MEDIA 2
O P E R AT I O N S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the media 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for SurfLink media 2

  • Page 1 MEDIA 2 O P E R AT I O N S M A N U A L...
  • Page 2: Table Of Contents

    Configuring Audio Settings ..........12 Electronic Audio Source – These provide the audio content that can be streamed through SurfLink Media 2 to your hearing instruments.
  • Page 3: Rear Panel Overview

    Supply LED: The LED indicator provides helpful information 4. Coaxial S/PDIF Jack: This cable can be obtained about the current state of SurfLink Media 2. from your professional (ask for part #90971-000). 1. Microphone Jack: Mono external microphones Mono/Stereo Switch:...
  • Page 4: Basic Use

    Basic Use To quickly start using SurfLink Media 2 with a typical setup: 5. Choose appropriate settings for Audio Fidelity switch: Selected Hearing Instruments • All wireless hearing instruments can stream audio from bottom Audio 1. Insert a TOSLINK cable into the Audio OUT jack on switch position ( your electronic audio source.
  • Page 5: Connecting To Power

    Turn on SurfLink Media 2 by pressing the front power button until it glows blue. To apply power to SurfLink Media 2: If the rear LED glows solid green, then SurfLink Media 2 is detecting an incoming audio signal. 1. Plug the power adaptor into a wall socket.
  • Page 6: Using With External Microphone

    The External Microphone takes priority over all incoming audio into SurfLink Media 2. TIP: If your electronic audio source has multiple AUDIO OUT jacks, only use one. You can connect SurfLink Media 2 to multiple electronic audio sources by using a combination of different cable styles.
  • Page 7: Configuring Audio Settings

    When initially setting up SurfLink Media 2, a solid green LED confirms that an electronic audio source is outputting audio at a detectable level and the cable is properly attached to SurfLink Media 2. If you are not hearing streamed...
  • Page 8: Front Panel Overview

    TIP: During initial setup, a solid green LED confirms a proper cable hookup between SurfLink Media 2 and your electronic audio source. streaming level, slide your finger left or right to find a comfortable listening position. Volume adjustments made on SurfLink Media 2 do not affect a hearing instrument microphone volume level, nor do they affect the volume setting of the electronic audio source.
  • Page 9: Streaming To Hearing Instruments

    ) can be used to start and stop audio streaming. To use a remote • Try using another audio output jack (which may require a different type control during audio streaming, aim the remote control directly at SurfLink Media 2 as the command is actually of cable) on your television.
  • Page 10: Safety Information

    International Use Your SurfLink Media 2 is approved to operate at a radio frequency that is specific to your country or region and might not be approved for use outside your country or region. Be aware that operation during international travel may cause interference to other electronic devices, or other electronic devices may cause interference to your SurfLink Media 2.
  • Page 11: Regulatory Notices

    6600 Washington Ave. South Eden Prairie, MN USA The North American version of SurfLink Media 2 operates in the 902-928 MHz frequency band with a maximum FCC Notice effective radiated power of 14.5 dBm with transmission modulation type of 723KF1D. The receiver section of This device complies with part 15 of the FCC rules and with Industry Canada license-exempt RSS standards.
  • Page 12 Notes Notes...
  • Page 13 Dolby Digital is a registered trademark of Dolby Laboratories. © 2018 Starkey Hearing Technologies. All Rights Reserved. 81922-007 1/18 BKLT2822-05-EE-XX...
