000 min Grinding disk diameter.....................115 mm ......125 mm Thread of work spindle ..................M 14 ......M 14 Weight according EPTA-Procedure 01/2003 ........
Page 23
m) Do not run the power tool while carrying it at your side. e) Do not use worn down wheels from larger power tools. Accidental contact with the spinning accessory could snag your Wheel intended for larger power tool is not suitable for the clothing, pulling the accessory into your body.
If needed, an exploded view of the tool can be ordered. Please For accessories intended to be fi tted with threaded hole wheel, state the ten-digit No. as well as the machine type printed on ensure that the thread in the wheel is long enough to accept the label and order the drawing at your local service agents or the spindle length.
Page 25
To obtain the longest possible battery life remove the battery pack from the charger once it is fully charged. For battery pack storage longer than 30 days: Store the battery pack where the temperature is below 27°C and away from moisture Store the battery packs in a 30% - 50% charged condition Every six months of storage, charge the pack as normal.
