1/4" AIR RIVETER INSTRUCTION MANUAL
Speci ca ons:
Nosepiece: 1/8", 5/32", 3/16", 1/4"
Rivet Capacity: 1/4"
Motor: 1/2 Hp
Air Inlet Thread NPT: 1/4"
Air Hose I.D. Size: 3/8" (10mm)
Avg. Air Consumption: 4 CFM
Air Pressure: 90-120 psi
Pulling Force: 2646 lbs.
ATD-5851
WARNING: This product can expose you to chemicals, including lead, which are known to the
State of California to cause cancer, birth defects or other reproductive harm.
For more information go to www.P65Warningsca.gov.
Made in China to ATD Tools, Inc. Specifications
Visit us at www.atdtools.com
ATD5851_rev_0717

Advertisement

loading
Need help?

Need help?

Do you have a question about the ATD-5851 and is the answer not in the manual?

Questions and answers

Related Manuals for ATD AIR ATD-5851

Summary of Contents for ATD AIR ATD-5851

  • Page 1 ATD-5851 1/4” AIR RIVETER INSTRUCTION MANUAL Speci ca ons: Nosepiece: 1/8", 5/32", 3/16", 1/4" Rivet Capacity: 1/4” Motor: 1/2 Hp Air Inlet Thread NPT: 1/4” Air Hose I.D. Size: 3/8” (10mm) Avg. Air Consumption: 4 CFM Air Pressure: 90-120 psi Pulling Force: 2646 lbs.

  • Page 2: General Safety Warnings

    General Safety Warnings: WARNING: The instruc ons and warnings contained in this manual should be read and understood before using or opera ng this tool. Do not allow anyone to use or operate this tool un l they have read this manual and have developed a thorough understanding of how this tool works.
  • Page 3 WARNING: Always check for damaged, frayed or loose hoses and ngs. Have any defec ve or damaged parts replaced immediately by qu ed personnel. WARNING: Do not carry the tool by the hose. Protect the hose from sharp objects and heat. WARNING: Always use air hose and couplings with a minimum working pressure ra ng of at least 1-1/2 mes the maximum working pressure ra ng of the tool.
  • Page 4 The nosepieces are stored under the rubber base. Maintenance/Adding Oil for Hydraulic Riveter Your ATD-5851 riveter should be ready to use from the box, however maintenance will be needed periodically, and varies hydraulic oil such as Mobil DTE 10 or equivalent.
  • Page 5 ATD-5851...
  • Page 6 ATD-5851 ITEM# ORDERING PART# PART DESCRIPTION ITEM# ORDERING PART# PART DESCRIPTION PRT5851-01 NOSEPIECE (SET OF 4) PRT5851-26 LINK PRT5851-02 OUTER CYLINDER PRT5851-27 PRESS PLANK PRT5851-03 JAW CARRIER PRT5851-28 AIR VALVE PRT5851-04 PRT5851-29 VALVE SPRING PRT5851-05 JAW PUSHER PRT5851-30 COPPER WASHER...
